7I2L | pdb_00007i2l

Group deposition for crystallographic fragment screening of the NS5 RNA-dependent RNA polymerase from Dengue virus serotype 2 -- Crystal structure of the NS5 RNA-dependent RNA polymerase from Dengue virus serotype 2 in complex with Z1627772104 (DNV2_NS5A-x0566)

PDB DOI: https://doi.org/10.2210/pdb7I2L/pdb
Deposition Group: G_1002341 (changed state) | Explore G_1002341

Classification: VIRAL PROTEIN
Organism(s): dengue virus type 2
Expression System: Escherichia coli
Mutation(s): No

Deposited: 2025-03-06 Released: 2025-04-02
Deposition Author(s): Aschenbrenner, J.C., Saini, M., Chopra, A., Marples, P.G., Balcomb, B.H., Lithgo, R.M., Fearon, D., von Delft, F., Ruiz, F.X., Arnold, E.
Funding Organization(s): National Institutes of Health/National Institute Of Allergy and Infectious Diseases (NIH/NIAID)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.03 Å
R-Value Free:
0.243 (Depositor), 0.300 (DCC)
R-Value Work:
0.200 (Depositor), 0.280 (DCC)
R-Value Observed:
0.203 (Depositor)

wwPDB Validation 3D Report Full Report

Ligand Structure Quality Assessment

This is version 1.1 of the entry. See complete history.

Literature

Crystallographic Fragment Screening of the Dengue Virus Polymerase Reveals Multiple Binding Sites for the Development of Non-nucleoside Antiflavivirals.

Saini, M., Aschenbrenner, J.C., Ruiz, F.X., Chopra, A., Chandran, A.V., Marples, P.G., Balcomb, B.H., Fearon, D., von Delft, F., Arnold, E.

(2025) J Med Chem 68: 18356-18369

PubMed: 40892049 Search on PubMed Search on PubMed Central
DOI: https://doi.org/10.1021/acs.jmedchem.5c01014

PubMed Abstract:
Dengue viruses (DENVs) infect approximately 400 million people each year, and currently, there are no effective therapeutics available. To explore potential starting points for antiviral drug development, we conducted a large-scale crystallographic fragment screen targeting the RNA-dependent RNA polymerase (RdRp) domain of the nonstructural protein 5 (NS5) from DENV serotype 2. Our screening, which involved 1108 fragments, identified 60 hit compounds across various known binding sites, including the active site, N pocket, and RNA tunnel. Additionally, we discovered a novel binding site and a fragment-binding hot spot in thumb site II. These structural findings open amenable avenues for developing non-nucleoside inhibitors and offer valuable insights for future structure-based drug design aimed at DENV and other flaviviral RdRps.

Organizational Affiliation

Center for Advanced Biotechnology and Medicine, Rutgers, the State University of New Jersey, Piscataway, New Jersey 08854, United States.

Macromolecule Content

Total Structure Weight: 75.01 kDa
Atom Count: 4,990
Modeled Residue Count: 566
Deposited Residue Count: 637
Unique protein chains: 1

Macromolecules

Find similar proteins by:

| 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
NS5 RNA-dependent RNA polymerase	A	637	dengue virus type 2	Mutation(s): 0 EC: 2.7.7.48
UniProt
Find proteins for Q91H74 (Dengue virus type 2) Explore Q91H74 Go to UniProtKB: Q91H74
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	Q91H74
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 7 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
A1B0O (Subject of Investigation/LOI) Query on A1B0O Download:Ideal Coordinates CCD File SDF format, chain K [auth A] MOL2 format, chain K [auth A] mmCIF format, chain K [auth A]	K [auth A]	(3S)-3-(2-fluoro-3-methylphenoxy)-1-methylpyrrolidin-2-one C₁₂ H₁₄ F N O₂ ZGHOVIJLBUUPON-UHFFFAOYSA-N		Interactions Focus chain K [auth A] Interactions & Density Focus chain K [auth A]
MES Query on MES Download:Ideal Coordinates CCD File SDF format, chain D [auth A] MOL2 format, chain D [auth A] mmCIF format, chain D [auth A]	D [auth A]	2-(N-MORPHOLINO)-ETHANESULFONIC ACID C₆ H₁₃ N O₄ S SXGZJKUKBWWHRA-UHFFFAOYSA-N		Interactions Focus chain D [auth A] Interactions & Density Focus chain D [auth A]
PEG Query on PEG Download:Ideal Coordinates CCD File SDF format, chain J [auth A] MOL2 format, chain J [auth A] mmCIF format, chain J [auth A]	J [auth A]	DI(HYDROXYETHYL)ETHER C₄ H₁₀ O₃ MTHSVFCYNBDYFN-UHFFFAOYSA-N		Interactions Focus chain J [auth A] Interactions & Density Focus chain J [auth A]
PO4 Query on PO4 Download:Ideal Coordinates CCD File SDF format, chain H [auth A] SDF format, chain I [auth A] MOL2 format, chain H [auth A] MOL2 format, chain I [auth A] mmCIF format, chain H [auth A] mmCIF format, chain I [auth A]	H [auth A], I [auth A]	PHOSPHATE ION O₄ P NBIIXXVUZAFLBC-UHFFFAOYSA-K		Interactions Focus chain H [auth A] Focus chain I [auth A] Interactions & Density Focus chain H [auth A] Focus chain I [auth A]
DMS Query on DMS Download:Ideal Coordinates CCD File SDF format, chain E [auth A] SDF format, chain F [auth A] SDF format, chain G [auth A] MOL2 format, chain E [auth A] MOL2 format, chain F [auth A] MOL2 format, chain G [auth A] mmCIF format, chain E [auth A] mmCIF format, chain F [auth A] mmCIF format, chain G [auth A]	E [auth A], F [auth A], G [auth A]	DIMETHYL SULFOXIDE C₂ H₆ O S IAZDPXIOMUYVGZ-UHFFFAOYSA-N		Interactions Focus chain E [auth A] Focus chain F [auth A] Focus chain G [auth A] Interactions & Density Focus chain E [auth A] Focus chain F [auth A] Focus chain G [auth A]
ZN Query on ZN Download:Ideal Coordinates CCD File SDF format, chain B [auth A] SDF format, chain C [auth A] MOL2 format, chain B [auth A] MOL2 format, chain C [auth A] mmCIF format, chain B [auth A] mmCIF format, chain C [auth A]	B [auth A], C [auth A]	ZINC ION Zn PTFCDOFLOPIGGS-UHFFFAOYSA-N		Interactions Focus chain B [auth A] Focus chain C [auth A] Interactions & Density Focus chain B [auth A] Focus chain C [auth A]
CL Query on CL Download:Ideal Coordinates CCD File SDF format, chain L [auth A] MOL2 format, chain L [auth A] mmCIF format, chain L [auth A]	L [auth A]	CHLORIDE ION Cl VEXZGXHMUGYJMC-UHFFFAOYSA-M		Interactions Focus chain L [auth A] Interactions & Density Focus chain L [auth A]
