7FVI | pdb_00007fvi

PanDDA analysis group deposition -- PHIP in complex with Z183306756

PDB DOI: https://doi.org/10.2210/pdb7FVI/pdb
Deposition Group: G_1002265 (changed state) ExploreG_1002265

Classification: SIGNALING PROTEIN
Organism(s): Homo sapiens
Expression System: Escherichia coli
Mutation(s): No

Deposited: 2023-03-09 Released: 2023-03-29
Deposition Author(s): Grosjean, H., Tomlinson, C., Bradshaw, W.J., Koekemoer, L., Krojer, T., Fearon, D., Biggin, P.C., von Delft, F.
Funding Organization(s): Wellcome Trust

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.18 Å
R-Value Free:
0.212 (Depositor), 0.250 (DCC)
R-Value Work:
0.187 (Depositor), 0.230 (DCC)
R-Value Observed:
0.189 (Depositor)

wwPDB Validation 3D Report Full Report

Ligand Structure Quality Assessment

This is version 1.2 of the entry. See complete history.

Literature

Structure-activity relationships can be directly extracted from high-throughput crystallographic evaluation of fragment elaborations in crude reaction mixtures

Grosjean, H., Fieseler, K.K., Sanchez-Garcia, R., Thompson, W., Deane, C.M., von Delft, F., Biggin, P.C.

(2026) Chem Sci

DOI: https://doi.org/10.1039/D5SC04919A

Macromolecule Content

Total Structure Weight: 17.99 kDa
Atom Count: 1,256
Modeled Residue Count: 120
Deposited Residue Count: 149
Unique protein chains: 1

Macromolecules

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
PH-interacting protein	A	149	Homo sapiens	Mutation(s): 0 Gene Names: PHIP, DCAF14, WDR11
UniProt & NIH Common Fund Data Resources
Find proteins for Q8WWQ0 (Homo sapiens) Explore Q8WWQ0 Go to UniProtKB: Q8WWQ0
PHAROS: Q8WWQ0 GTEx: ENSG00000146247
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	Q8WWQ0
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
ZO5 (Subject of Investigation/LOI) Query on ZO5 Download Ideal Coordinates CCD File SDF format, chain B [auth A] MOL2 format, chain B [auth A] mmCIF format, chain B [auth A]	B [auth A]	N-[(2H-1,3-benzodioxol-5-yl)methyl]-4-(furan-2-carbonyl)piperazine-1-carboxamide C₁₈ H₁₉ N₃ O₅ OROHVINEJMFCOR-UHFFFAOYSA-N		Interactions Focus chain B [auth A] Interactions & Density Focus chain B [auth A]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.18 Å
R-Value Free: 0.212 (Depositor), 0.250 (DCC)
R-Value Work: 0.187 (Depositor), 0.230 (DCC)
R-Value Observed: 0.189 (Depositor)

Space Group: C 1 2 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 81.859	α = 90
b = 27.516	β = 99.81
c = 56.423	γ = 90

Software Package:

Software Name	Purpose
REFMAC	refinement
Aimless	data scaling
PDB_EXTRACT	data extraction
XDS	data reduction
REFMAC	phasing

Structure Validation

View Full Validation Report

Ligand Structure Quality Assessment

Entry History & Funding Information

Deposition Data

Released Date: 2023-03-29

Deposition Author(s):

Funding Organization	Location	Grant Number
Wellcome Trust	United Kingdom	--

Revision History (Full details and data files)

Version 1.0: 2023-03-29
Type: Initial release
Version 1.1: 2024-05-22
Changes: Data collection
Version 1.2: 2026-01-21
Changes: Database references, Structure summary
