7FH7 | pdb_00007fh7

Friedel-Crafts alkylation enzyme CylK mutant Y37F

PDB DOI: https://doi.org/10.2210/pdb7FH7/pdb

Classification: BIOSYNTHETIC PROTEIN
Organism(s): Cylindrospermum licheniforme UTEX B 2014
Expression System: Escherichia coli
Mutation(s): Yes

Deposited: 2021-07-29 Released: 2022-02-16
Deposition Author(s): Wang, H.Q., Wei, Z., Xiang, Z.

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.42 Å
R-Value Free:
0.179 (Depositor), 0.179 (DCC)
R-Value Work:
0.135 (Depositor), 0.135 (DCC)
R-Value Observed:
0.137 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Ligand Structure Quality Assessment

This is version 1.1 of the entry. See complete history.

Literature

Structural Basis for the Friedel-Crafts Alkylation in Cylindrocyclophane Biosynthesis

Wang, H.Q., Mou, S.B., Xiao, W., Zhou, H., Hou, X.D., Wang, S.J., Wang, Q., Gao, J., Wei, Z., Liu, L., Xiang, Z.

(2022) Acs Catal 12: 2108-2117

DOI: https://doi.org/10.1021/acscatal.1c04816

Macromolecule Content

Total Structure Weight: 75.03 kDa
Atom Count: 5,996
Modeled Residue Count: 653
Deposited Residue Count: 676
Unique protein chains: 1

Macromolecules

Find similar proteins by:

| 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
CylK	A	676	Cylindrospermum licheniforme UTEX B 2014	Mutation(s): 1 Gene Names: cylK
UniProt
Find proteins for A0A1Y0K711 (Cylindrospermum licheniforme UTEX B 2014) Explore A0A1Y0K711 Go to UniProtKB: A0A1Y0K711
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	A0A1Y0K711
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 4 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
4ON (Subject of Investigation/LOI) Query on 4ON Download:Ideal Coordinates CCD File SDF format, chain C [auth A] SDF format, chain B [auth A] MOL2 format, chain C [auth A] MOL2 format, chain B [auth A] mmCIF format, chain C [auth A] mmCIF format, chain B [auth A]	B [auth A], C [auth A]	5-[(2S,7R)-7-fluoranyl-2-methyl-undecyl]benzene-1,3-diol C₁₈ H₂₉ F O₂ OSAGUKIZXFZGQI-GOEBONIOSA-N		Interactions Focus chain B [auth A] Focus chain C [auth A] Interactions & Density Focus chain B [auth A] Focus chain C [auth A]
CA Query on CA Download:Ideal Coordinates CCD File SDF format, chain S [auth A] SDF format, chain R [auth A] SDF format, chain Q [auth A] SDF format, chain P [auth A] SDF format, chain O [auth A] SDF format, chain N [auth A] SDF format, chain M [auth A] SDF format, chain L [auth A] SDF format, chain K [auth A] SDF format, chain J [auth A] SDF format, chain I [auth A] SDF format, chain H [auth A] MOL2 format, chain S [auth A] MOL2 format, chain R [auth A] MOL2 format, chain Q [auth A] MOL2 format, chain P [auth A] MOL2 format, chain O [auth A] MOL2 format, chain N [auth A] MOL2 format, chain M [auth A] MOL2 format, chain L [auth A] MOL2 format, chain K [auth A] MOL2 format, chain J [auth A] MOL2 format, chain I [auth A] MOL2 format, chain H [auth A] mmCIF format, chain S [auth A] mmCIF format, chain R [auth A] mmCIF format, chain Q [auth A] mmCIF format, chain P [auth A] mmCIF format, chain O [auth A] mmCIF format, chain N [auth A] mmCIF format, chain M [auth A] mmCIF format, chain L [auth A] mmCIF format, chain K [auth A] mmCIF format, chain J [auth A] mmCIF format, chain I [auth A] mmCIF format, chain H [auth A]	H [auth A] I [auth A] J [auth A] K [auth A] L [auth A] H [auth A], I [auth A], J [auth A], K [auth A], L [auth A], M [auth A], N [auth A], O [auth A], P [auth A], Q [auth A], R [auth A], S [auth A]	CALCIUM ION Ca BHPQYMZQTOCNFJ-UHFFFAOYSA-N		Interactions Focus chain H [auth A] Focus chain I [auth A] Focus chain J [auth A] Focus chain K [auth A] Focus chain L [auth A] Focus chain M [auth A] Focus chain N [auth A] Focus chain O [auth A] Focus chain P [auth A] Focus chain Q [auth A] Focus chain R [auth A] Focus chain S [auth A] Interactions & Density Focus chain H [auth A] Focus chain I [auth A] Focus chain J [auth A] Focus chain K [auth A] Focus chain L [auth A] Focus chain M [auth A] Focus chain N [auth A] Focus chain O [auth A] Focus chain P [auth A] Focus chain Q [auth A] Focus chain R [auth A] Focus chain S [auth A]
CL Query on CL Download:Ideal Coordinates CCD File SDF format, chain Z [auth A] SDF format, chain Y [auth A] SDF format, chain X [auth A] SDF format, chain W [auth A] SDF format, chain V [auth A] SDF format, chain U [auth A] SDF format, chain T [auth A] MOL2 format, chain Z [auth A] MOL2 format, chain Y [auth A] MOL2 format, chain X [auth A] MOL2 format, chain W [auth A] MOL2 format, chain V [auth A] MOL2 format, chain U [auth A] MOL2 format, chain T [auth A] mmCIF format, chain Z [auth A] mmCIF format, chain Y [auth A] mmCIF format, chain X [auth A] mmCIF format, chain W [auth A] mmCIF format, chain V [auth A] mmCIF format, chain U [auth A] mmCIF format, chain T [auth A]	T [auth A] U [auth A] V [auth A] W [auth A] X [auth A] T [auth A], U [auth A], V [auth A], W [auth A], X [auth A], Y [auth A], Z [auth A]	CHLORIDE ION Cl VEXZGXHMUGYJMC-UHFFFAOYSA-M		Interactions Focus chain T [auth A] Focus chain U [auth A] Focus chain V [auth A] Focus chain W [auth A] Focus chain X [auth A] Focus chain Y [auth A] Focus chain Z [auth A] Interactions & Density Focus chain T [auth A] Focus chain U [auth A] Focus chain V [auth A] Focus chain W [auth A] Focus chain X [auth A] Focus chain Y [auth A] Focus chain Z [auth A]
MG Query on MG Download:Ideal Coordinates CCD File SDF format, chain G [auth A] SDF format, chain F [auth A] SDF format, chain E [auth A] SDF format, chain D [auth A] MOL2 format, chain G [auth A] MOL2 format, chain F [auth A] MOL2 format, chain E [auth A] MOL2 format, chain D [auth A] mmCIF format, chain G [auth A] mmCIF format, chain F [auth A] mmCIF format, chain E [auth A] mmCIF format, chain D [auth A]	D [auth A], E [auth A], F [auth A], G [auth A]	MAGNESIUM ION Mg JLVVSXFLKOJNIY-UHFFFAOYSA-N		Interactions Focus chain D [auth A] Focus chain E [auth A] Focus chain F [auth A] Focus chain G [auth A] Interactions & Density Focus chain D [auth A] Focus chain E [auth A] Focus chain F [auth A] Focus chain G [auth A]
