7F11

Crystal structure of NsrQ M128I in complex with substrate analogue 7


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.60 Å
  • R-Value Free: 0.229
  • R-Value Work: 0.204
  • R-Value Observed: 0.206

wwPDB Validation   3D Report Full Report


Ligand Structure Quality Assessment


This is version 1.1 of the entry. See complete history


Literature

Structural Basis for Isomerization Reactions in Fungal Tetrahydroxanthone Biosynthesis and Diversification.

Yang, J.Mori, T.Wei, X.Matsuda, Y.Abe, I.

(2021) Angew Chem Int Ed Engl 60: 19458-19465

  • DOI: https://doi.org/10.1002/anie.202107884
  • Primary Citation of Related Structures:
    7F0O, 7F0Y, 7F0Z, 7F10, 7F11, 7F13, 7F14

  • PubMed Abstract:

    The novel isomerase NsrQ, from Aspergillus novofumigatus, is a key enzyme in the biosynthesis of fungal tetrahydroxanthones and is responsible for dearomatizing cyclization to provide a tetrahydroxanthone scaffold. NsrQ catalyzes a two-step isomerization reaction, involving the isomerization of allylic alcohol and subsequent inversion of configuration at the methyl group. We report on the biochemical and structural characterizations of NsrQ, and its homologue Dcr3, from Diaporthe longicolla. The crystal structures of NsrQ and Dcr3 revealed their similar overall structures, with a cone-shaped α+β barrel fold, to those of the nuclear transport factor 2-like superfamily enzymes. Furthermore, the structures of Dcr3 and NsrQ variants complexed with substrate analogues and the site-directed mutagenesis studies identified the catalytic residues and the important hydrophobic residues in shaping the active site pocket for substrate binding. These enzymes thus utilize Glu and His residues as acid-base catalysts. Based on these observations, we proposed a detailed reaction mechanism for NsrQ-catalyzed isomerization reactions.


  • Organizational Affiliation

    Graduate School of Pharmaceutical Sciences, The University of Tokyo, 7-3-1 Hongo, Bunkyo-ku, Tokyo, 113-0033, Japan.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
NsrQ
A, B
171Aspergillus novofumigatusMutation(s): 1
UniProt
Find proteins for A0A2I1C3W8 (Aspergillus novofumigatus (strain IBT 16806))
Explore A0A2I1C3W8
Go to UniProtKB:  A0A2I1C3W8
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA0A2I1C3W8
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 1 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
0ER (Subject of Investigation/LOI)
Query on 0ER

Download Ideal Coordinates CCD File
C [auth B]methyl 2-[2,6-bis(oxidanyl)phenyl]carbonyl-5-methyl-3,6-bis(oxidanyl)benzoate
C16 H14 O7
RHLYWFLKBXEUTQ-UHFFFAOYSA-N
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.60 Å
  • R-Value Free: 0.229
  • R-Value Work: 0.204
  • R-Value Observed: 0.206
  • Space Group: P 21 21 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 58.464α = 90
b = 64.119β = 90
c = 87.798γ = 90
Software Package:
Software NamePurpose
PHENIXrefinement
XDSdata reduction
Aimlessdata scaling
PHASERphasing

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2022-04-20
    Type: Initial release
  • Version 1.1: 2023-11-29
    Changes: Data collection, Refinement description
