7EGY | pdb_00007egy

Recombinant head-to-tail dimeric E2 protein

PDB DOI: https://doi.org/10.2210/pdb7EGY/pdb

Classification: VIRAL PROTEIN
Organism(s): Hog cholera virus strain 'Chinese vaccine, Wuhan
Expression System: Oryza sativa
Mutation(s): No

Deposited: 2021-03-27 Released: 2022-03-30
Deposition Author(s): Ru, Q.X.

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 4.20 Å
R-Value Free:
0.444 (Depositor), 0.420 (DCC)
R-Value Work:
0.381 (Depositor), 0.400 (DCC)
R-Value Observed:
0.388 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

This is version 1.2 of the entry. See complete history.

Literature

Recombinant head-to-tail dimeric E2 protein

Ru, Q.X.

To be published.

Macromolecule Content

Total Structure Weight: 76.38 kDa
Atom Count: 3,402
Modeled Residue Count: 476
Deposited Residue Count: 684
Unique protein chains: 1

Macromolecules

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
E2 protein	A, B	342	Hog cholera virus strain 'Chinese vaccine, Wuhan	Mutation(s): 0
UniProt
Find proteins for Q991S8 (Classical swine fever virus) Explore Q991S8 Go to UniProtKB: Q991S8
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	Q991S8
Sequence Annotations Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 4.20 Å
R-Value Free: 0.444 (Depositor), 0.420 (DCC)
R-Value Work: 0.381 (Depositor), 0.400 (DCC)
R-Value Observed: 0.388 (Depositor)

Space Group: P 6₃

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 177.17	α = 90
b = 177.17	β = 90
c = 59.171	γ = 120

Software Package:

Software Name	Purpose
HKL-2000	data scaling
PHENIX	refinement
PDB_EXTRACT	data extraction
xia2	data reduction
PHENIX	phasing

Structure Validation

View Full Validation Report

Entry History

Deposition Data

Released Date: 2022-03-30

Deposition Author(s):

Revision History (Full details and data files)

Version 1.0: 2022-03-30
Type: Initial release
Version 1.1: 2023-11-29
Changes: Data collection, Refinement description
Version 1.2: 2024-11-20
Changes: Structure summary
