7DSZ | pdb_00007dsz

Crystal structure of Amuc_1102 from Akkermansia muciniphila

PDB DOI: https://doi.org/10.2210/pdb7DSZ/pdb

Classification: MOTOR PROTEIN
Organism(s): Akkermansia muciniphila
Expression System: Escherichia coli BL21(DE3)
Mutation(s): No

Deposited: 2021-01-04 Released: 2021-02-24
Deposition Author(s): Xiang, R., Wang, J., Wang, Y., Zhang, M., Wang, M.
Funding Organization(s): Other government

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.75 Å
R-Value Free:
0.200 (Depositor), 0.201 (DCC)
R-Value Work:
0.172 (Depositor), 0.173 (DCC)
R-Value Observed:
0.173 (Depositor)

wwPDB Validation 3D Report Full Report

Validation slider image for 7DSZ

This is version 1.1 of the entry. See complete history.

Literature

Amuc_1102 fromAkkermansia muciniphilaadopts animmunoglobulin-like fold related to archaeal type IV pilus

Xiang, R., Wang, J., Xu, W., Zhang, M., Wang, M.

(2021) Biochem Biophys Res Commun 547: 59-64

DOI: https://doi.org/10.1016/j.bbrc.2021.02.022

Macromolecule Content

Total Structure Weight: 80.34 kDa
Atom Count: 5,399
Modeled Residue Count: 568
Deposited Residue Count: 696
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Amuc_1102	A, B, C	232	Akkermansia muciniphila	Mutation(s): 0 Gene Names: Amuc_1102
UniProt
Find proteins for B2UR43 (Akkermansia muciniphila (strain ATCC BAA-835 / DSM 22959 / JCM 33894 / BCRC 81048 / CCUG 64013 / CIP 107961 / Muc)) Explore B2UR43 Go to UniProtKB: B2UR43
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	B2UR43
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
CL Query on CL Download:Ideal Coordinates CCD File SDF format, chain H [auth C] SDF format, chain G [auth C] SDF format, chain F [auth B] SDF format, chain E [auth B] SDF format, chain D [auth A] MOL2 format, chain H [auth C] MOL2 format, chain G [auth C] MOL2 format, chain F [auth B] MOL2 format, chain E [auth B] MOL2 format, chain D [auth A] mmCIF format, chain H [auth C] mmCIF format, chain G [auth C] mmCIF format, chain F [auth B] mmCIF format, chain E [auth B] mmCIF format, chain D [auth A]	D [auth A], E [auth B], F [auth B], G [auth C], H [auth C]	CHLORIDE ION Cl VEXZGXHMUGYJMC-UHFFFAOYSA-M		Interactions Focus chain D [auth A] Focus chain E [auth B] Focus chain F [auth B] Focus chain G [auth C] Focus chain H [auth C] Interactions & Density Focus chain D [auth A] Focus chain E [auth B] Focus chain F [auth B] Focus chain G [auth C] Focus chain H [auth C]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.75 Å
R-Value Free: 0.200 (Depositor), 0.201 (DCC)
R-Value Work: 0.172 (Depositor), 0.173 (DCC)
R-Value Observed: 0.173 (Depositor)

Space Group: P 2₁ 2₁ 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 83.469	α = 90
b = 83.941	β = 90
c = 107.252	γ = 90

Software Package:

Software Name	Purpose
HKL-2000	data reduction
SCALEPACK	data scaling
PHENIX	refinement
PDB_EXTRACT	data extraction
SHELXDE	phasing

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Released Date: 2021-02-24

Deposition Author(s):

Funding Organization	Location	Grant Number
Other government	China	KJ2019ZD02

Revision History (Full details and data files)

Version 1.0: 2021-02-24
Type: Initial release
Version 1.1: 2024-03-27
Changes: Data collection, Database references
