7D75 | pdb_00007d75

X-ray structure of a domain-swapped dimer of Monellin with YEDKG loop-1 mutant

PDB DOI: https://doi.org/10.2210/pdb7D75/pdb

Classification: PLANT PROTEIN
Organism(s): Dioscoreophyllum cumminsii
Expression System: Escherichia coli BL21
Mutation(s): No

Deposited: 2020-10-03 Released: 2021-10-06
Deposition Author(s): Manjula, R., Ramaswamy, S., Gosavi, S.

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.50 Å
R-Value Free:
0.304 (Depositor), 0.296 (DCC)
R-Value Work:
0.262 (Depositor), 0.259 (DCC)
R-Value Observed:
0.264 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 7D75

This is version 1.2 of the entry. See complete history.

Literature

Domain swapped structure of Monellin Loop1-mutant

Manjula, R., Gosavi, S., Subramanian, R.

To be published.

Macromolecule Content

Total Structure Weight: 44.73 kDa
Atom Count: 3,183
Modeled Residue Count: 360
Deposited Residue Count: 364
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Single chain Monellin	A, B, C, D	91	Dioscoreophyllum cumminsii	Mutation(s): 0
UniProt
Find proteins for P02881 (Dioscoreophyllum cumminsii) Explore P02881 Go to UniProtKB: P02881
Find proteins for P02882 (Dioscoreophyllum cumminsii) Explore P02882 Go to UniProtKB: P02882
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Groups	P02881 P02882
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 3 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
MES Query on MES Download:Ideal Coordinates CCD File SDF format, chain E [auth A] SDF format, chain FA [auth D] MOL2 format, chain E [auth A] MOL2 format, chain FA [auth D] mmCIF format, chain E [auth A] mmCIF format, chain FA [auth D]	E [auth A], FA [auth D]	2-(N-MORPHOLINO)-ETHANESULFONIC ACID C₆ H₁₃ N O₄ S SXGZJKUKBWWHRA-UHFFFAOYSA-N		Interactions Focus chain E [auth A] Focus chain FA [auth D] Interactions & Density Focus chain E [auth A] Focus chain FA [auth D]
SO4 Query on SO4 Download:Ideal Coordinates CCD File SDF format, chain F [auth A] SDF format, chain G [auth A] SDF format, chain GA [auth D] SDF format, chain H [auth A] SDF format, chain I [auth A] SDF format, chain J [auth A] SDF format, chain K [auth A] SDF format, chain Q [auth B] SDF format, chain R [auth B] SDF format, chain S [auth B] SDF format, chain T [auth B] SDF format, chain Z [auth C] MOL2 format, chain F [auth A] MOL2 format, chain G [auth A] MOL2 format, chain GA [auth D] MOL2 format, chain H [auth A] MOL2 format, chain I [auth A] MOL2 format, chain J [auth A] MOL2 format, chain K [auth A] MOL2 format, chain Q [auth B] MOL2 format, chain R [auth B] MOL2 format, chain S [auth B] MOL2 format, chain T [auth B] MOL2 format, chain Z [auth C] mmCIF format, chain F [auth A] mmCIF format, chain G [auth A] mmCIF format, chain GA [auth D] mmCIF format, chain H [auth A] mmCIF format, chain I [auth A] mmCIF format, chain J [auth A] mmCIF format, chain K [auth A] mmCIF format, chain Q [auth B] mmCIF format, chain R [auth B] mmCIF format, chain S [auth B] mmCIF format, chain T [auth B] mmCIF format, chain Z [auth C]	F [auth A] G [auth A] GA [auth D] H [auth A] I [auth A] F [auth A], G [auth A], GA [auth D], H [auth A], I [auth A], J [auth A], K [auth A], Q [auth B], R [auth B], S [auth B], T [auth B], Z [auth C]	SULFATE ION O₄ S QAOWNCQODCNURD-UHFFFAOYSA-L		Interactions Focus chain F [auth A] Focus chain G [auth A] Focus chain GA [auth D] Focus chain H [auth A] Focus chain I [auth A] Focus chain J [auth A] Focus chain K [auth A] Focus chain Q [auth B] Focus chain R [auth B] Focus chain S [auth B] Focus chain T [auth B] Focus chain Z [auth C] Interactions & Density Focus chain F [auth A] Focus chain G [auth A] Focus chain GA [auth D] Focus chain H [auth A] Focus chain I [auth A] Focus chain J [auth A] Focus chain K [auth A] Focus chain Q [auth B] Focus chain R [auth B] Focus chain S [auth B] Focus chain T [auth B] Focus chain Z [auth C]
MG Query on MG Download:Ideal Coordinates CCD File SDF format, chain AA [auth C] SDF format, chain BA [auth C] SDF format, chain CA [auth C] SDF format, chain DA [auth C] SDF format, chain EA [auth C] SDF format, chain HA [auth D] SDF format, chain IA [auth D] SDF format, chain JA [auth D] SDF format, chain L [auth A] SDF format, chain M [auth A] SDF format, chain N [auth A] SDF format, chain O [auth A] SDF format, chain P [auth A] SDF format, chain U [auth B] SDF format, chain V [auth B] SDF format, chain W [auth B] SDF format, chain X [auth B] SDF format, chain Y [auth B] MOL2 format, chain AA [auth C] MOL2 format, chain BA [auth C] MOL2 format, chain CA [auth C] MOL2 format, chain DA [auth C] MOL2 format, chain EA [auth C] MOL2 format, chain HA [auth D] MOL2 format, chain IA [auth D] MOL2 format, chain JA [auth D] MOL2 format, chain L [auth A] MOL2 format, chain M [auth A] MOL2 format, chain N [auth A] MOL2 format, chain O [auth A] MOL2 format, chain P [auth A] MOL2 format, chain U [auth B] MOL2 format, chain V [auth B] MOL2 format, chain W [auth B] MOL2 format, chain X [auth B] MOL2 format, chain Y [auth B] mmCIF format, chain AA [auth C] mmCIF format, chain BA [auth C] mmCIF format, chain CA [auth C] mmCIF format, chain DA [auth C] mmCIF format, chain EA [auth C] mmCIF format, chain HA [auth D] mmCIF format, chain IA [auth D] mmCIF format, chain JA [auth D] mmCIF format, chain L [auth A] mmCIF format, chain M [auth A] mmCIF format, chain N [auth A] mmCIF format, chain O [auth A] mmCIF format, chain P [auth A] mmCIF format, chain U [auth B] mmCIF format, chain V [auth B] mmCIF format, chain W [auth B] mmCIF format, chain X [auth B] mmCIF format, chain Y [auth B]	AA [auth C] BA [auth C] CA [auth C] DA [auth C] EA [auth C] AA [auth C], BA [auth C], CA [auth C], DA [auth C], EA [auth C], HA [auth D], IA [auth D], JA [auth D], L [auth A], M [auth A], N [auth A], O [auth A], P [auth A], U [auth B], V [auth B], W [auth B], X [auth B], Y [auth B]	MAGNESIUM ION Mg JLVVSXFLKOJNIY-UHFFFAOYSA-N		Interactions Focus chain AA [auth C] Focus chain BA [auth C] Focus chain CA [auth C] Focus chain DA [auth C] Focus chain EA [auth C] Focus chain HA [auth D] Focus chain IA [auth D] Focus chain JA [auth D] Focus chain L [auth A] Focus chain M [auth A] Focus chain N [auth A] Focus chain O [auth A] Focus chain P [auth A] Focus chain U [auth B] Focus chain V [auth B] Focus chain W [auth B] Focus chain X [auth B] Focus chain Y [auth B] Interactions & Density Focus chain AA [auth C] Focus chain BA [auth C] Focus chain CA [auth C] Focus chain DA [auth C] Focus chain EA [auth C] Focus chain HA [auth D] Focus chain IA [auth D] Focus chain JA [auth D] Focus chain L [auth A] Focus chain M [auth A] Focus chain N [auth A] Focus chain O [auth A] Focus chain P [auth A] Focus chain U [auth B] Focus chain V [auth B] Focus chain W [auth B] Focus chain X [auth B] Focus chain Y [auth B]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.50 Å
R-Value Free: 0.304 (Depositor), 0.296 (DCC)
R-Value Work: 0.262 (Depositor), 0.259 (DCC)
R-Value Observed: 0.264 (Depositor)

Space Group: P 1 2 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 45.794	α = 90
b = 55.783	β = 93.63
c = 105.831	γ = 90

Software Package:

Software Name	Purpose
PHENIX	refinement
Aimless	data scaling
PDB_EXTRACT	data extraction
MOSFLM	data reduction
MOLREP	phasing

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

Deposition Data

Released Date: 2021-10-06

Deposition Author(s):

Revision History (Full details and data files)

Version 1.0: 2021-10-06
Type: Initial release
Version 1.1: 2021-11-03
Changes: Structure summary
Version 1.2: 2023-11-29
Changes: Data collection, Refinement description
