7D62 | pdb_00007d62

pGpG-specific phosphodiesterase - PggH from Vibrio cholrae

PDB DOI: https://doi.org/10.2210/pdb7D62/pdb

Classification: SIGNALING PROTEIN
Organism(s): Vibrio cholerae O1 biovar El Tor str. N16961
Expression System: Escherichia coli BL21(DE3)
Mutation(s): No

Deposited: 2020-09-28 Released: 2020-10-28
Deposition Author(s): Ha, N.-C., Jang, Y.

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.90 Å
R-Value Free:
0.239 (Depositor), 0.244 (DCC)
R-Value Work:
0.196 (Depositor)
R-Value Observed:
0.198 (Depositor)

wwPDB Validation 3D Report Full Report

Validation slider image for 7D62

Ligand Structure Quality Assessment

This is version 1.1 of the entry. See complete history.

Literature

A pGpG-specific phosphodiesterase

Lee, J.-W., Heo, K., Jang, Y., Ha, N.-C., Seok, Y.-J.

To be published.

Macromolecule Content

Total Structure Weight: 74.32 kDa
Atom Count: 4,796
Modeled Residue Count: 587
Deposited Residue Count: 648
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
PggH	A, B	324	Vibrio cholerae O1 biovar El Tor str. N16961	Mutation(s): 0 Gene Names: VC_A0593
UniProt
Find proteins for Q9KLZ6 (Vibrio cholerae serotype O1 (strain ATCC 39315 / El Tor Inaba N16961)) Explore Q9KLZ6 Go to UniProtKB: Q9KLZ6
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	Q9KLZ6
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
SO4 (Subject of Investigation/LOI) Query on SO4 Download:Ideal Coordinates CCD File SDF format, chain E [auth A] SDF format, chain D [auth A] MOL2 format, chain E [auth A] MOL2 format, chain D [auth A] mmCIF format, chain E [auth A] mmCIF format, chain D [auth A]	D [auth A], E [auth A]	SULFATE ION O₄ S QAOWNCQODCNURD-UHFFFAOYSA-L		Interactions Focus chain D [auth A] Focus chain E [auth A] Interactions & Density Focus chain D [auth A] Focus chain E [auth A]
MN (Subject of Investigation/LOI) Query on MN Download:Ideal Coordinates CCD File SDF format, chain F [auth B] SDF format, chain C [auth A] MOL2 format, chain F [auth B] MOL2 format, chain C [auth A] mmCIF format, chain F [auth B] mmCIF format, chain C [auth A]	C [auth A], F [auth B]	MANGANESE (II) ION Mn WAEMQWOKJMHJLA-UHFFFAOYSA-N		Interactions Focus chain C [auth A] Focus chain F [auth B] Interactions & Density Focus chain C [auth A] Focus chain F [auth B]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.90 Å
R-Value Free: 0.239 (Depositor), 0.244 (DCC)
R-Value Work: 0.196 (Depositor)
R-Value Observed: 0.198 (Depositor)

Space Group: P 2₁ 2₁ 2

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 68.367	α = 90
b = 148.83	β = 90
c = 58.845	γ = 90

Software Package:

Software Name	Purpose
PHENIX	refinement
XDS	data reduction
HKL-2000	data scaling
PHENIX	phasing

Structure Validation

View Full Validation Report

Ligand Structure Quality Assessment

View more in-depth experimental data

Entry History

Deposition Data

Released Date: 2020-10-28

Deposition Author(s):

Revision History (Full details and data files)

Version 1.0: 2020-10-28
Type: Initial release
Version 1.1: 2024-03-27
Changes: Data collection, Database references
