7D2U

Crystal structure of Rsu1/PINCH1_LIM45C complex


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 3.15 Å
  • R-Value Free: 0.216
  • R-Value Work: 0.192
  • R-Value Observed: 0.193

wwPDB Validation   3D Report Full Report


This is version 1.1 of the entry. See complete history


Literature

Complex structures of Rsu1 and PINCH1 reveal a regulatory mechanism of the ILK/PINCH/Parvin complex for F-actin dynamics.

Yang, H.Lin, L.Sun, K.Zhang, T.Chen, W.Li, L.Xie, Y.Wu, C.Wei, Z.Yu, C.

(2021) Elife 10

  • DOI: https://doi.org/10.7554/eLife.64395
  • Primary Citation of Related Structures:
    7D2S, 7D2T, 7D2U

  • PubMed Abstract:

    Communications between actin filaments and integrin-mediated focal adhesion (FA) are crucial for cell adhesion and migration. As a core platform to organize FA proteins, the tripartite ILK/PINCH/Parvin (IPP) complex interacts with actin filaments to regulate the cytoskeleton-FA crosstalk. Rsu1, a Ras suppressor, is enriched in FA through PINCH1 and plays important roles in regulating F-actin structures. Here, we solved crystal structures of the Rsu1/PINCH1 complex, in which the leucine-rich-repeats of Rsu1 form a solenoid structure to tightly associate with the C-terminal region of PINCH1. Further structural analysis uncovered that the interaction between Rsu1 and PINCH1 blocks the IPP-mediated F-actin bundling by disrupting the binding of PINCH1 to actin. Consistently, overexpressing Rsu1 in HeLa cells impairs stress fiber formation and cell spreading. Together, our findings demonstrated that Rsu1 is critical for tuning the communication between F-actin and FA by interacting with the IPP complex and negatively modulating the F-actin bundling.


  • Organizational Affiliation

    Department of Biology, Southern University of Science and Technology, Shenzhen, China.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Ras suppressor protein 1282Homo sapiensMutation(s): 0
Gene Names: RSU1RSP1
UniProt & NIH Common Fund Data Resources
Find proteins for Q15404 (Homo sapiens)
Explore Q15404
Go to UniProtKB:  Q15404
PHAROS:  Q15404
GTEx:  ENSG00000148484
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ15404
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 2
MoleculeChains Sequence LengthOrganismDetailsImage
LIM and senescent cell antigen-like-containing domain protein 1142Homo sapiensMutation(s): 0
Gene Names: LIMS1PINCHPINCH1
UniProt & NIH Common Fund Data Resources
Find proteins for P48059 (Homo sapiens)
Explore P48059
Go to UniProtKB:  P48059
PHAROS:  P48059
GTEx:  ENSG00000169756
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP48059
Sequence Annotations
Expand
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 3.15 Å
  • R-Value Free: 0.216
  • R-Value Work: 0.192
  • R-Value Observed: 0.193
  • Space Group: I 2 2 2
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 51.354α = 90
b = 144.397β = 90
c = 185.043γ = 90
Software Package:
Software NamePurpose
SCALEPACKdata scaling
PHENIXrefinement
PDB_EXTRACTdata extraction
HKL-2000data reduction
PHASERphasing

Structure Validation

View Full Validation Report



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
National Natural Science Foundation of China (NSFC)China31870757
National Natural Science Foundation of China (NSFC)China31971131
National Natural Science Foundation of China (NSFC)China31770791

Revision History  (Full details and data files)

  • Version 1.0: 2021-02-24
    Type: Initial release
  • Version 1.1: 2023-11-29
    Changes: Data collection, Database references, Refinement description
