7CWX | pdb_00007cwx

Crystal structure of a tyrosine decarboxylase from Enterococcus faecalis

• PDB DOI: https://doi.org/10.2210/pdb7CWX/pdb

• Classification: LYASE
• Organism(s): Enterococcus faecalis
• Expression System: Escherichia coli BL21(DE3)
• Mutation(s): No


• Deposited: 2020-09-01 Released: 2021-09-01
• Deposition Author(s): Yu, X., Gong, M., Huang, J., Liu, W., Chen, C., Guo, R.

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 2.15 Å
• R-Value Free:
  0.230 (Depositor), 0.230 (DCC)
• R-Value Work:
  0.192 (Depositor), 0.200 (DCC)
• R-Value Observed:
  0.194 (Depositor)

Starting Model: experimental

Literature

Crystal structure of a tyrosine decarboxylase from Enterococcus faecalis

Yu, X., Gong, M., Huang, J., Liu, W., Chen, C., Guo, R.

To be published.

Biological Assembly 1

Global Symmetry: Cyclic - C2  (Explore in 3D)
Global Stoichiometry: Homo 2-mer - A2

Biological assembly 1 assigned by authors and generated by PISA (software)

Biological Assembly Evidence: gel filtration

Biological Assembly 2

Global Symmetry: Cyclic - C2  (Explore in 3D)
Global Stoichiometry: Homo 2-mer - A2

Biological assembly 2 assigned by authors and generated by PISA (software)

Macromolecule Content

• Total Structure Weight: 210.71 kDa
• Atom Count: 14,808
• Modeled Residue Count: 1,784
• Deposited Residue Count: 1,860
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Decarboxylase	A, B, C	620	Enterococcus faecalis	Mutation(s): 0  Gene Names: tyrDC, ddc, ELS84_1624, KUB3007_C03520, NCTC8729_00604 EC: 4.1.1.86 (PDB Primary Data), 4.1.1.25 (UniProt), 4.1.1 (UniProt)
UniProt
Find proteins for Q838D6 (Enterococcus faecalis (strain ATCC 700802 / V583)) Explore Q838D6  Go to UniProtKB:  Q838D6

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
PEG	D [auth A], E [auth B]	DI(HYDROXYETHYL)ETHER C4 H10 O3 MTHSVFCYNBDYFN-UHFFFAOYSA-N
GOL	F [auth B]	GLYCEROL C3 H8 O3 PEDCQBHIVMGVHV-UHFFFAOYSA-N

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 2.15 Å
• R-Value Free:  0.230 (Depositor), 0.230 (DCC)
• R-Value Work:  0.192 (Depositor), 0.200 (DCC)
• R-Value Observed: 0.194 (Depositor)

Space Group: P 6₁ 2 2

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 132.338	α = 90
b = 132.338	β = 90
c = 391.483	γ = 120

Software Package:

Software Name	Purpose
PHENIX	refinement
HKL-2000	data scaling
PDB_EXTRACT	data extraction
HKL-2000	data reduction
PHASER	phasing

Structure Validation

Entry History

Deposition Data

• Released Date: 2021-09-01
Deposition Author(s): Yu, X., Gong, M., Huang, J., Liu, W., Chen, C., Guo, R.

Revision History

• Version 1.0: 2021-09-01
  Type: Initial release

• Version 1.1: 2023-11-29
  Changes: Data collection, Refinement description
