7BNL | pdb_00007bnl

Notum ARUK3003710

PDB DOI: https://doi.org/10.2210/pdb7BNL/pdb

Classification: HYDROLASE
Organism(s): Homo sapiens
Expression System: Homo sapiens
Mutation(s): Yes

Deposited: 2021-01-22 Released: 2022-03-02
Deposition Author(s): Zhao, Y., Jones, E.Y., Fish, P.V., Svensson, F., Steadman, D.
Funding Organization(s): Cancer Research UK

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.23 Å
R-Value Free:
0.198 (Depositor), 0.198 (DCC)
R-Value Work:
0.178 (Depositor), 0.179 (DCC)
R-Value Observed:
0.179 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Ligand Structure Quality Assessment

This is version 1.2 of the entry. See complete history.

Literature

Notum Inhibitor ARUK3003710

Zhao, Y., Jones, E.Y.

To be published.

Macromolecule Content

Total Structure Weight: 45.04 kDa
Atom Count: 3,001
Modeled Residue Count: 350
Deposited Residue Count: 383
Unique protein chains: 1

Macromolecules

Find similar proteins by:

| 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Palmitoleoyl-protein carboxylesterase NOTUM	A	383	Homo sapiens	Mutation(s): 1 Gene Names: NOTUM, OK/SW-CL.30 EC: 3.1.1.98
UniProt & NIH Common Fund Data Resources
Find proteins for Q6P988 (Homo sapiens) Explore Q6P988 Go to UniProtKB: Q6P988
PHAROS: Q6P988 GTEx: ENSG00000185269
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	Q6P988
Glycosylation
Glycosylation Sites: 1	Glycosylation Focus chain A	Go to GlyGen: Q6P988-1
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 5 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
U5T (Subject of Investigation/LOI) Query on U5T Download:Ideal Coordinates CCD File SDF format, chain L [auth A] MOL2 format, chain L [auth A] mmCIF format, chain L [auth A]	L [auth A]	(4~{E})-2-(3,4-dimethylphenyl)-4-[(1-methylpyrazol-4-yl)methylidene]-1,3-oxazol-5-one C₁₆ H₁₅ N₃ O₂ BNKZAUBGRRNYQS-VGOFMYFVSA-N		Interactions Focus chain L [auth A] Interactions & Density Focus chain L [auth A]
NAG Query on NAG Download:Ideal Coordinates CCD File SDF format, chain B [auth A] MOL2 format, chain B [auth A] mmCIF format, chain B [auth A]	B [auth A]	2-acetamido-2-deoxy-beta-D-glucopyranose C₈ H₁₅ N O₆ OVRNDRQMDRJTHS-FMDGEEDCSA-N		Interactions Focus chain B [auth A] Interactions & Density Focus chain B [auth A]
SO4 Query on SO4 Download:Ideal Coordinates CCD File SDF format, chain N [auth A] SDF format, chain M [auth A] SDF format, chain G [auth A] SDF format, chain F [auth A] SDF format, chain E [auth A] SDF format, chain D [auth A] SDF format, chain C [auth A] MOL2 format, chain N [auth A] MOL2 format, chain M [auth A] MOL2 format, chain G [auth A] MOL2 format, chain F [auth A] MOL2 format, chain E [auth A] MOL2 format, chain D [auth A] MOL2 format, chain C [auth A] mmCIF format, chain N [auth A] mmCIF format, chain M [auth A] mmCIF format, chain G [auth A] mmCIF format, chain F [auth A] mmCIF format, chain E [auth A] mmCIF format, chain D [auth A] mmCIF format, chain C [auth A]	C [auth A] D [auth A] E [auth A] F [auth A] G [auth A] C [auth A], D [auth A], E [auth A], F [auth A], G [auth A], M [auth A], N [auth A]	SULFATE ION O₄ S QAOWNCQODCNURD-UHFFFAOYSA-L		Interactions Focus chain C [auth A] Focus chain D [auth A] Focus chain E [auth A] Focus chain F [auth A] Focus chain G [auth A] Focus chain M [auth A] Focus chain N [auth A] Interactions & Density Focus chain C [auth A] Focus chain D [auth A] Focus chain E [auth A] Focus chain F [auth A] Focus chain G [auth A] Focus chain M [auth A] Focus chain N [auth A]
DMS Query on DMS Download:Ideal Coordinates CCD File SDF format, chain J [auth A] SDF format, chain I [auth A] SDF format, chain H [auth A] MOL2 format, chain J [auth A] MOL2 format, chain I [auth A] MOL2 format, chain H [auth A] mmCIF format, chain J [auth A] mmCIF format, chain I [auth A] mmCIF format, chain H [auth A]	H [auth A], I [auth A], J [auth A]	DIMETHYL SULFOXIDE C₂ H₆ O S IAZDPXIOMUYVGZ-UHFFFAOYSA-N		Interactions Focus chain H [auth A] Focus chain I [auth A] Focus chain J [auth A] Interactions & Density Focus chain H [auth A] Focus chain I [auth A] Focus chain J [auth A]
EDO Query on EDO Download:Ideal Coordinates CCD File SDF format, chain K [auth A] MOL2 format, chain K [auth A] mmCIF format, chain K [auth A]	K [auth A]	1,2-ETHANEDIOL C₂ H₆ O₂ LYCAIKOWRPUZTN-UHFFFAOYSA-N		Interactions Focus chain K [auth A] Interactions & Density Focus chain K [auth A]
