7BKR

Endothiapepsin structure obtained at 298K and 40 mM DMSO from a dataset collected with JUNGFRAU detector

PDB DOI: https://doi.org/10.2210/pdb7BKR/pdb

Classification: HYDROLASE
Organism(s): Cryphonectria parasitica
Mutation(s): No

Deposited: 2021-01-17 Released: 2022-03-02
Deposition Author(s): Engilberge, S., Huang, C.-Y., Leonarski, F., Wojdyla, J.A., Marsh, M., Olieric, V., Wang, M.
Funding Organization(s): Swiss National Science Foundation

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.10 Å
R-Value Free: 0.195
R-Value Work: 0.147
R-Value Observed: 0.149

wwPDB Validation 3D Report Full Report

This is version 1.1 of the entry. See complete history.

Literature

Endothiapepsin structure obtained at 298K and 40 mM DMSO from a dataset collected with JUNGFRAU detector

Engilberge, S., Huang, C.-Y., Smith, K.M.L., Eris, D., Wojdyla, J.A., Olieric, V., Leonarski, F., Sharpe, M., Wang, M.

To be published.

Macromolecule Content

Total Structure Weight: 34.78 kDa
Atom Count: 2,644
Modelled Residue Count: 330
Deposited Residue Count: 330
Unique protein chains: 1

Macromolecules

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Endothiapepsin	A	330	Cryphonectria parasitica	Mutation(s): 0 EC: 3.4.23.22
UniProt
Find proteins for P11838 (Cryphonectria parasitica) Explore P11838 Go to UniProtKB: P11838
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	P11838
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 3 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
1PE Query on 1PE Download Ideal Coordinates CCD File SDF format, chain H [auth A] MOL2 format, chain H [auth A]	H [auth A]	PENTAETHYLENE GLYCOL C₁₀ H₂₂ O₆ JLFNLZLINWHATN-UHFFFAOYSA-N		Interactions Focus chain H [auth A] Interactions & Density Focus chain H [auth A]
PEG Query on PEG Download Ideal Coordinates CCD File SDF format, chain G [auth A] MOL2 format, chain G [auth A]	G [auth A]	DI(HYDROXYETHYL)ETHER C₄ H₁₀ O₃ MTHSVFCYNBDYFN-UHFFFAOYSA-N		Interactions Focus chain G [auth A] Interactions & Density Focus chain G [auth A]
DMS Query on DMS Download Ideal Coordinates CCD File SDF format, chain B [auth A] SDF format, chain C [auth A] SDF format, chain D [auth A] SDF format, chain E [auth A] SDF format, chain F [auth A] SDF format, chain I [auth A] SDF format, chain J [auth A] SDF format, chain K [auth A] MOL2 format, chain B [auth A] MOL2 format, chain C [auth A] MOL2 format, chain D [auth A] MOL2 format, chain E [auth A] MOL2 format, chain F [auth A] MOL2 format, chain I [auth A] MOL2 format, chain J [auth A] MOL2 format, chain K [auth A]	B [auth A] C [auth A] D [auth A] E [auth A] F [auth A] B [auth A], C [auth A], D [auth A], E [auth A], F [auth A], I [auth A], J [auth A], K [auth A]	DIMETHYL SULFOXIDE C₂ H₆ O S IAZDPXIOMUYVGZ-UHFFFAOYSA-N		Interactions Focus chain B [auth A] Focus chain C [auth A] Focus chain D [auth A] Focus chain E [auth A] Focus chain F [auth A] Focus chain I [auth A] Focus chain J [auth A] Focus chain K [auth A] Interactions & Density Focus chain B [auth A] Focus chain C [auth A] Focus chain D [auth A] Focus chain E [auth A] Focus chain F [auth A] Focus chain I [auth A] Focus chain J [auth A] Focus chain K [auth A]
