7B51 | pdb_00007b51

Crystal structure of human CRM1 covalently modified by 2-mercaptoethanol at Cys528

PDB DOI: https://doi.org/10.2210/pdb7B51/pdb

Classification: NUCLEAR PROTEIN
Organism(s): Homo sapiens
Expression System: Escherichia coli
Mutation(s): Yes

Deposited: 2020-12-03 Released: 2021-03-10
Deposition Author(s): Shaikhqasem, A., Ficner, R.
Funding Organization(s): German Research Foundation (DFG)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.58 Å
R-Value Free:
0.250 (Depositor), 0.249 (DCC)
R-Value Work:
0.214 (Depositor), 0.213 (DCC)
R-Value Observed:
0.216 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Ligand Structure Quality Assessment

This is version 1.2 of the entry. See complete history.

Literature

Crystal structure of human CRM1, covalently modified by 2-mercaptoethanol on Cys528, in complex with RanGTP.

Shaikhqasem, A., Schmitt, K., Valerius, O., Ficner, R.

(2021) Acta Crystallogr F Struct Biol Commun 77: 70-78

PubMed: 33682791 Search on PubMed Search on PubMed Central
DOI: https://doi.org/10.1107/S2053230X2100203X
Primary Citation Related Structures:
7B51

PubMed Abstract:
CRM1 is a nuclear export receptor that has been intensively targeted over the last decade for the development of antitumor and antiviral drugs. Structural analysis of several inhibitor compounds bound to CRM1 revealed that their mechanism of action relies on the covalent modification of a critical cysteine residue (Cys528 in the human receptor) located in the nuclear export signal-binding cleft. This study presents the crystal structure of human CRM1, covalently modified by 2-mercaptoethanol on Cys528, in complex with RanGTP at 2.58 Å resolution. The results demonstrate that buffer components can interfere with the characterization of cysteine-dependent inhibitor compounds.

Organizational Affiliation

Department for Molecular Structural Biology, Georg-August-Universität Göttingen, Justus-von-Liebig Weg 11, 37077 Göttingen, Germany.

Macromolecule Content

Total Structure Weight: 143.37 kDa
Atom Count: 9,786
Modeled Residue Count: 1,187
Deposited Residue Count: 1,242
Unique protein chains: 2

Macromolecules

Find similar proteins by:

| 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
GTP-binding nuclear protein Ran	A [auth B]	182	Homo sapiens	Mutation(s): 1 Gene Names: RAN, ARA24, OK/SW-cl.81 EC: 3.6.5
UniProt & NIH Common Fund Data Resources
Find proteins for P62826 (Homo sapiens) Explore P62826 Go to UniProtKB: P62826
PHAROS: P62826 GTEx: ENSG00000132341
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	P62826
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

| 3D Structure

Entity ID: 2
Molecule	Chains	Sequence Length	Organism	Details	Image
Exportin-1	B [auth A]	1,060	Homo sapiens	Mutation(s): 3 Gene Names: XPO1, CRM1
UniProt & NIH Common Fund Data Resources
Find proteins for O14980 (Homo sapiens) Explore O14980 Go to UniProtKB: O14980
PHAROS: O14980 GTEx: ENSG00000082898
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	O14980
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 3 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
GTP Query on GTP Download:Ideal Coordinates CCD File SDF format, chain C [auth B] MOL2 format, chain C [auth B] mmCIF format, chain C [auth B]	C [auth B]	GUANOSINE-5'-TRIPHOSPHATE C₁₀ H₁₆ N₅ O₁₄ P₃ XKMLYUALXHKNFT-UUOKFMHZSA-N		Interactions Focus chain C [auth B] Interactions & Density Focus chain C [auth B]
BME (Subject of Investigation/LOI) Query on BME Download:Ideal Coordinates CCD File SDF format, chain E [auth A] MOL2 format, chain E [auth A] mmCIF format, chain E [auth A]	E [auth A]	BETA-MERCAPTOETHANOL C₂ H₆ O S DGVVWUTYPXICAM-UHFFFAOYSA-N		Interactions Focus chain E [auth A] Interactions & Density Focus chain E [auth A]
MG Query on MG Download:Ideal Coordinates CCD File SDF format, chain D [auth B] MOL2 format, chain D [auth B] mmCIF format, chain D [auth B]	D [auth B]	MAGNESIUM ION Mg JLVVSXFLKOJNIY-UHFFFAOYSA-N		Interactions Focus chain D [auth B] Interactions & Density Focus chain D [auth B]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.58 Å
R-Value Free: 0.250 (Depositor), 0.249 (DCC)
R-Value Work: 0.214 (Depositor), 0.213 (DCC)
R-Value Observed: 0.216 (Depositor)

Space Group: I 2 2 2

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 121.111	α = 90
b = 150.591	β = 90
c = 231.969	γ = 90

Software Package:

Software Name	Purpose
REFMAC	refinement
XDS	data reduction
XSCALE	data scaling
PDB_EXTRACT	data extraction
PHASER	phasing

Structure Validation

View Full Validation Report

Ligand Structure Quality Assessment

View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Released Date: 2021-03-10

Deposition Author(s):

Shaikhqasem, A.

Ficner, R.

Funding Organization	Location	Grant Number
German Research Foundation (DFG)	Germany	--

Revision History (Full details and data files)

Version 1.0: 2021-03-10
Type: Initial release
Version 1.1: 2021-03-17
Changes: Database references
Version 1.2: 2024-01-31
Changes: Data collection, Database references, Refinement description
