7AQH | pdb_00007aqh

Cell wall binding domain of the Staphylococcal phage 2638A endolysin

PDB DOI: https://doi.org/10.2210/pdb7AQH/pdb

Classification: VIRAL PROTEIN
Organism(s): Staphylococcus phage 2638A
Expression System: Escherichia coli BL21(DE3)
Mutation(s): No

Deposited: 2020-10-21 Released: 2020-12-02
Deposition Author(s): Dunne, M., Sobieraj, A., Ernst, P., Mittl, P.R.E., Pluckthun, A., Loessner, M.J.

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.49 Å
R-Value Free:
0.286 (Depositor), 0.285 (DCC)
R-Value Work:
0.250 (Depositor), 0.251 (DCC)
R-Value Observed:
0.252 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 7AQH

This is version 1.1 of the entry. See complete history.

Literature

Cell wall binding domain of the Staphylococcal phage 2638A endolysin

Dunne, M., Sobieraj, A., Ernst, P., Mittl, P.R.E., Pluckthun, A., Loessner, M.J.

To be published.

Macromolecule Content

Total Structure Weight: 88.38 kDa
Atom Count: 6,302
Modeled Residue Count: 744
Deposited Residue Count: 760
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
ORF007	A B [auth D] C D [auth G] E [auth H] A, B [auth D], C, D [auth G], E [auth H], F [auth B], G [auth E], H [auth F]	95	Staphylococcus phage 2638A	Mutation(s): 0 EC: 3.5.1.28
UniProt
Find proteins for Q4ZD58 (Staphylococcus phage 2638A) Explore Q4ZD58 Go to UniProtKB: Q4ZD58
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	Q4ZD58
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
EPE Query on EPE Download:Ideal Coordinates CCD File SDF format, chain J [auth G] SDF format, chain I [auth A] MOL2 format, chain J [auth G] MOL2 format, chain I [auth A] mmCIF format, chain J [auth G] mmCIF format, chain I [auth A]	I [auth A], J [auth G]	4-(2-HYDROXYETHYL)-1-PIPERAZINE ETHANESULFONIC ACID C₈ H₁₈ N₂ O₄ S JKMHFZQWWAIEOD-UHFFFAOYSA-N		Interactions Focus chain I [auth A] Focus chain J [auth G] Interactions & Density Focus chain I [auth A] Focus chain J [auth G]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.49 Å
R-Value Free: 0.286 (Depositor), 0.285 (DCC)
R-Value Work: 0.250 (Depositor), 0.251 (DCC)
R-Value Observed: 0.252 (Depositor)

Space Group: P 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 62.13	α = 111.01
b = 62.51	β = 108.387
c = 66.171	γ = 90.184

Software Package:

Software Name	Purpose
XDS	data reduction
XDS	data scaling
MOLREP	phasing
PHENIX	refinement
Coot	model building

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

Deposition Data

Released Date: 2020-12-02

Deposition Author(s):

Revision History (Full details and data files)

Version 1.0: 2020-12-02
Type: Initial release
Version 1.1: 2024-01-31
Changes: Data collection, Database references, Refinement description
