7AOO | pdb_00007aoo

Plasmoredoxin, a redox-active protein unique for malaria parasites


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.60 Å
  • R-Value Free:
    0.210 (Depositor), 0.211 (DCC)
  • R-Value Work:
    0.178 (Depositor), 0.179 (DCC)
  • R-Value Observed:
    0.179 (Depositor)

wwPDB Validation 3D Report Full Report

Validation slider image for 7AOO

This is version 1.2 of the entry. See complete history

Literature

Crystal structure of plasmoredoxin, a redox-active protein unique for malaria parasites.

Fritz-Wolf, K.Bathke, J.Rahlfs, S.Becker, K.

(2022) Curr Res Struct Biol 4: 87-95

  • DOI: https://doi.org/10.1016/j.crstbi.2022.03.004
  • Primary Citation Related Structures:
    7AOJ, 7AOO

  • PubMed Abstract:

    Plasmoredoxin is a 22 ​kDa thiol-disulfide oxidoreductase involved in cellular redox regulatory processes and antioxidant defense. The 1.6 ​Å structure of the protein, solved via X-ray crystallography, adopts a modified thioredoxin fold. The structure reveals that plasmoredoxin, unique for malarial parasites, forms a new subgroup of thioredoxin-like proteins together with tryparedoxin, unique for kinetoplastids. Unlike most members of this superfamily, Plrx does not have a proline residue within the CxxC redox motif. In addition, the Plrx structure has a distinct C-terminal domain. Similar to human thioredoxin, plasmoredoxin forms monomers and dimers, which are also structurally similar to the human thioredoxin dimer, and, as in humans, plasmoredoxin is inactive as a dimer. Monomer-dimer equilibrium depends on the surrounding redox conditions, which could support the parasite in reacting to oxidative challenges. Based on structural considerations, the residues of the dimer interface are likely to interact with target proteins. In contrast to human and Plasmodium falciparum thioredoxin, however, there is a cluster of positively charged residues at the dimer interface of plasmoredoxin. These intersubunit (lysine) residues might allow binding of the protein to cellular membranes or to plasminogen. Malaria parasites lack catalase and glutathione peroxidase and therefore depend on their other glutathione and thioredoxin-dependent redox relays. Plasmoredoxin could be part of a so far unknown electron transfer system that only occurs in these parasites. Since the surface charge of plasmoredoxin differs significantly from other members of the thioredoxin superfamily, its three-dimensional structure can provide a model for designing selective redox-modulatory inhibitors.


  • Organizational Affiliation
    • Biochemistry and Molecular Biology, Interdisciplinary Research Center, Justus Liebig University, 35392, Giessen, Germany.

Macromolecule Content

  • Total Structure Weight: 90.25 kDa
  • Atom Count: 6,181
  • Modeled Residue Count: 648
  • Deposited Residue Count: 716
  • Unique protein chains: 1

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
Plasmoredoxin
A, B, C, D
179Plasmodium falciparum 3D7Mutation(s): 0
Gene Names: PF3D7_0303600
UniProt
Find proteins for Q8I224 (Plasmodium falciparum (isolate 3D7))
Explore Q8I224
Go to UniProtKB:  Q8I224
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ8I224
Sequence Annotations
Expand
Reference Sequence

Small Molecules

Ligands 4 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
P6G

Query on P6G



Download:Ideal Coordinates CCD File
AA [auth D],
S [auth C],
T [auth C],
U [auth C]
HEXAETHYLENE GLYCOL
C12 H26 O7
IIRDTKBZINWQAW-UHFFFAOYSA-N
PGE

Query on PGE



Download:Ideal Coordinates CCD File
BA [auth D],
G [auth A],
O [auth B]
TRIETHYLENE GLYCOL
C6 H14 O4
ZIBGPFATKBEMQZ-UHFFFAOYSA-N
PEG

Query on PEG



Download:Ideal Coordinates CCD File
F [auth A]
H [auth B]
I [auth B]
J [auth B]
K [auth B]
F [auth A],
H [auth B],
I [auth B],
J [auth B],
K [auth B],
L [auth B],
M [auth B],
N [auth B],
P [auth C],
Q [auth C],
R [auth C],
V [auth D],
W [auth D],
X [auth D],
Y [auth D],
Z [auth D]
DI(HYDROXYETHYL)ETHER
C4 H10 O3
MTHSVFCYNBDYFN-UHFFFAOYSA-N
GOL

Query on GOL



Download:Ideal Coordinates CCD File
E [auth A]GLYCEROL
C3 H8 O3
PEDCQBHIVMGVHV-UHFFFAOYSA-N

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.60 Å
  • R-Value Free:  0.210 (Depositor), 0.211 (DCC)
  • R-Value Work:  0.178 (Depositor), 0.179 (DCC)
  • R-Value Observed: 0.179 (Depositor)
Space Group: P 1 21 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 47.75α = 90
b = 122.73β = 104.881
c = 72.86γ = 90
Software Package:
Software NamePurpose
PHENIXrefinement
PHENIXrefinement
XDSdata reduction
XSCALEdata scaling
PHENIXphasing

Structure Validation

View Full Validation Report



Entry History

& Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Hessian Ministry of Science, Higher Education and Art (HMWK)--

Revision History  (Full details and data files)

  • Version 1.0: 2022-04-13
    Type: Initial release
  • Version 1.1: 2022-04-27
    Changes: Database references
  • Version 1.2: 2024-06-19
    Changes: Data collection
