7AHY

Crystal structure of Western clawed frog MDM2 RING domain homodimer


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.53 Å
  • R-Value Free: 0.279
  • R-Value Work: 0.217

wwPDB Validation   3D Report Full Report


This is version 1.3 of the entry. See complete history


Literature

Identification of a Catalytic Active but Non-Aggregating MDM2 RING Domain Variant.

Magnussen, H.M.Huang, D.T.

(2021) J Mol Biol 433: 166807-166807

  • DOI: https://doi.org/10.1016/j.jmb.2021.166807
  • Primary Citation of Related Structures:
    7AH2, 7AHY, 7AHZ, 7AI0, 7AI1

  • PubMed Abstract:

    As a key regulator of the tumour suppressor protein p53, MDM2 is involved in various types of cancer and has thus been an attractive drug target. So far, small molecule design has primarily focussed on the N-terminal p53-binding domain although on-target toxicity effects have been reported. Targeting the catalytic RING domain of MDM2 resembles an alternative approach to drug MDM2 with the idea to prevent MDM2-mediated ubiquitination of p53 while retaining MDM2's ability to bind p53. The design of RING inhibitors has been limited by the extensive aggregation tendency of the RING domain, making it challenging to undertake co-crystallization attempts with potential inhibitors. Here we compare the purification profiles of the MDM2 RING domain from several species and show that the MDM2 RING domain of other species than human is much less prone to aggregate although the overall structure of the RING domain is conserved. Through sequence comparison and mutagenesis analyses, we identify a single point mutation, G443T, which greatly enhances the dimeric fraction of human MDM2 RING domain during purification. Neither does the mutation alter the structure of the RING domain, nor does it affect E2(UbcH5B)-Ub binding and activity. Hence, MDM2-G443T facilitates studies involving binding partners that would be hampered by the low solubility of the wild-type RING domain. Furthermore, it will be valuable for the development of MDM2 RING inhibitors.


  • Organizational Affiliation

    Cancer Research UK Beatson Institute, Garscube Estate, Switchback Road, Glasgow G61 1BD, United Kingdom; Institute of Cancer Sciences, University of Glasgow, Glasgow G61 1QH, United Kingdom.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
E3 ubiquitin-protein ligase Mdm2A [auth AAA],
B [auth BBB]
71Xenopus tropicalisMutation(s): 0
Gene Names: mdm2irak1
EC: 2.3.2.27
UniProt
Find proteins for Q6P3Q9 (Xenopus tropicalis)
Explore Q6P3Q9
Go to UniProtKB:  Q6P3Q9
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ6P3Q9
Sequence Annotations
Expand
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.53 Å
  • R-Value Free: 0.279
  • R-Value Work: 0.217
  • Space Group: P 1 21 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 42.559α = 90
b = 23.76β = 101.224
c = 55.744γ = 90
Software Package:
Software NamePurpose
REFMACrefinement
xia2data reduction
Aimlessdata scaling
PHASERphasing

Structure Validation

View Full Validation Report



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Cancer Research UKUnited KingdomA17196
Cancer Research UKUnited KingdomA29256
European Research Council (ERC)United Kingdom647849

Revision History  (Full details and data files)

  • Version 1.0: 2021-01-20
    Type: Initial release
  • Version 1.1: 2021-01-27
    Changes: Database references
  • Version 1.2: 2021-02-10
    Changes: Database references
  • Version 1.3: 2024-01-31
    Changes: Advisory, Data collection, Database references, Derived calculations, Refinement description
