7ADI | pdb_00007adi

KirBac3.1 W46R: role of a highly conserved tryptophan at the membrane-water interface of Kir channel


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.80 Å
  • R-Value Free:
    0.287 (Depositor), 0.286 (DCC)
  • R-Value Work:
    0.222 (Depositor), 0.224 (DCC)
  • R-Value Observed:
    0.225 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 7ADI

This is version 1.2 of the entry. See complete history

Literature

Integrative Study of the Structural and Dynamical Properties of a KirBac3.1 Mutant: Functional Implication of a Highly Conserved Tryptophan in the Transmembrane Domain.

Fagnen, C.Bannwarth, L.Oubella, I.Zuniga, D.Haouz, A.Forest, E.Scala, R.Bendahhou, S.De Zorzi, R.Perahia, D.Venien-Bryan, C.

(2021) Int J Mol Sci 23

  • DOI: https://doi.org/10.3390/ijms23010335
  • Primary Citation Related Structures:
    7ADI

  • PubMed Abstract:

    ATP-sensitive potassium (K-ATP) channels are ubiquitously expressed on the plasma membrane of cells in several organs, including the heart, pancreas, and brain, and they govern a wide range of physiological processes. In pancreatic β-cells, K-ATP channels composed of Kir6.2 and SUR1 play a key role in coupling blood glucose and insulin secretion. A tryptophan residue located at the cytosolic end of the transmembrane helix is highly conserved in eukaryote and prokaryote Kir channels. Any mutation on this amino acid causes a gain of function and neonatal diabetes mellitus. In this study, we have investigated the effect of mutation on this highly conserved residue on a KirBac channel (prokaryotic homolog of mammalian Kir6.2). We provide the crystal structure of the mutant KirBac3.1 W46R (equivalent to W68R in Kir6.2) and its conformational flexibility properties using HDX-MS. In addition, the detailed dynamical view of the mutant during the gating was investigated using the in silico method. Finally, functional assays have been performed. A comparison of important structural determinants for the gating mechanism between the wild type KirBac and the mutant W46R suggests interesting structural and dynamical clues and a mechanism of action of the mutation that leads to the gain of function.


  • Organizational Affiliation
    • IMPMC, UMR 7590, CNRS, Muséum National d'Histoire Naturelle, Sorbonne Université, 75005 Paris, France.

Macromolecule Content

  • Total Structure Weight: 67.65 kDa
  • Atom Count: 4,303
  • Modeled Residue Count: 541
  • Deposited Residue Count: 602
  • Unique protein chains: 1

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
Inward rectifier potassium channel Kirbac3.1
A, B
301Paramagnetospirillum magnetotacticumMutation(s): 1
Membrane Entity: Yes
UniProt
Find proteins for D9N164 (Paramagnetospirillum magnetotacticum)
Explore D9N164
Go to UniProtKB:  D9N164
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupD9N164
Sequence Annotations
Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.80 Å
  • R-Value Free:  0.287 (Depositor), 0.286 (DCC)
  • R-Value Work:  0.222 (Depositor), 0.224 (DCC)
  • R-Value Observed: 0.225 (Depositor)
Space Group: P 21 21 2
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 106.77α = 90
b = 113.98β = 90
c = 89.18γ = 90
Software Package:
Software NamePurpose
XDSdata reduction
Aimlessdata scaling
REFMACrefinement
BUSTERrefinement
PDB_EXTRACTdata extraction
PHASERphasing

Structure Validation

View Full Validation Report



Entry History

& Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Other privateFrance19928
Other governmentFranceANR-EQUIPEX
Other governmentFinlandMRT

Revision History  (Full details and data files)

  • Version 1.0: 2022-01-12
    Type: Initial release
  • Version 1.1: 2022-01-26
    Changes: Database references
  • Version 1.2: 2024-01-31
    Changes: Data collection, Refinement description
