6XZF | pdb_00006xzf

Nanobody in complex with eGFP

PDB DOI: https://doi.org/10.2210/pdb6XZF/pdb

Classification: IMMUNE SYSTEM
Organism(s): Aequorea victoria, Lama glama
Expression System: Escherichia coli 'BL21-Gold(DE3)pLysS AG
Mutation(s): No

Deposited: 2020-02-04 Released: 2021-02-17
Deposition Author(s): Pompidor, G., Zimmermann, S., Loew, C., Schneider, T.

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.80 Å
R-Value Free:
0.203 (Depositor), 0.206 (DCC)
R-Value Work:
0.173 (Depositor), 0.176 (DCC)
R-Value Observed:
0.175 (Depositor)

wwPDB Validation 3D Report Full Report

Validation slider image for 6XZF

This is version 2.1 of the entry. See complete history.

Literature

Engineered nanobodies with a lanthanide binding motif for crystallographic phasing

Pompidor, G., Zimmermann, S., Loew, C., Schneider, T.

To be published.

Macromolecule Content

Total Structure Weight: 41.85 kDa
Atom Count: 3,055
Modeled Residue Count: 352
Deposited Residue Count: 368
Unique protein chains: 2

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
eGFP	A	236	Aequorea victoria	Mutation(s): 0
UniProt
Find proteins for P42212 (Aequorea victoria) Explore P42212 Go to UniProtKB: P42212
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	P42212
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

Entity ID: 2
Molecule	Chains	Sequence Length	Organism	Details	Image
Nanobody targeted against eGFP	B	132	Lama glama	Mutation(s): 0

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
TB (Subject of Investigation/LOI) Query on TB Download:Ideal Coordinates CCD File SDF format, chain C [auth B] MOL2 format, chain C [auth B] mmCIF format, chain C [auth B]	C [auth B]	TERBIUM(III) ION Tb HKCRVXUAKWXBLE-UHFFFAOYSA-N		Interactions Focus chain C [auth B] Interactions & Density Focus chain C [auth B]

Modified Residues 1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
CRO Query on CRO	A	L-PEPTIDE LINKING	C₁₅ H₁₇ N₃ O₅		THR, TYR, GLY

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.80 Å
R-Value Free: 0.203 (Depositor), 0.206 (DCC)
R-Value Work: 0.173 (Depositor), 0.176 (DCC)
R-Value Observed: 0.175 (Depositor)

Space Group: P 3₁ 2 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 69.335	α = 90
b = 69.335	β = 90
c = 169.063	γ = 120

Software Package:

Software Name	Purpose
PHENIX	refinement
PDB_EXTRACT	data extraction
XDS	data reduction
Aimless	data scaling
SHELXDE	phasing

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

Deposition Data

Released Date: 2021-02-17

Deposition Author(s):

Revision History (Full details and data files)

Version 1.0: 2021-02-17
Type: Initial release
Version 2.0: 2023-11-15
Changes: Advisory, Atomic model, Data collection, Database references
Version 2.1: 2024-10-23
Changes: Structure summary
