6VJ7

Crystal structure of red kidney bean purple acid phosphatase in complex with adenosine 5'-(beta,gamma imido)triphosphate


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.60 Å
  • R-Value Free: 0.274
  • R-Value Work: 0.213
  • R-Value Observed: 0.216

wwPDB Validation   3D Report Full Report

Currently 6VJ7 does not have a validation slider image.


This is version 3.1 of the entry. See complete history


Literature

Structural elements that modulate the substrate specificity of plant purple acid phosphatases: Avenues for improved phosphorus acquisition in crops.

Feder, D.McGeary, R.P.Mitic, N.Lonhienne, T.Furtado, A.Schulz, B.L.Henry, R.J.Schmidt, S.Guddat, L.W.Schenk, G.

(2020) Plant Sci 294: 110445-110445

  • DOI: https://doi.org/10.1016/j.plantsci.2020.110445
  • Primary Citation of Related Structures:
    6PY9, 6VJ7

  • PubMed Abstract:

    Phosphate acquisition by plants is an essential process that is directly implicated in the optimization of crop yields. Purple acid phosphatases (PAPs) are ubiquitous metalloenzymes, which catalyze the hydrolysis of a wide range of phosphate esters and anhydrides. While some plant PAPs display a preference for ATP as the substrate, others are efficient in hydrolyzing phytate or 2-phosphoenolpyruvate (PEP). PAP from red kidney bean (rkbPAP) is an efficient ATP- and ADPase, but has no activity towards phytate. Crystal structures of this enzyme in complex with ATP analogues (to 2.20 and 2.60 Å resolution, respectively) complement the recent structure of rkbPAP with a bound ADP analogue (ChemBioChem 20 (2019) 1536). Together these complexes provide the first structural insight of a PAP in complex with molecules that mimic biologically relevant substrates. Homology modeling was used to generate three-dimensional structures for the active sites of PAPs from tobacco (NtPAP) and thale cress (AtPAP26) that are efficient in hydrolyzing phytate and PEP as preferred substrates, respectively. The combining of crystallographic data, substrate docking simulations and a phylogenetic analysis of 49 plant PAP sequences (including the first PAP sequences reported from Eucalyptus) resulted in the identification of several active site residues that are important in defining the substrate specificities of plant PAPs; of particular relevance is the identification of a motif ("REKA") that is characteristic for plant PAPs that possess phytase activity. These results may inform bioengineering studies aimed at identifying and incorporating suitable plant PAP genes into crops to improve phosphorus acquisition and use efficiency. Organic phosphorus sources increasingly supplement or replace inorganic fertilizer, and efficient phosphorus use of crops will lower the environmental footprint of agriculture while enhancing food production.


  • Organizational Affiliation

    School of Chemistry and Molecular Biosciences, The University of Queensland, St. Lucia, QLD 4072, Australia; Department of Biochemistry and Molecular Biology, George S. Wise Faculty of Life Sciences, Tel Aviv University, Tel Aviv, Israel.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Fe(3+)-Zn(2+) purple acid phosphatase
A, B, C, D
426Phaseolus vulgarisMutation(s): 0
EC: 3.1.3.2
UniProt
Find proteins for P80366 (Phaseolus vulgaris)
Explore P80366
Go to UniProtKB:  P80366
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP80366
Sequence Annotations
Expand
  • Reference Sequence
Oligosaccharides

Help

Entity ID: 2
MoleculeChains Length2D Diagram Glycosylation3D Interactions
beta-D-mannopyranose-(1-3)-beta-D-mannopyranose-(1-4)-2-acetamido-2-deoxy-beta-D-glucopyranose-(1-4)-2-acetamido-2-deoxy-beta-D-glucopyranose
E
4N-Glycosylation
Glycosylation Resources
GlyTouCan:  G31886NL
GlyCosmos:  G31886NL
GlyGen:  G31886NL
Entity ID: 3
MoleculeChains Length2D Diagram Glycosylation3D Interactions
beta-D-mannopyranose-(1-4)-2-acetamido-2-deoxy-beta-D-glucopyranose-(1-4)-2-acetamido-2-deoxy-beta-D-glucopyranose
F, H
3N-Glycosylation
Glycosylation Resources
GlyTouCan:  G15407YE
GlyCosmos:  G15407YE
GlyGen:  G15407YE
Entity ID: 4
MoleculeChains Length2D Diagram Glycosylation3D Interactions
beta-D-mannopyranose-(1-4)-beta-D-mannopyranose-(1-4)-2-acetamido-2-deoxy-beta-D-glucopyranose-(1-4)-2-acetamido-2-deoxy-beta-D-glucopyranose
G
4N-Glycosylation
Glycosylation Resources
GlyTouCan:  G53755TJ
GlyCosmos:  G53755TJ
GlyGen:  G53755TJ
Entity ID: 5
MoleculeChains Length2D Diagram Glycosylation3D Interactions
alpha-L-fucopyranose-(1-3)-[2-acetamido-2-deoxy-beta-D-glucopyranose-(1-4)]2-acetamido-2-deoxy-beta-D-glucopyranose
I, J
3N-Glycosylation
Glycosylation Resources
GlyTouCan:  G11971MR
GlyCosmos:  G11971MR
GlyGen:  G11971MR
Entity ID: 6
MoleculeChains Length2D Diagram Glycosylation3D Interactions
2-acetamido-2-deoxy-beta-D-glucopyranose-(1-4)-2-acetamido-2-deoxy-beta-D-glucopyranose
K, L
2N-Glycosylation
Glycosylation Resources
GlyTouCan:  G42666HT
GlyCosmos:  G42666HT
GlyGen:  G42666HT
Small Molecules
Ligands 11 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
ANP
Query on ANP

Download Ideal Coordinates CCD File
CD [auth D],
DA [auth A],
UB [auth C]
PHOSPHOAMINOPHOSPHONIC ACID-ADENYLATE ESTER
C10 H17 N6 O12 P3
PVKSNHVPLWYQGJ-KQYNXXCUSA-N
NAG
Query on NAG

Download Ideal Coordinates CCD File
AD [auth D]
BA [auth A]
BD [auth D]
CA [auth A]
SB [auth C]
AD [auth D],
BA [auth A],
BD [auth D],
CA [auth A],
SB [auth C],
UA [auth B],
XA [auth C]
2-acetamido-2-deoxy-beta-D-glucopyranose
C8 H15 N O6
OVRNDRQMDRJTHS-FMDGEEDCSA-N
PG4
Query on PG4

Download Ideal Coordinates CCD File
EA [auth A],
WB [auth D]
TETRAETHYLENE GLYCOL
C8 H18 O5
UWHCKJMYHZGTIT-UHFFFAOYSA-N
PGE
Query on PGE

Download Ideal Coordinates CCD File
AA [auth A]
QB [auth C]
RB [auth C]
SA [auth B]
TA [auth B]
AA [auth A],
QB [auth C],
RB [auth C],
SA [auth B],
TA [auth B],
YC [auth D],
ZC [auth D]
TRIETHYLENE GLYCOL
C6 H14 O4
ZIBGPFATKBEMQZ-UHFFFAOYSA-N
SO4
Query on SO4

Download Ideal Coordinates CCD File
AB [auth C]
AC [auth D]
BB [auth C]
BC [auth D]
CB [auth C]
AB [auth C],
AC [auth D],
BB [auth C],
BC [auth D],
CB [auth C],
CC [auth D],
DB [auth C],
DC [auth D],
EB [auth C],
EC [auth D],
FB [auth C],
FC [auth D],
GB [auth C],
GC [auth D],
HC [auth D],
IA [auth B],
JA [auth B],
KA [auth B],
LA [auth B],
O [auth A],
P [auth A],
Q [auth A],
WA [auth C],
ZB [auth D]
SULFATE ION
O4 S
QAOWNCQODCNURD-UHFFFAOYSA-L
GOL
Query on GOL

Download Ideal Coordinates CCD File
HB [auth C]
IC [auth D]
JC [auth D]
KC [auth D]
LC [auth D]
HB [auth C],
IC [auth D],
JC [auth D],
KC [auth D],
LC [auth D],
R [auth A],
S [auth A],
T [auth A],
U [auth A]
GLYCEROL
C3 H8 O3
PEDCQBHIVMGVHV-UHFFFAOYSA-N
ZN
Query on ZN

Download Ideal Coordinates CCD File
GA [auth B],
M [auth A],
XB [auth D],
YA [auth C]
ZINC ION
Zn
PTFCDOFLOPIGGS-UHFFFAOYSA-N
EDO
Query on EDO

Download Ideal Coordinates CCD File
IB [auth C]
JB [auth C]
KB [auth C]
LB [auth C]
MA [auth B]
IB [auth C],
JB [auth C],
KB [auth C],
LB [auth C],
MA [auth B],
MB [auth C],
MC [auth D],
NA [auth B],
NB [auth C],
NC [auth D],
OA [auth B],
OB [auth C],
OC [auth D],
PA [auth B],
PB [auth C],
PC [auth D],
QA [auth B],
QC [auth D],
RA [auth B],
RC [auth D],
SC [auth D],
TC [auth D],
UC [auth D],
V [auth A],
VC [auth D],
W [auth A],
WC [auth D],
X [auth A],
XC [auth D],
Y [auth A],
Z [auth A]
1,2-ETHANEDIOL
C2 H6 O2
LYCAIKOWRPUZTN-UHFFFAOYSA-N
IPA
Query on IPA

Download Ideal Coordinates CCD File
TB [auth C]ISOPROPYL ALCOHOL
C3 H8 O
KFZMGEQAYNKOFK-UHFFFAOYSA-N
FE
Query on FE

Download Ideal Coordinates CCD File
HA [auth B],
N [auth A],
YB [auth D],
ZA [auth C]
FE (III) ION
Fe
VTLYFUHAOXGGBS-UHFFFAOYSA-N
NA
Query on NA

Download Ideal Coordinates CCD File
FA [auth A],
VA [auth B],
VB [auth C]
SODIUM ION
Na
FKNQFGJONOIPTF-UHFFFAOYSA-N
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.60 Å
  • R-Value Free: 0.274
  • R-Value Work: 0.213
  • R-Value Observed: 0.216
  • Space Group: P 31 2 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 125.704α = 90
b = 125.704β = 90
c = 298.151γ = 120
Software Package:
Software NamePurpose
PHENIXrefinement
d*TREKdata reduction
pointlessdata scaling
PHASERphasing

Structure Validation

View Full Validation Report

Currently 6VJ7 does not have a validation slider image.



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Australian Research Council (ARC)AustraliaDP0986292
Australian Research Council (ARC)Australia150104358

Revision History  (Full details and data files)

  • Version 1.0: 2020-04-29
    Type: Initial release
  • Version 2.0: 2020-05-20
    Type: Coordinate replacement
    Reason: Ligand geometry
    Changes: Advisory, Atomic model, Author supporting evidence, Data collection, Derived calculations, Other, Refinement description, Structure summary
  • Version 3.0: 2020-07-29
    Type: Remediation
    Reason: Carbohydrate remediation
    Changes: Advisory, Atomic model, Data collection, Derived calculations, Structure summary
  • Version 3.1: 2023-10-11
    Changes: Data collection, Database references, Refinement description, Structure summary
