HslU from Staphylococcus aureus

Experimental Data Snapshot

  • Resolution: 3.00 Å
  • R-Value Free: 0.279
  • R-Value Work: 0.235
  • R-Value Observed: 0.235

wwPDB Validation   3D Report Full Report

This is version 1.2 of the entry. See complete history


Cleavage-Dependent Activation of ATP-Dependent Protease HslUV from Staphylococcus aureus .

Jeong, S.Ahn, J.Kwon, A.R.Ha, N.-C.

(2020) Mol Cells 43: 694-704

  • DOI: https://doi.org/10.14348/molcells.2020.0074
  • Primary Citation of Related Structures:
    6KR1, 6KUI, 6KWW

  • PubMed Abstract:

    HslUV is a bacterial heat shock protein complex consisting of the AAA+ ATPase component HslU and the protease component HslV. HslV is a threonine (Thr) protease employing the N-terminal Thr residue in the mature protein as the catalytic residue. To date, HslUV from Gram-negative bacteria has been extensively studied. However, the mechanisms of action and activation of HslUV from Gram-positive bacteria, which have an additional N-terminal sequence before the catalytic Thr residue, remain to be revealed. In this study, we determined the crystal structures of HslV from the Gram-positive bacterium Staphylococcus aureus with and without HslU in the crystallization conditions. The structural comparison suggested that a structural transition to the symmetric form of HslV was triggered by ATP-bound HslU. More importantly, the additional N-terminal sequence was cleaved in the presence of HslU and ATP, exposing the Thr9 residue at the N-terminus and activating the ATP-dependent protease activity. Further biochemical studies demonstrated that the exposed N-terminal Thr residue is critical for catalysis with binding to the symmetric HslU hexamer. Since eukaryotic proteasomes have a similar additional N-terminal sequence, our results will improve our understanding of the common molecular mechanisms for the activation of proteasomes.

  • Organizational Affiliation

    Department of Agricultural Biotechnology, Center for Food Safety and Toxicology, Center for Food and Bioconvergence, and Research Institute for Agriculture and Life Sciences, CALS, Seoul National University, Seoul 08826, Korea.

Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
ATP-dependent protease ATPase subunit HslU481Staphylococcus aureus subsp. aureus Mu50Mutation(s): 0
Gene Names: hslUclpYSAV1254
Find proteins for P63796 (Staphylococcus aureus (strain Mu50 / ATCC 700699))
Explore P63796
Go to UniProtKB:  P63796
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP63796
Sequence Annotations
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Resolution: 3.00 Å
  • R-Value Free: 0.279
  • R-Value Work: 0.235
  • R-Value Observed: 0.235
  • Space Group: P 1 21 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 146.618α = 90
b = 189.602β = 92.617
c = 215.813γ = 90
Software Package:
Software NamePurpose
HKL-2000data reduction
HKL-2000data scaling

Structure Validation

View Full Validation Report

Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2020-07-15
    Type: Initial release
  • Version 1.1: 2020-12-09
    Changes: Database references
  • Version 1.2: 2023-11-22
    Changes: Data collection, Database references, Refinement description
