Crystal Structure of a Non-hemolytic Pneumolysin from Streptococcus pneumoniae strain ST306

Experimental Data Snapshot

  • Resolution: 2.20 Å
  • R-Value Free: 0.266
  • R-Value Work: 0.224
  • R-Value Observed: 0.226

wwPDB Validation   3D Report Full Report

This is version 1.3 of the entry. See complete history


Structural insights into loss of function of a pore forming toxin and its role in pneumococcal adaptation to an intracellular lifestyle.

Badgujar, D.C.Anil, A.Green, A.E.Surve, M.V.Madhavan, S.Beckett, A.Prior, I.A.Godsora, B.K.Patil, S.B.More, P.K.Sarkar, S.G.Mitchell, A.Banerjee, R.Phale, P.S.Mitchell, T.J.Neill, D.R.Bhaumik, P.Banerjee, A.

(2020) PLoS Pathog 16: e1009016-e1009016

  • DOI: https://doi.org/10.1371/journal.ppat.1009016
  • Primary Citation of Related Structures:

  • PubMed Abstract:

    The opportunistic pathogen Streptococcus pneumoniae has dual lifestyles: one of an asymptomatic colonizer in the human nasopharynx and the other of a deadly pathogen invading sterile host compartments. The latter triggers an overwhelming inflammatory response, partly driven via pore forming activity of the cholesterol dependent cytolysin (CDC), pneumolysin. Although pneumolysin-induced inflammation drives person-to-person transmission from nasopharynx, the primary reservoir for pneumococcus, it also contributes to high mortality rates, creating a bottleneck that hampers widespread bacterial dissemination, thus acting as a double-edged sword. Serotype 1 ST306, a widespread pneumococcal clone, harbours a non-hemolytic variant of pneumolysin (Ply-NH). Performing crystal structure analysis of Ply-NH, we identified Y150H and T172I as key substitutions responsible for loss of its pore forming activity. We uncovered a novel inter-molecular cation-π interaction, governing formation of the transmembrane β-hairpins (TMH) in the pore state of Ply, which can be extended to other CDCs. H150 in Ply-NH disrupts this interaction, while I172 provides structural rigidity to domain-3, through hydrophobic interactions, inhibiting TMH formation. Loss of pore forming activity enabled improved cellular invasion and autophagy evasion, promoting an atypical intracellular lifestyle for pneumococcus, a finding that was corroborated in in vivo infection models. Attenuation of inflammatory responses and tissue damage promoted tolerance of Ply-NH-expressing pneumococcus in the lower respiratory tract. Adoption of this altered lifestyle may be necessary for ST306 due to its limited nasopharyngeal carriage, with Ply-NH, aided partly by loss of its pore forming ability, facilitating a benign association of SPN in an alternative, intracellular host niche.

  • Organizational Affiliation

    Department of Biosciences and Bioengineering, Indian Institute of Technology Bombay, Mumbai, Maharashtra, India.

Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Thiol-activated cytolysin469Streptococcus pneumoniaeMutation(s): 0
Gene Names: ply
Membrane Entity: Yes
Find proteins for Q2XU25 (Streptococcus pneumoniae)
Explore Q2XU25
Go to UniProtKB:  Q2XU25
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ2XU25
Sequence Annotations
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Resolution: 2.20 Å
  • R-Value Free: 0.266
  • R-Value Work: 0.224
  • R-Value Observed: 0.226
  • Space Group: P 21 21 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 24.48α = 90
b = 84.73β = 90
c = 214.62γ = 90
Software Package:
Software NamePurpose
XDSdata reduction
XSCALEdata scaling

Structure Validation

View Full Validation Report

Entry History & Funding Information

Deposition Data

Funding OrganizationLocationGrant Number
Department of Science & Technology (India)India--

Revision History  (Full details and data files)

  • Version 1.0: 2020-09-09
    Type: Initial release
  • Version 1.1: 2020-09-23
    Changes: Database references
  • Version 1.2: 2021-02-24
    Changes: Database references
  • Version 1.3: 2023-11-22
    Changes: Data collection, Database references, Refinement description
