Crystal structure of YFV-17D sE in prefusion state

Experimental Data Snapshot

  • Resolution: 2.80 Å
  • R-Value Free: 0.276
  • R-Value Work: 0.243
  • R-Value Observed: 0.244

wwPDB Validation   3D Report Full Report

This is version 1.0 of the entry. See complete history


Double Lock of a Human Neutralizing and Protective Monoclonal Antibody Targeting the Yellow Fever Virus Envelope.

Lu, X.Xiao, H.Li, S.Pang, X.Song, J.Liu, S.Cheng, H.Li, Y.Wang, X.Huang, C.Guo, T.Ter Meulen, J.Daffis, S.Yan, J.Dai, L.Rao, Z.Klenk, H.D.Qi, J.Shi, Y.Gao, G.F.

(2019) Cell Rep 26: 438-446.e5

  • DOI: https://doi.org/10.1016/j.celrep.2018.12.065
  • Primary Citation of Related Structures:
    6IVZ, 6IW0, 6IW1, 6IW2, 6IW4, 6IW5

  • PubMed Abstract:

    Yellow fever virus (YFV), a deadly human pathogen, is the prototype of the genus Flavivirus. Recently, YFV re-emerged in Africa and Brazil, leading to hundreds of deaths, with some cases imported to China. Prophylactic or therapeutic countermeasures are urgently needed. Previously, several human monoclonal antibodies against YFV were screened out by phage display. Here, we find that one of them, 5A, exhibits high neutralizing potency and good protection. Crystallographic analysis of the YFV envelope (E) protein in its pre- and post-fusion states shows conformations similar to those observed in other E proteins of flaviviruses. Furthermore, the structures of 5A in complex with the E protein in both states are resolved, revealing an invariant recognition site. Structural analysis and functional data suggest that 5A has high neutralization potency because it interferes with virus entry by preventing both virus attachment and fusion. These findings will be instrumental for immunogen or inhibitor design.

  • Organizational Affiliation

    Laboratory of Protein Engineering and Vaccines, Tianjin Institute of Industrial Biotechnology, Chinese Academy of Sciences, Tianjin 300308, China.

Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Envelope protein E
A, B
395Yellow fever virus 17DMutation(s): 0
EC: (UniProt), (UniProt), (UniProt), (UniProt), (UniProt), (UniProt)
Find proteins for P03314 (Yellow fever virus (strain 17D vaccine))
Explore P03314
Go to UniProtKB:  P03314
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP03314
Sequence Annotations
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Resolution: 2.80 Å
  • R-Value Free: 0.276
  • R-Value Work: 0.243
  • R-Value Observed: 0.244
  • Space Group: P 63
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 150.361α = 90
b = 150.361β = 90
c = 88.898γ = 120
Software Package:
Software NamePurpose
HKL-3000data reduction
HKL-3000data scaling

Structure Validation

View Full Validation Report

Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2019-02-13
    Type: Initial release
