A fast recovering full-length LOV protein (DsLOV) from the marine phototrophic bacterium Dinoroseobacter shibae (Dark state) - M49I mutant

Experimental Data Snapshot

  • Resolution: 1.86 Å
  • R-Value Free: 0.209
  • R-Value Work: 0.166
  • R-Value Observed: 0.168

wwPDB Validation   3D Report Full Report

Ligand Structure Quality Assessment

This is version 1.2 of the entry. See complete history


Mechanistic Basis of the Fast Dark Recovery of the Short LOV Protein DsLOV from Dinoroseobacter shibae.

Fettweiss, T.Rollen, K.Granzin, J.Reiners, O.Endres, S.Drepper, T.Willbold, D.Jaeger, K.E.Batra-Safferling, R.Krauss, U.

(2018) Biochemistry 57: 4833-4847

  • DOI: https://doi.org/10.1021/acs.biochem.8b00645
  • Primary Citation of Related Structures:
    6GAY, 6GB3, 6GBA, 6GBV

  • PubMed Abstract:

    Light, oxygen, voltage (LOV) proteins, a ubiquitously distributed class of photoreceptors, regulate a wide variety of light-dependent physiological responses. Because of their modular architecture, LOV domains, i.e., the sensory domains of LOV photoreceptors, have been widely used for the construction of optogenetic tools. We recently described the structure and function of a short LOV protein (DsLOV) from the marine phototropic bacterium Dinoroseobacter shibae, for which, in contrast to other LOV photoreceptors, the dark state represents the physiologically relevant signaling state. Among bacterial LOV photoreceptors, DsLOV possesses an exceptionally fast dark recovery, corroborating its function as a "dark" sensor. To address the mechanistic basis of this unusual characteristic, we performed a comprehensive mutational, kinetic, thermodynamic, and structural characterization of DsLOV. The mechanistic basis of the fast dark recovery of the protein was revealed by mutation of the previously noted uncommon residue substitution at position 49 found in DsLOV. The substitution of M49 with different residues that are naturally conserved in LOV domains tuned the dark-recovery time of DsLOV over 3 orders of magnitude, without grossly affecting its overall structure or the light-dependent structural change observed for the wild-type protein. Our study thus provides a striking example of how nature can achieve LOV photocycle tuning by subtle structural alterations in the LOV domain active site, highlighting the easy evolutionary adaptability of the light sensory function. At the same time, our data provide guidance for the mutational photocycle tuning of LOV domains, with relevance for the growing field of optogenetics.

  • Organizational Affiliation

    IBG-1: Biotechnology , Forschungszentrum Jülich , D-52425 Jülich , Germany.

Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Putative blue-light photoreceptor
A, B
146Dinoroseobacter shibae DFL 12 = DSM 16493Mutation(s): 1
Gene Names: Dshi_2006
Find proteins for A8LP63 (Dinoroseobacter shibae (strain DSM 16493 / NCIMB 14021 / DFL 12))
Explore A8LP63
Go to UniProtKB:  A8LP63
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA8LP63
Sequence Annotations
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Resolution: 1.86 Å
  • R-Value Free: 0.209
  • R-Value Work: 0.166
  • R-Value Observed: 0.168
  • Space Group: P 41 21 2
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 56.675α = 90
b = 56.675β = 90
c = 156.383γ = 90
Software Package:
Software NamePurpose
XDSdata reduction
Aimlessdata scaling

Structure Validation

View Full Validation Report

Ligand Structure Quality Assessment

Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2018-07-18
    Type: Initial release
  • Version 1.1: 2018-08-22
    Changes: Data collection, Database references
  • Version 1.2: 2024-01-17
    Changes: Data collection, Database references, Refinement description
