6FEY

Crystal structure of Drosophila neural ectodermal development factor Imp-L2 with Drosophila DILP5 insulin


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 3.48 Å
  • R-Value Free: 0.345
  • R-Value Work: 0.261
  • R-Value Observed: 0.265

wwPDB Validation   3D Report Full Report


This is version 1.3 of the entry. See complete history


Literature

Structures of insect Imp-L2 suggest an alternative strategy for regulating the bioavailability of insulin-like hormones.

Roed, N.K.Viola, C.M.Kristensen, O.Schluckebier, G.Norrman, M.Sajid, W.Wade, J.D.Andersen, A.S.Kristensen, C.Ganderton, T.R.Turkenburg, J.P.De Meyts, P.Brzozowski, A.M.

(2018) Nat Commun 9: 3860-3860

  • DOI: https://doi.org/10.1038/s41467-018-06192-3
  • Primary Citation of Related Structures:
    6FEY, 6FF3

  • PubMed Abstract:

    The insulin/insulin-like growth factor signalling axis is an evolutionary ancient and highly conserved hormonal system involved in the regulation of metabolism, growth and lifespan in animals. Human insulin is stored in the pancreas, while insulin-like growth factor-1 (IGF-1) is maintained in blood in complexes with IGF-binding proteins (IGFBP1-6). Insect insulin-like polypeptide binding proteins (IBPs) have been considered as IGFBP-like structural and functional homologues. Here, we report structures of the Drosophila IBP Imp-L2 in its free form and bound to Drosophila insulin-like peptide 5 and human IGF-1. Imp-L2 contains two immunoglobulin-like fold domains and its architecture is unrelated to human IGFBPs, suggesting a distinct strategy for bioavailability regulation of insulin-like hormones. Similar hormone binding modes may exist in other insect vectors, as the IBP sequences are highly conserved. Therefore, these findings may open research routes towards a rational interference of transmission of diseases such as malaria, dengue and yellow fevers.


  • Organizational Affiliation

    Global Research, Novo Nordisk A/S, Novo Nordisk Park 1, 2760, Maaloev, Denmark.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Neural/ectodermal development factor IMP-L2A,
B,
C [auth D],
D [auth C]
242Drosophila melanogasterMutation(s): 0
Gene Names: ImpL2CG15009
UniProt
Find proteins for Q09024 (Drosophila melanogaster)
Explore Q09024
Go to UniProtKB:  Q09024
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ09024
Sequence Annotations
Expand
  • Reference Sequence

Find similar proteins by:  Sequence   |   3D Structure

Entity ID: 2
MoleculeChains Sequence LengthOrganismDetailsImage
Probable insulin-like peptide 5
E, G, I, K
25Drosophila melanogasterMutation(s): 1
Gene Names: Ilp5HDC09365CG33273
UniProt
Find proteins for Q7KUD5 (Drosophila melanogaster)
Explore Q7KUD5
Go to UniProtKB:  Q7KUD5
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ7KUD5
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 3
MoleculeChains Sequence LengthOrganismDetailsImage
Probable insulin-like peptide 5
F, H, J, L
28Drosophila melanogasterMutation(s): 0
Gene Names: Ilp5HDC09365CG33273
UniProt
Find proteins for Q7KUD5 (Drosophila melanogaster)
Explore Q7KUD5
Go to UniProtKB:  Q7KUD5
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ7KUD5
Sequence Annotations
Expand
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 3.48 Å
  • R-Value Free: 0.345
  • R-Value Work: 0.261
  • R-Value Observed: 0.265
  • Space Group: P 41 21 2
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 150.834α = 90
b = 150.834β = 90
c = 125.321γ = 90
Software Package:
Software NamePurpose
REFMACrefinement
XDSdata reduction
SCALAdata scaling
MOLREPphasing

Structure Validation

View Full Validation Report



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Medical Research Council (United Kingdom)United KingdomMR/K000179/1

Revision History  (Full details and data files)

  • Version 1.0: 2018-09-26
    Type: Initial release
  • Version 1.1: 2018-10-03
    Changes: Data collection, Database references
  • Version 1.2: 2019-12-18
    Changes: Derived calculations
  • Version 1.3: 2024-01-17
    Changes: Data collection, Database references, Refinement description
