Key residues affecting transglycosylation activity in family 18 chitinases - Insights into donor and acceptor subsites

Experimental Data Snapshot

  • Resolution: 1.45 Å
  • R-Value Free: 0.209
  • R-Value Work: 0.175
  • R-Value Observed: 0.177

wwPDB Validation   3D Report Full Report

This is version 2.1 of the entry. See complete history


Key Residues Affecting Transglycosylation Activity in Family 18 Chitinases: Insights into Donor and Acceptor Subsites.

Madhuprakash, J.Dalhus, B.Rani, T.S.Podile, A.R.Eijsink, V.G.H.Sorlie, M.

(2018) Biochemistry 57: 4325-4337

  • DOI: https://doi.org/10.1021/acs.biochem.8b00381
  • Primary Citation of Related Structures:

  • PubMed Abstract:

    Understanding features that determine transglycosylation (TG) activity in glycoside hydrolases is important because it would allow the construction of enzymes that can catalyze controlled synthesis of oligosaccharides. To increase TG activity in two family 18 chitinases, chitinase D from Serratia proteamaculans ( SpChiD) and chitinase A from Serratia marcescens ( SmChiA), we have mutated residues important for stabilizing the reaction intermediate and substrate binding in both donor and acceptor sites. To help mutant design, the crystal structure of the inactive SpChiD-E153Q mutant in complex with chitobiose was determined. We identified three mutations with a beneficial effect on TG activity: Y28A (affecting the -1 subsite and the intermediate), Y222A (affecting the intermediate), and Y226W (affecting the +2 subsite). Furthermore, exchange of D151, the middle residue in the catalytically important DXDXE motif, to asparagine reduced hydrolytic activity ≤99% with a concomitant increase in apparent TG activity. The combination of mutations yielded even higher degrees of TG activity. Reactions with the best mutant, SpChiD-D151N/Y226W/Y222A, led to rapid accumulation of high levels of TG products that remained stable over time. Importantly, the introduction of analogous mutations at the same positions in SmChiA (Y163A equal to Y28A and Y390F similar to Y222A) had similar effects on TG efficiency. Thus, the combination of the decreasing hydrolytic power, subsite affinity, and stability of intermediate states provides a powerful, general strategy for creating hypertransglycosylating mutants of retaining glycoside hydrolases.

  • Organizational Affiliation

    Department of Chemistry, Biotechnology and Food Science , Norwegian University of Life Sciences (NMBU) , P.O. Box 5003, 1432 Ås , Norway.

Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Glycoside hydrolase family 18
A, B
414Serratia proteamaculans 568Mutation(s): 1
Gene Names: Spro_2725
Find proteins for A8GFD6 (Serratia proteamaculans (strain 568))
Explore A8GFD6
Go to UniProtKB:  A8GFD6
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA8GFD6
Sequence Annotations
  • Reference Sequence


Entity ID: 2
MoleculeChains Length2D Diagram Glycosylation3D Interactions
C, D
Glycosylation Resources
GlyTouCan:  G42666HT
GlyCosmos:  G42666HT
GlyGen:  G42666HT
Experimental Data & Validation

Experimental Data

  • Resolution: 1.45 Å
  • R-Value Free: 0.209
  • R-Value Work: 0.175
  • R-Value Observed: 0.177
  • Space Group: C 1 2 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 128.84α = 90
b = 87.57β = 115.49
c = 75.39γ = 90
Software Package:
Software NamePurpose
XDSdata reduction
XDSdata scaling

Structure Validation

View Full Validation Report

Entry History & Funding Information

Deposition Data

Funding OrganizationLocationGrant Number
Research Council of NorwayNorway221576, 247001 and 247730
South-Eastern Norway Regional Health AuthorityNorway2015095
DST-INSPIRE-Faculty awardIndiaIFA16-LSPA 40

Revision History  (Full details and data files)

  • Version 1.0: 2018-07-04
    Type: Initial release
  • Version 1.1: 2018-08-01
    Changes: Data collection, Database references
  • Version 2.0: 2020-07-29
    Type: Remediation
    Reason: Carbohydrate remediation
    Changes: Atomic model, Data collection, Derived calculations, Structure summary
  • Version 2.1: 2024-01-17
    Changes: Data collection, Database references, Refinement description, Structure summary
