6EG0

Crystal structure of Dpr4 Ig1-Ig2 in complex with DIP-Eta Ig1-Ig3


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.9 Å
  • R-Value Free: 0.264
  • R-Value Work: 0.221

wwPDB Validation 3D Report Full Report


This is version 1.4 of the entry. See complete history

Literature

Neuron-Subtype-Specific Expression, Interaction Affinities, and Specificity Determinants of DIP/Dpr Cell Recognition Proteins.

Cosmanescu, F.Katsamba, P.S.Sergeeva, A.P.Ahlsen, G.Patel, S.D.Brewer, J.J.Tan, L.Xu, S.Xiao, Q.Nagarkar-Jaiswal, S.Nern, A.Bellen, H.J.Zipursky, S.L.Honig, B.Shapiro, L.

(2018) Neuron 100: 1385

  • DOI: 10.1016/j.neuron.2018.10.046
  • Primary Citation of Related Structures:

  • PubMed Abstract:
  • Binding between DIP and Dpr neuronal recognition proteins has been proposed to regulate synaptic connections between lamina and medulla neurons in the Drosophila visual system. Each lamina neuron was previously shown to express many Dprs. Here, we de ...

    Binding between DIP and Dpr neuronal recognition proteins has been proposed to regulate synaptic connections between lamina and medulla neurons in the Drosophila visual system. Each lamina neuron was previously shown to express many Dprs. Here, we demonstrate, by contrast, that their synaptic partners typically express one or two DIPs, with binding specificities matched to the lamina neuron-expressed Dprs. A deeper understanding of the molecular logic of DIP/Dpr interaction requires quantitative studies on the properties of these proteins. We thus generated a quantitative affinity-based DIP/Dpr interactome for all DIP/Dpr protein family members. This revealed a broad range of affinities and identified homophilic binding for some DIPs and some Dprs. These data, along with full-length ectodomain DIP/Dpr and DIP/DIP crystal structures, led to the identification of molecular determinants of DIP/Dpr specificity. This structural knowledge, along with a comprehensive set of quantitative binding affinities, provides new tools for functional studies in vivo.


    Organizational Affiliation

    Department of Biological Chemistry, Howard Hughes Medical Institute, David Geffen School of Medicine, University of California, Los Angeles, Los Angeles, CA 90095, USA. Electronic address: lzipursky@mednet.ucla.edu.,Department of Biochemistry and Molecular Biophysics, Columbia University, New York, NY 10032, USA; Zuckerman Mind Brain Behavior Institute, Columbia University, New York, NY 10027, USA.,Department of Molecular and Human Genetics, Howard Hughes Medical Institute, Baylor College of Medicine, Houston, TX 77030, USA.,Janelia Research Campus, Howard Hughes Medical Institute, Ashburn, VA 20147, USA.,Department of Biochemistry and Molecular Biophysics, Columbia University, New York, NY 10032, USA; Zuckerman Mind Brain Behavior Institute, Columbia University, New York, NY 10027, USA. Electronic address: lss8@columbia.edu.,Department of Biochemistry and Molecular Biophysics, Columbia University, New York, NY 10032, USA; Zuckerman Mind Brain Behavior Institute, Columbia University, New York, NY 10027, USA; Howard Hughes Medical Institute, Columbia University, New York, NY 10032, USA; Department of Systems Biology, Columbia University, New York, NY 10032, USA.,Department of Biochemistry and Molecular Biophysics, Columbia University, New York, NY 10032, USA; Zuckerman Mind Brain Behavior Institute, Columbia University, New York, NY 10027, USA; Howard Hughes Medical Institute, Columbia University, New York, NY 10032, USA.,Department of Biochemistry and Molecular Biophysics, Columbia University, New York, NY 10032, USA; Zuckerman Mind Brain Behavior Institute, Columbia University, New York, NY 10027, USA; Division of Gastroenterology, Hepatology and Nutrition, Boston Children's Hospital, Boston, MA 02115, USA.,Department of Biological Chemistry, Howard Hughes Medical Institute, David Geffen School of Medicine, University of California, Los Angeles, Los Angeles, CA 90095, USA.,Department of Biochemistry and Molecular Biophysics, Columbia University, New York, NY 10032, USA; Zuckerman Mind Brain Behavior Institute, Columbia University, New York, NY 10027, USA; Howard Hughes Medical Institute, Columbia University, New York, NY 10032, USA; Department of Systems Biology, Columbia University, New York, NY 10032, USA; Department of Medicine, Columbia University, New York, NY 10032, USA. Electronic address: bh6@columbia.edu.




Macromolecules

Find similar proteins by: Sequence  |  Structure

Entity ID: 1
MoleculeChainsSequence LengthOrganismDetails
Defective proboscis extension response 4
A
220Drosophila melanogasterMutation(s): 0
Gene Names: dpr4 (CG12593, CG14707, CT34497, Dmel\CG33512, Dpr-4, Dpr4, dpr4-RA)
Find proteins for Q59DX6 (Drosophila melanogaster)
Go to UniProtKB:  Q59DX6
Entity ID: 2
MoleculeChainsSequence LengthOrganismDetails
Dpr-interacting protein eta, isoform B
B
314Drosophila melanogasterMutation(s): 0
Gene Names: DIP-eta (14010, CT33567, Dmel\CG14010)
Find proteins for Q9VMN9 (Drosophila melanogaster)
Go to UniProtKB:  Q9VMN9
Small Molecules
Ligands 7 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
ACT
Query on ACT

Download SDF File
Download CCD File
B
ACETATE ION
C2 H3 O2
QTBSBXVTEAMEQO-UHFFFAOYSA-M
 Ligand Interaction
MAN
Query on MAN

Download SDF File
Download CCD File
B
ALPHA-D-MANNOSE
C6 H12 O6
WQZGKKKJIJFFOK-PQMKYFCFSA-N
 Ligand Interaction
FUC
Query on FUC

Download SDF File
Download CCD File
A, B
ALPHA-L-FUCOSE
C6 H12 O5
SHZGCJCMOBCMKK-SXUWKVJYSA-N
 Ligand Interaction
EDO
Query on EDO

Download SDF File
Download CCD File
B
1,2-ETHANEDIOL
ETHYLENE GLYCOL
C2 H6 O2
LYCAIKOWRPUZTN-UHFFFAOYSA-N
 Ligand Interaction
BMA
Query on BMA

Download SDF File
Download CCD File
A, B
BETA-D-MANNOSE
C6 H12 O6
WQZGKKKJIJFFOK-RWOPYEJCSA-N
 Ligand Interaction
PEG
Query on PEG

Download SDF File
Download CCD File
B
DI(HYDROXYETHYL)ETHER
C4 H10 O3
MTHSVFCYNBDYFN-UHFFFAOYSA-N
 Ligand Interaction
NAG
Query on NAG

Download SDF File
Download CCD File
A, B
N-ACETYL-D-GLUCOSAMINE
C8 H15 N O6
OVRNDRQMDRJTHS-FMDGEEDCSA-N
 Ligand Interaction
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.9 Å
  • R-Value Free: 0.264
  • R-Value Work: 0.221
  • Space Group: P 31 2 1
Unit Cell:
Length (Å)Angle (°)
a = 94.294α = 90.00
b = 94.294β = 90.00
c = 212.463γ = 120.00
Software Package:
Software NamePurpose
XDSdata reduction
PHASERphasing
PHENIXrefinement
Aimlessdata scaling

Structure Validation

View Full Validation Report or Ramachandran Plots



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)United States--

Revision History

  • Version 1.0: 2018-11-28
    Type: Initial release
  • Version 1.1: 2018-12-19
    Type: Data collection, Database references
  • Version 1.2: 2019-01-02
    Type: Data collection, Database references
  • Version 1.3: 2019-08-21
    Type: Data collection, Structure summary
  • Version 1.4: 2020-01-01
    Type: Author supporting evidence, Data collection
