Triosephosphate isomerase of Synechocystis in complex with 2-Phosphoglycolic acid

Experimental Data Snapshot

  • Resolution: 1.78 Å
  • R-Value Free: 0.190
  • R-Value Work: 0.154
  • R-Value Observed: 0.156

wwPDB Validation   3D Report Full Report

Ligand Structure Quality Assessment

This is version 1.3 of the entry. See complete history


Structural Basis for the Limited Response to Oxidative and Thiol-Conjugating Agents by Triosephosphate Isomerase From the Photosynthetic BacteriaSynechocystis.

Castro-Torres, E.Jimenez-Sandoval, P.Fernandez-de Gortari, E.Lopez-Castillo, M.Baruch-Torres, N.Lopez-Hidalgo, M.Peralta-Castro, A.Diaz-Quezada, C.Sotelo-Mundo, R.R.Benitez-Cardoza, C.G.Espinoza-Fonseca, L.M.Ochoa-Leyva, A.Brieba, L.G.

(2018) Front Mol Biosci 5: 103-103

  • DOI: https://doi.org/10.3389/fmolb.2018.00103
  • Primary Citation of Related Structures:

  • PubMed Abstract:

    In plants, the ancestral cyanobacterial triosephosphate isomerase (TPI) was replaced by a duplicated version of the cytosolic TPI. This isoform acquired a transit peptide for chloroplast localization and functions in the Calvin-Benson cycle. To gain insight into the reasons for this gene replacement in plants, we characterized the TPI from the photosynthetic bacteria Synechocystis (SyTPI). SyTPI presents typical TPI enzyme kinetics profiles and assembles as a homodimer composed of two subunits that arrange in a (β-α) 8 fold. We found that oxidizing agents diamide (DA) and H 2 O 2 , as well as thiol-conjugating agents such as oxidized glutathione (GSSG) and methyl methanethiosulfonate (MMTS), do not inhibit the catalytic activity of SyTPI at concentrations required to inactivate plastidic and cytosolic TPIs from the plant model Arabidopsis thaliana (AtpdTPI and AtcTPI, respectively). The crystal structure of SyTPI revealed that each monomer contains three cysteines, C47, C127, and C176; however only the thiol group of C176 is solvent exposed. While AtcTPI and AtpdTPI are redox-regulated by chemical modifications of their accessible and reactive cysteines, we found that C176 of SyTPI is not sensitive to redox modification in vitro . Our data let us postulate that SyTPI was replaced by a eukaryotic TPI, because the latter contains redox-sensitive cysteines that may be subject to post-translational modifications required for modulating TPI's enzymatic activity.

  • Organizational Affiliation

    Departamento de Microbiología Molecular, Instituto de Biotecnología, Universidad Nacional Autónoma de México, Cuernavaca, Mexico.

Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Triosephosphate isomerase
A, B
245Synechocystis sp. PCC 6803 substr. KazusaMutation(s): 0
Gene Names: tpiAtpislr0783
Find proteins for Q59994 (Synechocystis sp. (strain PCC 6803 / Kazusa))
Explore Q59994
Go to UniProtKB:  Q59994
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ59994
Sequence Annotations
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Resolution: 1.78 Å
  • R-Value Free: 0.190
  • R-Value Work: 0.154
  • R-Value Observed: 0.156
  • Space Group: P 21 21 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 72.88α = 90
b = 73.099β = 90
c = 85.175γ = 90
Software Package:
Software NamePurpose
d*TREKdata reduction
Aimlessdata scaling
PDB_EXTRACTdata extraction

Structure Validation

View Full Validation Report

Ligand Structure Quality Assessment

Entry History & Funding Information

Deposition Data

Funding OrganizationLocationGrant Number
Consejo Nacional de Ciencia y Tecnologia (CONACYT)MexicoFronteras de la Ciencia 13

Revision History  (Full details and data files)

  • Version 1.0: 2018-12-19
    Type: Initial release
  • Version 1.1: 2018-12-26
    Changes: Data collection, Database references
  • Version 1.2: 2020-01-15
    Changes: Author supporting evidence
  • Version 1.3: 2023-10-04
    Changes: Data collection, Database references, Derived calculations, Refinement description
