6A15

Structure of CYP90B1 in complex with cholesterol


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.79 Å
  • R-Value Free: 0.187
  • R-Value Work: 0.158
  • R-Value Observed: 0.159

wwPDB Validation 3D Report Full Report


This is version 1.1 of the entry. See complete history


Literature

Structural insights into a key step of brassinosteroid biosynthesis and its inhibition.

Fujiyama, K.Hino, T.Kanadani, M.Watanabe, B.Jae Lee, H.Mizutani, M.Nagano, S.

(2019) Nat Plants 5: 589-594

  • DOI: 10.1038/s41477-019-0436-6
  • Primary Citation of Related Structures:
    6A17, 6A16, 6A18, 6A15

  • PubMed Abstract:
  • Brassinosteroids (BRs) are essential plant steroid hormones that regulate plant growth and development 1 . The most potent BR, brassinolide, is produced by addition of many oxygen atoms to campesterol by several cytochrome P450 monooxygena ...

    Brassinosteroids (BRs) are essential plant steroid hormones that regulate plant growth and development 1 . The most potent BR, brassinolide, is produced by addition of many oxygen atoms to campesterol by several cytochrome P450 monooxygenases (CYPs). CYP90B1 (also known as DWF4) catalyses the 22(S)-hydroxylation of campesterol and is the first and rate-limiting enzyme at the branch point of the biosynthetic pathway from sterols to BRs 2 . Here we show the crystal structure of Arabidopsis thaliana CYP90B1 complexed with cholesterol as a substrate. The substrate-binding conformation explains the stereoselective introduction of a hydroxy group at the 22S position, facilitating hydrogen bonding of brassinolide with the BR receptor 3-5 . We also determined the crystal structures of CYP90B1 complexed with uniconazole 6,7 or brassinazole 8 , which inhibit BR biosynthesis. The two inhibitors are structurally similar; however, their binding conformations are unexpectedly different. The shape and volume of the active site pocket varies depending on which inhibitor or substrate is bound. These crystal structures of plant CYPs that function as membrane-anchored enzymes and exhibit structural plasticity can inform design of novel inhibitors targeting plant membrane-bound CYPs, including those involved in BR biosynthesis, which could then be used as plant growth regulators and agrochemicals.


    Organizational Affiliation

    Center for Research on Green Sustainable Chemistry, Tottori University, Tottori, Japan. snagano@tottori-u.ac.jp.



Macromolecules
Find similar proteins by:  (by identity cutoff)  |  Structure
Entity ID: 1
MoleculeChainsSequence LengthOrganismDetailsImage
Cytochrome P450 90B1A456Arabidopsis thalianaMutation(s): 1
Gene Names: CYP90B1DWF4At3g50660T3A5.40
EC: 1.14
Find proteins for O64989 (Arabidopsis thaliana)
Explore O64989
Go to UniProtKB:  O64989
Protein Feature View
Expand
 ( Mouse scroll to zoom / Hold left click to move )
  • Reference Sequence
Small Molecules
Ligands 4 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
HEM
Query on HEM

Download CCD File
A
PROTOPORPHYRIN IX CONTAINING FE
C34 H32 Fe N4 O4
KABFMIBPWCXCRK-RGGAHWMASA-L
 Ligand Interaction
CLR
Query on CLR

Download CCD File
A
CHOLESTEROL
C27 H46 O
HVYWMOMLDIMFJA-DPAQBDIFSA-N
 Ligand Interaction
GOL
Query on GOL

Download CCD File
A
GLYCEROL
C3 H8 O3
PEDCQBHIVMGVHV-UHFFFAOYSA-N
 Ligand Interaction
CL
Query on CL

Download CCD File
A
CHLORIDE ION
Cl
VEXZGXHMUGYJMC-UHFFFAOYSA-M
 Ligand Interaction
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.79 Å
  • R-Value Free: 0.187
  • R-Value Work: 0.158
  • R-Value Observed: 0.159
  • Space Group: P 21 21 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 76.818α = 90
b = 80.574β = 90
c = 83.031γ = 90
Software Package:
Software NamePurpose
PHENIXrefinement
XDSdata reduction
XDSdata scaling
Aimlessdata scaling
PHASERphasing
Cootmodel building

Structure Validation

View Full Validation Report



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Japan Society for the Promotion of ScienceJapan17H05444

Revision History

  • Version 1.0: 2019-06-12
    Type: Initial release
  • Version 1.1: 2019-07-10
    Changes: Data collection, Database references
