6Z6Z | pdb_00006z6z

Crystal structure of an Anticalin directed towards colchicine without ligand

PDB DOI: https://doi.org/10.2210/pdb6Z6Z/pdb

Classification: TRANSPORT PROTEIN
Organism(s): Homo sapiens
Expression System: Escherichia coli
Mutation(s): Yes

Deposited: 2020-05-29 Released: 2021-06-09
Deposition Author(s): Skerra, A., Eichinger, A.
Funding Organization(s): Helmholtz Association

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.78 Å
R-Value Free:
0.259 (Depositor), 0.275 (DCC)
R-Value Work:
0.201 (Depositor)
R-Value Observed:
0.204 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 6Z6Z

This is version 1.2 of the entry. See complete history.

Literature

Structural rearrangement in the ligand pocket of Colchicalin upon Colchicine binding

Ilyukhina, E., Eichinger, A., Skerra, A.

To be published.

Macromolecule Content

Total Structure Weight: 21.54 kDa
Atom Count: 1,466
Modeled Residue Count: 172
Deposited Residue Count: 187
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Neutrophil gelatinase-associated lipocalin	A	187	Homo sapiens	Mutation(s): 24 Gene Names: LCN2, HNL, NGAL
UniProt & NIH Common Fund Data Resources
Find proteins for P80188 (Homo sapiens) Explore P80188 Go to UniProtKB: P80188
PHAROS: P80188 GTEx: ENSG00000148346
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	P80188
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
CA (Subject of Investigation/LOI) Query on CA Download:Ideal Coordinates CCD File SDF format, chain B [auth A] MOL2 format, chain B [auth A] mmCIF format, chain B [auth A]	B [auth A]	CALCIUM ION Ca BHPQYMZQTOCNFJ-UHFFFAOYSA-N		Interactions Focus chain B [auth A] Interactions & Density Focus chain B [auth A]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.78 Å
R-Value Free: 0.259 (Depositor), 0.275 (DCC)
R-Value Work: 0.201 (Depositor)
R-Value Observed: 0.204 (Depositor)

Space Group: I 2 2 2

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 38.557	α = 90
b = 75.579	β = 90
c = 116.12	γ = 90

Software Package:

Software Name	Purpose
MOSFLM	data reduction
SCALA	data scaling
PHASER	phasing
REFMAC	refinement
PDB_EXTRACT	data extraction

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Released Date: 2021-06-09

Deposition Author(s):

Funding Organization	Location	Grant Number
Helmholtz Association	Germany	--

Revision History (Full details and data files)

Version 1.0: 2021-06-09
Type: Initial release
Version 1.1: 2024-01-24
Changes: Data collection, Database references, Refinement description
Version 1.2: 2024-10-16
Changes: Structure summary
