6Z4V

Crystal structure of the neurotensin receptor 1 (NTSR1-H4bmx) in complex with NTS8-13


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.60 Å
  • R-Value Free: 0.272
  • R-Value Work: 0.256

wwPDB Validation   3D Report Full Report


This is version 1.3 of the entry. See complete history


Literature

Complexes of the neurotensin receptor 1 with small-molecule ligands reveal structural determinants of full, partial, and inverse agonism.

Deluigi, M.Klipp, A.Klenk, C.Merklinger, L.Eberle, S.A.Morstein, L.Heine, P.Mittl, P.R.E.Ernst, P.Kamenecka, T.M.He, Y.Vacca, S.Egloff, P.Honegger, A.Pluckthun, A.

(2021) Sci Adv 7

  • DOI: https://doi.org/10.1126/sciadv.abe5504
  • Primary Citation of Related Structures:
    6YVR, 6Z4Q, 6Z4S, 6Z4V, 6Z66, 6Z8N, 6ZA8, 6ZIN

  • PubMed Abstract:

    Neurotensin receptor 1 (NTSR1) and related G protein-coupled receptors of the ghrelin family are clinically unexploited, and several mechanistic aspects of their activation and inactivation have remained unclear. Enabled by a new crystallization design, we present five new structures: apo-state NTSR1 as well as complexes with nonpeptide inverse agonists SR48692 and SR142948A, partial agonist RTI-3a, and the novel full agonist SRI-9829, providing structural rationales on how ligands modulate NTSR1. The inverse agonists favor a large extracellular opening of helices VI and VII, undescribed so far for NTSR1, causing a constriction of the intracellular portion. In contrast, the full and partial agonists induce a binding site contraction, and their efficacy correlates with the ability to mimic the binding mode of the endogenous agonist neurotensin. Providing evidence of helical and side-chain rearrangements modulating receptor activation, our structural and functional data expand the mechanistic understanding of NTSR1 and potentially other peptidergic receptors.


  • Organizational Affiliation

    Department of Biochemistry, University of Zurich, Winterthurerstrasse 190, CH-8057 Zurich, Switzerland.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Neurotensin receptor type 1,Neurotensin receptor type 1,DARPinA [auth AAA]482Rattus norvegicussynthetic construct
This entity is chimeric
Mutation(s): 22
Gene Names: Ntsr1Ntsr
Membrane Entity: Yes
UniProt
Find proteins for P20789 (Rattus norvegicus)
Explore P20789
Go to UniProtKB:  P20789
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP20789
Sequence Annotations
Expand
  • Reference Sequence

Find similar proteins by:  Sequence   |   3D Structure

Entity ID: 2
MoleculeChains Sequence LengthOrganismDetailsImage
ARG-PRO-TYR-ILE-LEUB [auth BBB]6Rattus norvegicusMutation(s): 0
Sequence Annotations
Expand
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.60 Å
  • R-Value Free: 0.272
  • R-Value Work: 0.256
  • Space Group: C 1 2 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 69.223α = 90
b = 77.533β = 107.219
c = 111.858γ = 90
Software Package:
Software NamePurpose
REFMACrefinement
XDSdata reduction
Aimlessdata scaling
PHASERphasing

Structure Validation

View Full Validation Report



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Swiss National Science FoundationSwitzerland31003A_182334

Revision History  (Full details and data files)

  • Version 1.0: 2021-02-10
    Type: Initial release
  • Version 1.1: 2021-02-24
    Changes: Database references
  • Version 1.2: 2021-03-17
    Changes: Database references
  • Version 1.3: 2024-01-24
    Changes: Data collection, Database references, Derived calculations, Refinement description
