6YGC

Crystal structure of the NatC complex bound to Arl3 peptide and CoA


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.99 Å
  • R-Value Free: 0.248
  • R-Value Work: 0.196
  • R-Value Observed: 0.199

wwPDB Validation   3D Report Full Report


Ligand Structure Quality Assessment


This is version 1.2 of the entry. See complete history


Literature

Divergent architecture of the heterotrimeric NatC complex explains N-terminal acetylation of cognate substrates.

Grunwald, S.Hopf, L.V.M.Bock-Bierbaum, T.Lally, C.C.M.Spahn, C.M.T.Daumke, O.

(2020) Nat Commun 11: 5506-5506

  • DOI: https://doi.org/10.1038/s41467-020-19321-8
  • Primary Citation of Related Structures:
    6YGA, 6YGB, 6YGC, 6YGD

  • PubMed Abstract:

    The heterotrimeric NatC complex, comprising the catalytic Naa30 and the two auxiliary subunits Naa35 and Naa38, co-translationally acetylates the N-termini of numerous eukaryotic target proteins. Despite its unique subunit composition, its essential role for many aspects of cellular function and its suggested involvement in disease, structure and mechanism of NatC have remained unknown. Here, we present the crystal structure of the Saccharomyces cerevisiae NatC complex, which exhibits a strikingly different architecture compared to previously described N-terminal acetyltransferase (NAT) complexes. Cofactor and ligand-bound structures reveal how the first four amino acids of cognate substrates are recognized at the Naa30-Naa35 interface. A sequence-specific, ligand-induced conformational change in Naa30 enables efficient acetylation. Based on detailed structure-function studies, we suggest a catalytic mechanism and identify a ribosome-binding patch in an elongated tip region of NatC. Our study reveals how NAT machineries have divergently evolved to N-terminally acetylate specific subsets of target proteins.


  • Organizational Affiliation

    Department of Crystallography, Max Delbrück Center for Molecular Medicine, 13125, Berlin, Germany.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
N-alpha-acetyltransferase 30159Saccharomyces cerevisiaeMutation(s): 0
Gene Names: MAK3NAA30YPR051WYP9499.08
EC: 2.3.1.256
UniProt
Find proteins for Q03503 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore Q03503
Go to UniProtKB:  Q03503
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ03503
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 2
MoleculeChains Sequence LengthOrganismDetailsImage
N-alpha-acetyltransferase 35, NatC auxiliary subunit735Saccharomyces cerevisiaeMutation(s): 0
Gene Names: MAK10NAA35YEL053C
UniProt
Find proteins for Q02197 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore Q02197
Go to UniProtKB:  Q02197
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ02197
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 3
MoleculeChains Sequence LengthOrganismDetailsImage
N-alpha-acetyltransferase 38, NatC auxiliary subunit77Saccharomyces cerevisiaeMutation(s): 0
Gene Names: MAK31NAA38YCR020C-AYCR20C-A
UniProt
Find proteins for P23059 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore P23059
Go to UniProtKB:  P23059
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP23059
Sequence Annotations
Expand
  • Reference Sequence

Find similar proteins by:  Sequence   |   3D Structure

Entity ID: 4
MoleculeChains Sequence LengthOrganismDetailsImage
ADP-ribosylation factor-like protein 310Saccharomyces cerevisiaeMutation(s): 0
UniProt
Find proteins for Q02804 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore Q02804
Go to UniProtKB:  Q02804
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ02804
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 4 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
COA (Subject of Investigation/LOI)
Query on COA

Download Ideal Coordinates CCD File
E [auth A]COENZYME A
C21 H36 N7 O16 P3 S
RGJOEKWQDUBAIZ-IBOSZNHHSA-N
IOD
Query on IOD

Download Ideal Coordinates CCD File
H [auth B]
I [auth B]
J [auth B]
K [auth B]
L [auth B]
H [auth B],
I [auth B],
J [auth B],
K [auth B],
L [auth B],
M [auth B],
N [auth B],
W [auth C]
IODIDE ION
I
XMBWDFGMSWQBCA-UHFFFAOYSA-M
GOL
Query on GOL

Download Ideal Coordinates CCD File
G [auth A],
T [auth B],
U [auth B],
V [auth B]
GLYCEROL
C3 H8 O3
PEDCQBHIVMGVHV-UHFFFAOYSA-N
CL
Query on CL

Download Ideal Coordinates CCD File
F [auth A]
O [auth B]
P [auth B]
Q [auth B]
R [auth B]
F [auth A],
O [auth B],
P [auth B],
Q [auth B],
R [auth B],
S [auth B]
CHLORIDE ION
Cl
VEXZGXHMUGYJMC-UHFFFAOYSA-M
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.99 Å
  • R-Value Free: 0.248
  • R-Value Work: 0.196
  • R-Value Observed: 0.199
  • Space Group: P 21 21 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 48.303α = 90
b = 139.724β = 90
c = 166.824γ = 90
Software Package:
Software NamePurpose
XDSdata reduction
XSCALEdata scaling
PHENIXrefinement
PDB_EXTRACTdata extraction
PHENIXphasing

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
German Research Foundation (DFG)GermanySFB958-A12

Revision History  (Full details and data files)

  • Version 1.0: 2020-10-28
    Type: Initial release
  • Version 1.1: 2020-11-18
    Changes: Database references
  • Version 1.2: 2024-01-24
    Changes: Data collection, Database references, Refinement description
