6Y9L | pdb_00006y9l

Crystal structure of TSWV glycoprotein N ectodomain (sGn)

• PDB DOI: https://doi.org/10.2210/pdb6Y9L/pdb

• Classification: VIRAL PROTEIN
• Organism(s): Orthotospovirus tomatomaculae
• Expression System: Trichoplusia ni
• Mutation(s): No


• Deposited: 2020-03-09 Released: 2020-09-30
• Deposition Author(s): Dessau, M., Bahat, Y.

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 4.10 Å
• R-Value Free:
  0.302 (Depositor), 0.300 (DCC)
• R-Value Work:
  0.277 (Depositor), 0.280 (DCC)
• R-Value Observed:
  0.278 (Depositor)

Literature

Crystal structure of tomato spotted wilt virus G N reveals a dimer complex formation and evolutionary link to animal-infecting viruses

Bahat, Y., Alter, J., Dessau, M.

(2020) Proc Natl Acad Sci U S A 117: 26237

• DOI: https://doi.org/10.1073/pnas.2004657117

Biological Assembly 1

Global Symmetry: Cyclic - C2  (Explore in 3D)
Global Stoichiometry: Homo 2-mer - A2

Biological assembly 1 assigned by authors and generated by PISA (software)

Biological Assembly Evidence: mass spectrometry, cross-linking

Biological Assembly 2

Global Symmetry: Cyclic - C2  (Explore in 3D)
Global Stoichiometry: Homo 2-mer - A2

Biological assembly 2 assigned by authors and generated by PISA (software)

Macromolecule Content

• Total Structure Weight: 132.38 kDa
• Atom Count: 6,325
• Modeled Residue Count: 783
• Deposited Residue Count: 1,152
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Glycoprotein	A [auth B], B [auth D], C [auth A], D [auth C]	288	Orthotospovirus tomatomaculae	Mutation(s): 0  Gene Names: Gn, Gc
UniProt
Find proteins for P36291 (Tomato spotted wilt virus (strain Brazilian Br-01)) Explore P36291  Go to UniProtKB:  P36291
Glycosylation
Glycosylation Sites: 2

Oligosaccharides

Help

Entity ID: 2
Molecule	Chains	Length	2D Diagram	Glycosylation	3D Interactions
beta-D-mannopyranose-(1-4)-2-acetamido-2-deoxy-beta-D-glucopyranose-(1-4)-2-acetamido-2-deoxy-beta-D-glucopyranose	E, G, J	3		N-Glycosylation
Glycosylation Resources
GlyTouCan:  G15407YE GlyCosmos:  G15407YE GlyGen:  G15407YE

Entity ID: 3
Molecule	Chains	Length	2D Diagram	Glycosylation	3D Interactions
2-acetamido-2-deoxy-beta-D-glucopyranose-(1-4)-2-acetamido-2-deoxy-beta-D-glucopyranose	F, H, I, K	2		N-Glycosylation
Glycosylation Resources
GlyTouCan:  G42666HT GlyCosmos:  G42666HT GlyGen:  G42666HT

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
NAG	L [auth C]	2-acetamido-2-deoxy-beta-D-glucopyranose C8 H15 N O6 OVRNDRQMDRJTHS-FMDGEEDCSA-N

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 4.10 Å
• R-Value Free:  0.302 (Depositor), 0.300 (DCC)
• R-Value Work:  0.277 (Depositor), 0.280 (DCC)
• R-Value Observed: 0.278 (Depositor)

Space Group: C 2 2 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 165.992	α = 90
b = 215.878	β = 90
c = 146.368	γ = 90

Software Package:

Software Name	Purpose
PHENIX	refinement
XSCALE	data scaling
PDB_EXTRACT	data extraction
XDS	data reduction
AutoSol	phasing

Structure Validation

Entry History

Deposition Data

• Released Date: 2020-09-30
Deposition Author(s): Dessau, M., Bahat, Y.

Revision History

• Version 1.0: 2020-09-30
  Type: Initial release

• Version 1.1: 2020-10-21
  Changes: Database references
• Version 1.2: 2020-10-28
  Changes: Database references
• Version 1.3: 2021-04-14
  Changes: Database references
• Version 1.4: 2024-10-16
  Changes: Data collection, Database references, Structure summary
