6XLD | pdb_00006xld

Full-length Hsc82 in complex with Aha1 CTD in the presence of AMPPNP

PDB DOI: https://doi.org/10.2210/pdb6XLD/pdb
EM Map EMD-22240: EMDB EMDataResource

Classification: CHAPERONE
Organism(s): Saccharomyces cerevisiae S288C
Expression System: Escherichia coli
Mutation(s): No

Deposited: 2020-06-28 Released: 2021-06-30
Deposition Author(s): Liu, Y.X., Sun, M., Myasnikov, A.G., Elnatan, D., Agard, D.A.
Funding Organization(s): Howard Hughes Medical Institute, American Heart Association

Experimental Data Snapshot

Method: ELECTRON MICROSCOPY
Resolution: 3.66 Å
Aggregation State: PARTICLE
Reconstruction Method: SINGLE PARTICLE

wwPDB Validation 3D Report Full Report

Validation slider image for 6XLD

This is version 1.1 of the entry. See complete history.

Literature

Full-length Hsc82 in complex with Aha1 CTD in the presence of AMPPNP

Liu, Y.X., Sun, M., Myasnikov, A.G., Elnatan, D., Agard, D.A.

To be published.

Macromolecule Content

Total Structure Weight: 202.55 kDa
Atom Count: 10,992
Modeled Residue Count: 1,349
Deposited Residue Count: 1,760
Unique protein chains: 2

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
ATP-dependent molecular chaperone HSC82	A, B	705	Saccharomyces cerevisiae S288C	Mutation(s): 0 Gene Names: HSC82, YMR186W, YM8010.16
UniProt
Find proteins for P15108 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c)) Explore P15108 Go to UniProtKB: P15108
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	P15108
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

Entity ID: 2
Molecule	Chains	Sequence Length	Organism	Details	Image
Hsp90 co-chaperone AHA1	C	350	Saccharomyces cerevisiae S288C	Mutation(s): 0 Gene Names: AHA1, YDR214W, YD8142.16, YD8142B.06
UniProt
Find proteins for Q12449 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c)) Explore Q12449 Go to UniProtKB: Q12449
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	Q12449
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
ANP Query on ANP Download:Ideal Coordinates CCD File SDF format, chain F [auth B] SDF format, chain D [auth A] MOL2 format, chain F [auth B] MOL2 format, chain D [auth A] mmCIF format, chain F [auth B] mmCIF format, chain D [auth A]	D [auth A], F [auth B]	PHOSPHOAMINOPHOSPHONIC ACID-ADENYLATE ESTER C₁₀ H₁₇ N₆ O₁₂ P₃ PVKSNHVPLWYQGJ-KQYNXXCUSA-N		Interactions Focus chain D [auth A] Focus chain F [auth B] Interactions & Density Focus chain D [auth A] Focus chain F [auth B]
MG Query on MG Download:Ideal Coordinates CCD File SDF format, chain G [auth B] SDF format, chain E [auth A] MOL2 format, chain G [auth B] MOL2 format, chain E [auth A] mmCIF format, chain G [auth B] mmCIF format, chain E [auth A]	E [auth A], G [auth B]	MAGNESIUM ION Mg JLVVSXFLKOJNIY-UHFFFAOYSA-N		Interactions Focus chain E [auth A] Focus chain G [auth B] Interactions & Density Focus chain E [auth A] Focus chain G [auth B]

Binding Affinity Annotations
ID	Source	Binding Affinity
ANP	BindingDB: 6XLD	ΔG: min: -2.35e+1, max: 14.9 (kJ/mol) from 18 assay(s)

Experimental Data & Validation

Experimental Data

Method: ELECTRON MICROSCOPY
Resolution: 3.66 Å
Aggregation State: PARTICLE
Reconstruction Method: SINGLE PARTICLE

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Released Date: 2021-06-30

Deposition Author(s):

Myasnikov, A.G.

Funding Organization	Location	Grant Number
Howard Hughes Medical Institute	United States	--
American Heart Association	United States	--

Revision History (Full details and data files)

Version 1.0: 2021-06-30
Type: Initial release
Version 1.1: 2024-03-06
Changes: Data collection, Database references
