6WO5

Structure of Hepatitis C Virus Envelope Glycoprotein E2 core from genotype 1a bound to neutralizing antibody 212.1.1 and non neutralizing antibody E1


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.62 Å
  • R-Value Free: 0.250
  • R-Value Work: 0.203
  • R-Value Observed: 0.205

wwPDB Validation   3D Report Full Report


Ligand Structure Quality Assessment


This is version 1.0 of the entry. See complete history


Literature

An alternate conformation of HCV E2 neutralizing face as an additional vaccine target.

Tzarum, N.Giang, E.Kadam, R.U.Chen, F.Nagy, K.Augestad, E.H.Velazquez-Moctezuma, R.Keck, Z.Y.Hua, Y.Stanfield, R.L.Dreux, M.Prentoe, J.Foung, S.K.H.Bukh, J.Wilson, I.A.Law, M.

(2020) Sci Adv 6: eabb5642-eabb5642

  • DOI: 10.1126/sciadv.abb5642
  • Primary Citation of Related Structures:
    6WO3, 6WO4, 6WO5, 6WOQ, 6WOR, 6WOS

  • PubMed Abstract:
  • To achieve global elimination of hepatitis C virus (HCV), an effective cross-genotype vaccine is needed. The HCV envelope glycoprotein E2 is the main target for neutralizing antibodies (nAbs), which aid in HCV clearance and protection. E2 is structurally flexible and functions in engaging host receptors ...

    To achieve global elimination of hepatitis C virus (HCV), an effective cross-genotype vaccine is needed. The HCV envelope glycoprotein E2 is the main target for neutralizing antibodies (nAbs), which aid in HCV clearance and protection. E2 is structurally flexible and functions in engaging host receptors. Many nAbs bind to the "neutralizing face" on E2, including several broadly nAbs encoded by the V H 1-69 germline gene family that bind to a similar conformation (A) of this face. Here, a previously unknown conformation (B) of the neutralizing face is revealed in crystal structures of two of four additional E2-V H 1-69 nAb complexes. In this conformation, the E2 front-layer region is displaced upon antibody binding, exposing residues in the back layer for direct antibody interaction. This E2 B structure may represent another conformational state in the viral entry process that is susceptible to antibody neutralization and thus provide a new target for rational vaccine development.


    Organizational Affiliation

    Department of Immunology and Microbiology, The Scripps Research Institute, La Jolla, CA 92037, USA.



Macromolecules
Find similar proteins by:  (by identity cutoff)  |  Structure
Entity ID: 1
MoleculeChainsSequence LengthOrganismDetailsImage
Fab E1 heavy chainA, C227Homo sapiensMutation(s): 0
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  Structure
Entity ID: 2
MoleculeChainsSequence LengthOrganismDetailsImage
Fab E1 light chainB, D221Homo sapiensMutation(s): 0
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  Structure
Entity ID: 3
MoleculeChainsSequence LengthOrganismDetailsImage
Fab 212.1.1 heavy chainG, E [auth H]230Homo sapiensMutation(s): 0
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  Structure
Entity ID: 4
MoleculeChainsSequence LengthOrganismDetailsImage
Fab 212.1.1 light chainH [auth I], F [auth L]214Homo sapiensMutation(s): 0
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  Structure
Entity ID: 5
MoleculeChainsSequence LengthOrganismDetailsImage
Envelope glycoprotein E2I [auth E], J [auth F]191Hepatitis C virus (isolate H)Mutation(s): 0
EC: 3.4.22 (UniProt), 3.4.21.98 (UniProt), 3.6.1.15 (UniProt), 3.6.4.13 (UniProt), 2.7.7.48 (UniProt)
UniProt
Find proteins for P27958 (Hepatitis C virus genotype 1a (isolate H77))
Explore P27958
Go to UniProtKB:  P27958
Protein Feature View
Expand
  • Reference Sequence
Oligosaccharides

Help

Entity ID: 6
MoleculeChainsChain Length2D DiagramGlycosylation3D Interactions
beta-D-mannopyranose-(1-4)-2-acetamido-2-deoxy-beta-D-glucopyranose-(1-4)-2-acetamido-2-deoxy-beta-D-glucopyranoseK [auth J], N3N-Glycosylation Oligosaccharides Interaction
Glycosylation Resources
GlyTouCan:  G15407YE
GlyCosmos:  G15407YE
GlyGen:  G15407YE
Entity ID: 7
MoleculeChainsChain Length2D DiagramGlycosylation3D Interactions
2-acetamido-2-deoxy-beta-D-glucopyranose-(1-4)-2-acetamido-2-deoxy-beta-D-glucopyranoseL [auth K], M2N-Glycosylation Oligosaccharides Interaction
Glycosylation Resources
GlyTouCan:  G42666HT
GlyCosmos:  G42666HT
GlyGen:  G42666HT
Entity ID: 8
MoleculeChainsChain Length2D DiagramGlycosylation3D Interactions
alpha-D-mannopyranose-(1-3)-[alpha-D-mannopyranose-(1-6)]beta-D-mannopyranose-(1-4)-2-acetamido-2-deoxy-beta-D-glucopyranose-(1-4)-2-acetamido-2-deoxy-beta-D-glucopyranoseO5N-Glycosylation Oligosaccharides Interaction
Glycosylation Resources
GlyTouCan:  G22768VO
GlyCosmos:  G22768VO
GlyGen:  G22768VO
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.62 Å
  • R-Value Free: 0.250
  • R-Value Work: 0.203
  • R-Value Observed: 0.205
  • Space Group: P 1 21 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 55.793α = 90
b = 242.204β = 98.31
c = 100.729γ = 90
Software Package:
Software NamePurpose
PHENIXrefinement
HKL-2000data reduction
Blu-Icedata collection
SCALEPACKdata scaling
PHASERphasing

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
National Institutes of Health/National Institute Of Allergy and Infectious Diseases (NIH/NIAID)United StatesAl123365
National Institutes of Health/National Institute Of Allergy and Infectious Diseases (NIH/NIAID)United StatesAl106005

Revision History  (Full details and data files)

  • Version 1.0: 2020-08-19
    Type: Initial release
