Biological Assembly 1

 3D View: Structure | Electron Density

Global Symmetry: Cyclic - C2  (3D View)
Global Stoichiometry: Hetero 4-mer - A2B2

Biological assembly 1 assigned by authors and generated by PISA (software)

Macromolecule Content

• Total Structure Weight: 23.04 kDa
• Atom Count: 1507
• Residue Count: 195
• Unique protein chains: 2

6WIQ

Crystal structure of the co-factor complex of NSP7 and the C-terminal domain of NSP8 from SARS CoV-2

• DOI: 10.2210/pdb6WIQ/pdb

• Classification: VIRAL PROTEIN
• Organism(s): Severe acute respiratory syndrome coronavirus 2
• Expression System: Escherichia coli BL21(DE3)
• Mutation(s): No


• Deposited: 2020-04-10 Released: 2020-04-22
• Deposition Author(s): Wilamowski, M., Kim, Y., Jedrzejczak, R., Maltseva, N., Endres, M., Godzik, A., Michalska, K., Joachimiak, A., Center for Structural Genomics of Infectious Diseases (CSGID)
• Funding Organization(s): National Institutes of Health/National Institute Of Allergy and Infectious Diseases (NIH/NIAID)

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 2.85 Å
• R-Value Free: 0.252
• R-Value Work: 0.208
• R-Value Observed: 0.210

Literature

Crystal structure of the co-factor complex of NSP7 and the C-terminal domain of NSP8 from SARS CoV-2

Wilamowski, M., Kim, Y., Jedrzejczak, R., Maltseva, N., Endres, M., Godzik, A., Michalska, K., Joachimiak, A.

To be published.

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Non-structural protein 7	A	86	Severe acute respiratory syndrome coronavirus 2	Mutation(s): 0  Gene Names: rep, 1a-1b EC: 3.4.19.12 (UniProt), 3.4.22 (UniProt), 3.4.22.69 (UniProt), 2.7.7.48 (UniProt), 3.6.4.12 (UniProt), 3.6.4.13 (UniProt), 3.1.13 (UniProt), 3.1 (UniProt), 2.1.1 (UniProt)
Find proteins for P0DTD1 (Severe acute respiratory syndrome coronavirus 2) Explore P0DTD1  Go to UniProtKB:  P0DTD1

Entity ID: 2
Molecule	Chains	Sequence Length	Organism	Details	Image
Non-structural protein 8	B	122	Severe acute respiratory syndrome coronavirus 2	Mutation(s): 0  Gene Names: rep, 1a-1b EC: 3.4.19.12 (UniProt), 3.4.22 (UniProt), 3.4.22.69 (UniProt), 2.7.7.48 (UniProt), 3.6.4.12 (UniProt), 3.6.4.13 (UniProt), 3.1.13 (UniProt), 3.1 (UniProt), 2.1.1 (UniProt)
Find proteins for P0DTD1 (Severe acute respiratory syndrome coronavirus 2) Explore P0DTD1  Go to UniProtKB:  P0DTD1

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 2.85 Å
• R-Value Free: 0.252
• R-Value Work: 0.208
• R-Value Observed: 0.210
• Space Group: C 2 2 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 52.153	α = 90
b = 70.782	β = 90
c = 115.455	γ = 90

Software Package:

Software Name	Purpose
PHENIX	refinement
HKL-3000	data reduction
HKL-3000	data scaling
HKL-3000	phasing
MOLREP	phasing
Coot	model building

Structure Validation

Entry History & Funding Information

Deposition Data

• Deposited Date: 2020-04-10
• Released Date: 2020-04-22
Deposition Author(s): Wilamowski, M., Kim, Y., Jedrzejczak, R., Maltseva, N., Endres, M., Godzik, A., Michalska, K., Joachimiak, A., Center for Structural Genomics of Infectious Diseases (CSGID)

---

Funding Organization	Location	Grant Number
National Institutes of Health/National Institute Of Allergy and Infectious Diseases (NIH/NIAID)	United States	--

Revision History

• Version 1.0: 2020-04-22
  Type: Initial release

• Version 2.0: 2020-05-06
  Changes: Advisory, Atomic model, Data collection, Database references, Derived calculations, Refinement description, Source and taxonomy, Structure summary
• Version 2.1: 2021-01-27
  Changes: Structure summary
