6WHK | pdb_00006whk

Minimally mutated anti-influenza broadly neutralizing antibody

PDB DOI: https://doi.org/10.2210/pdb6WHK/pdb

Classification: VIRAL PROTEIN/Immune System
Organism(s): Influenza A virus (A/Beijing/262/1995(H1N1)), Homo sapiens
Expression System: Trichoplusia ni, Homo sapiens
Mutation(s): No

Deposited: 2020-04-08 Released: 2021-04-14
Deposition Author(s): Bajic, G., Schmidt, A.G.
Funding Organization(s): National Institutes of Health/National Institute Of Allergy and Infectious Diseases (NIH/NIAID)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.60 Å
R-Value Free:
0.268 (Depositor), 0.269 (DCC)
R-Value Work:
0.218 (Depositor), 0.219 (DCC)
R-Value Observed:
0.220 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

This is version 1.2 of the entry. See complete history.

Literature

Minimally mutated anti-influenza broadly neutralizing antibody

Bajic, G., Schmidt, A.G.

To be published.

Macromolecule Content

Total Structure Weight: 75.56 kDa
Atom Count: 5,075
Modeled Residue Count: 644
Deposited Residue Count: 689
Unique protein chains: 3

Macromolecules

Find similar proteins by:

| 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Hemagglutinin HA1 chain	A	230	Influenza A virus (A/Beijing/262/1995(H1N1))	Mutation(s): 0 Gene Names: HA
UniProt
Find proteins for B4UPF7 (Influenza A virus) Explore B4UPF7 Go to UniProtKB: B4UPF7
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	B4UPF7
Glycosylation
Glycosylation Sites: 1	Glycosylation Focus chain A
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

| 3D Structure

Entity ID: 2
Molecule	Chains	Sequence Length	Organism	Details	Image
Fab Heavy Chain	B [auth C]	240	Homo sapiens	Mutation(s): 0

Find similar proteins by:

| 3D Structure

Entity ID: 3
Molecule	Chains	Sequence Length	Organism	Details	Image
Fab Light Chain	C [auth B]	219	Homo sapiens	Mutation(s): 0

Oligosaccharides

Help

Entity ID: 4
Molecule	Chains	Length	2D Diagram	Glycosylation	D Interactions
2-acetamido-2-deoxy-beta-D-glucopyranose-(1-4)-2-acetamido-2-deoxy-beta-D-glucopyranose	D	2		N-Glycosylation	Interactions Focus chain D Interactions & Density Focus chain D
Glycosylation Resources
GlyTouCan: G42666HT GlyCosmos: G42666HT GlyGen: G42666HT

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
PE4 Query on PE4 Download:Ideal Coordinates CCD File SDF format, chain E [auth A] MOL2 format, chain E [auth A] mmCIF format, chain E [auth A]	E [auth A]	2-{2-[2-(2-{2-[2-(2-ETHOXY-ETHOXY)-ETHOXY]-ETHOXY}-ETHOXY)-ETHOXY]-ETHOXY}-ETHANOL C₁₆ H₃₄ O₈ PJWQOENWHPEPKI-UHFFFAOYSA-N		Interactions Focus chain E [auth A] Interactions & Density Focus chain E [auth A]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.60 Å
R-Value Free: 0.268 (Depositor), 0.269 (DCC)
R-Value Work: 0.218 (Depositor), 0.219 (DCC)
R-Value Observed: 0.220 (Depositor)

Space Group: P 2₁ 2₁ 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 69.57	α = 90
b = 76.33	β = 90
c = 126.17	γ = 90

Software Package:

Software Name	Purpose
PHENIX	refinement
XSCALE	data scaling
PDB_EXTRACT	data extraction
XDS	data reduction
PHASER	phasing

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Released Date: 2021-04-14

Deposition Author(s):

Bajic, G.

Schmidt, A.G.

Funding Organization	Location	Grant Number
National Institutes of Health/National Institute Of Allergy and Infectious Diseases (NIH/NIAID)	United States	P01 AI89618-A1

Revision History (Full details and data files)

Version 1.0: 2021-04-14
Type: Initial release
Version 1.1: 2023-10-18
Changes: Data collection, Database references, Refinement description
Version 1.2: 2024-10-16
Changes: Structure summary
