6WDJ

Cryo-EM of elongating ribosome with EF-Tu*GTP elucidates tRNA proofreading (Non-cognate Structure V-A1)


Experimental Data Snapshot

  • Method: ELECTRON MICROSCOPY
  • Resolution: 3.70 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE

wwPDB Validation   3D Report Full Report


This is version 1.2 of the entry. See complete history


Literature

Cryo-EM of elongating ribosome with EF-Tu•GTP elucidates tRNA proofreading.

Loveland, A.B.Demo, G.Korostelev, A.A.

(2020) Nature 584: 640-645

  • DOI: https://doi.org/10.1038/s41586-020-2447-x
  • Primary Citation of Related Structures:
    6WD0, 6WD1, 6WD2, 6WD3, 6WD4, 6WD5, 6WD6, 6WD7, 6WD8, 6WD9, 6WDA, 6WDB, 6WDC, 6WDD, 6WDE, 6WDF, 6WDG, 6WDH, 6WDI, 6WDJ, 6WDK, 6WDL, 6WDM

  • PubMed Abstract:

    Ribosomes accurately decode mRNA by proofreading each aminoacyl-tRNA that is delivered by the elongation factor EF-Tu 1 . To understand the molecular mechanism of this proofreading step it is necessary to visualize GTP-catalysed elongation, which has remained a challenge 2-4 . Here we use time-resolved cryogenic electron microscopy to reveal 33 ribosomal states after the delivery of aminoacyl-tRNA by EF-Tu•GTP. Instead of locking cognate tRNA upon initial recognition, the ribosomal decoding centre dynamically monitors codon-anticodon interactions before and after GTP hydrolysis. GTP hydrolysis enables the GTPase domain of EF-Tu to extend away, releasing EF-Tu from tRNA. The 30S subunit then locks cognate tRNA in the decoding centre and rotates, enabling the tRNA to bypass 50S protrusions during accommodation into the peptidyl transferase centre. By contrast, the decoding centre fails to lock near-cognate tRNA, enabling the dissociation of near-cognate tRNA both during initial selection (before GTP hydrolysis) and proofreading (after GTP hydrolysis). These findings reveal structural similarity between ribosomes in initial selection states 5,6 and in proofreading states, which together govern the efficient rejection of incorrect tRNA.


  • Organizational Affiliation

    Central European Institute of Technology, Masaryk University, Brno, Czech Republic.


Macromolecules

Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
50S ribosomal protein L2A [auth b]271Escherichia coli K-12Mutation(s): 0
Gene Names: rplBb3317JW3279
UniProt
Find proteins for P60422 (Escherichia coli (strain K12))
Explore P60422
Go to UniProtKB:  P60422
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP60422
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 2
MoleculeChains Sequence LengthOrganismDetailsImage
50S ribosomal protein L3B [auth c]209Escherichia coli K-12Mutation(s): 0
Gene Names: rplCb3320JW3282
UniProt
Find proteins for P60438 (Escherichia coli (strain K12))
Explore P60438
Go to UniProtKB:  P60438
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP60438
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 3
MoleculeChains Sequence LengthOrganismDetailsImage
50S ribosomal protein L4C [auth d]201Escherichia coli K-12Mutation(s): 0
Gene Names: rplDeryAb3319JW3281
UniProt
Find proteins for P60723 (Escherichia coli (strain K12))
Explore P60723
Go to UniProtKB:  P60723
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP60723
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 4
MoleculeChains Sequence LengthOrganismDetailsImage
50S ribosomal protein L5D [auth e]177Escherichia coli K-12Mutation(s): 0
Gene Names: rplEb3308JW3270
UniProt
Find proteins for P62399 (Escherichia coli (strain K12))
Explore P62399
Go to UniProtKB:  P62399
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP62399
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 5
MoleculeChains Sequence LengthOrganismDetailsImage
50S ribosomal protein L6E [auth f]176Escherichia coli K-12Mutation(s): 0
Gene Names: rplFb3305JW3267
UniProt
Find proteins for P0AG55 (Escherichia coli (strain K12))
Explore P0AG55
Go to UniProtKB:  P0AG55
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP0AG55
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 6
MoleculeChains Sequence LengthOrganismDetailsImage
50S ribosomal protein L9F [auth g]149Escherichia coli K-12Mutation(s): 0
Gene Names: rplIb4203JW4161
UniProt
Find proteins for P0A7R1 (Escherichia coli (strain K12))
Explore P0A7R1
Go to UniProtKB:  P0A7R1
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP0A7R1
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 7
MoleculeChains Sequence LengthOrganismDetailsImage
50S ribosomal protein L10G [auth h]131Escherichia coli K-12Mutation(s): 0
Gene Names: rplJb3985JW3948
UniProt
Find proteins for P0A7J3 (Escherichia coli (strain K12))
Explore P0A7J3
Go to UniProtKB:  P0A7J3
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP0A7J3
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 8
MoleculeChains Sequence LengthOrganismDetailsImage
50S ribosomal protein L11H [auth i]141Escherichia coli K-12Mutation(s): 0
Gene Names: rplKrelCb3983JW3946
UniProt
Find proteins for P0A7J7 (Escherichia coli (strain K12))
Explore P0A7J7
Go to UniProtKB:  P0A7J7
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP0A7J7
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 9
MoleculeChains Sequence LengthOrganismDetailsImage
50S ribosomal protein L13I [auth j]142Escherichia coli K-12Mutation(s): 0
Gene Names: rplMb3231JW3200
UniProt
Find proteins for P0AA10 (Escherichia coli (strain K12))
Explore P0AA10
Go to UniProtKB:  P0AA10
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP0AA10
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 10
MoleculeChains Sequence LengthOrganismDetailsImage
50S ribosomal protein L14J [auth k]122Escherichia coli K-12Mutation(s): 0
Gene Names: rplNb3310JW3272
UniProt
Find proteins for P0ADY3 (Escherichia coli (strain K12))
Explore P0ADY3
Go to UniProtKB:  P0ADY3
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP0ADY3
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 11
MoleculeChains Sequence LengthOrganismDetailsImage
50S ribosomal protein L15K [auth l]143Escherichia coli K-12Mutation(s): 0
Gene Names: rplOb3301JW3263
UniProt
Find proteins for P02413 (Escherichia coli (strain K12))
Explore P02413
Go to UniProtKB:  P02413
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP02413
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 12
MoleculeChains Sequence LengthOrganismDetailsImage
50S ribosomal protein L16L [auth m]136Escherichia coli K-12Mutation(s): 0
Gene Names: rplPb3313JW3275
UniProt
Find proteins for P0ADY7 (Escherichia coli (strain K12))
Explore P0ADY7
Go to UniProtKB:  P0ADY7
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP0ADY7
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 13
MoleculeChains Sequence LengthOrganismDetailsImage
50S ribosomal protein L17M [auth n]120Escherichia coli K-12Mutation(s): 0
Gene Names: rplQb3294JW3256
UniProt
Find proteins for P0AG44 (Escherichia coli (strain K12))
Explore P0AG44
Go to UniProtKB:  P0AG44
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP0AG44
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 14
MoleculeChains Sequence LengthOrganismDetailsImage
50S ribosomal protein L18N [auth o]116Escherichia coli K-12Mutation(s): 0
Gene Names: rplRb3304JW3266
UniProt
Find proteins for P0C018 (Escherichia coli (strain K12))
Explore P0C018
Go to UniProtKB:  P0C018
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP0C018
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 15
MoleculeChains Sequence LengthOrganismDetailsImage
50S ribosomal protein L19O [auth p]114Escherichia coli K-12Mutation(s): 0
Gene Names: rplSb2606JW2587
UniProt
Find proteins for P0A7K6 (Escherichia coli (strain K12))
Explore P0A7K6
Go to UniProtKB:  P0A7K6
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP0A7K6
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 16
MoleculeChains Sequence LengthOrganismDetailsImage
50S ribosomal protein L20P [auth q]117Escherichia coli K-12Mutation(s): 0
Gene Names: rplTpdzAb1716JW1706
UniProt
Find proteins for P0A7L3 (Escherichia coli (strain K12))
Explore P0A7L3
Go to UniProtKB:  P0A7L3
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP0A7L3
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 17
MoleculeChains Sequence LengthOrganismDetailsImage
50S ribosomal protein L21Q [auth r]103Escherichia coli K-12Mutation(s): 0
Gene Names: rplUb3186JW3153
UniProt
Find proteins for P0AG48 (Escherichia coli (strain K12))
Explore P0AG48
Go to UniProtKB:  P0AG48
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP0AG48
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 18
MoleculeChains Sequence LengthOrganismDetailsImage
50S ribosomal protein L22R [auth s]110Escherichia coli K-12Mutation(s): 0
Gene Names: rplVeryBb3315JW3277
UniProt
Find proteins for P61175 (Escherichia coli (strain K12))
Explore P61175
Go to UniProtKB:  P61175
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP61175
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 19
MoleculeChains Sequence LengthOrganismDetailsImage
50S ribosomal protein L23S [auth t]93Escherichia coli K-12Mutation(s): 0
Gene Names: rplWb3318JW3280
UniProt
Find proteins for P0ADZ0 (Escherichia coli (strain K12))
Explore P0ADZ0
Go to UniProtKB:  P0ADZ0
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP0ADZ0
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 20
MoleculeChains Sequence LengthOrganismDetailsImage
50S ribosomal protein L24T [auth u]102Escherichia coli K-12Mutation(s): 0
Gene Names: rplXb3309JW3271
UniProt
Find proteins for P60624 (Escherichia coli (strain K12))
Explore P60624
Go to UniProtKB:  P60624
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP60624
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 21
MoleculeChains Sequence LengthOrganismDetailsImage
50S ribosomal protein L25U [auth v]94Escherichia coli K-12Mutation(s): 0
Gene Names: rplYb2185JW2173
UniProt
Find proteins for P68919 (Escherichia coli (strain K12))
Explore P68919
Go to UniProtKB:  P68919
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP68919
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 22
MoleculeChains Sequence LengthOrganismDetailsImage
50S ribosomal protein L27V [auth w]75Escherichia coli K-12Mutation(s): 0
Gene Names: rpmAb3185JW3152
UniProt
Find proteins for P0A7L8 (Escherichia coli (strain K12))
Explore P0A7L8
Go to UniProtKB:  P0A7L8
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP0A7L8
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 23
MoleculeChains Sequence LengthOrganismDetailsImage
50S ribosomal protein L28W [auth x]77Escherichia coli K-12Mutation(s): 0
Gene Names: rpmBb3637JW3612
UniProt
Find proteins for P0A7M2 (Escherichia coli (strain K12))
Explore P0A7M2
Go to UniProtKB:  P0A7M2
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP0A7M2
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 24
MoleculeChains Sequence LengthOrganismDetailsImage
50S ribosomal protein L29X [auth y]63Escherichia coli K-12Mutation(s): 0
Gene Names: rpmCb3312JW3274
UniProt
Find proteins for P0A7M6 (Escherichia coli (strain K12))
Explore P0A7M6
Go to UniProtKB:  P0A7M6
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP0A7M6
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 25
MoleculeChains Sequence LengthOrganismDetailsImage
50S ribosomal protein L30Y [auth z]58Escherichia coli K-12Mutation(s): 0
Gene Names: rpmDb3302JW3264
UniProt
Find proteins for P0AG51 (Escherichia coli (strain K12))
Explore P0AG51
Go to UniProtKB:  P0AG51
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP0AG51
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 26
MoleculeChains Sequence LengthOrganismDetailsImage
50S ribosomal protein L32Z [auth B]56Escherichia coli K-12Mutation(s): 0
Gene Names: rpmFb1089JW1075
UniProt
Find proteins for P0A7N4 (Escherichia coli (strain K12))
Explore P0A7N4
Go to UniProtKB:  P0A7N4
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP0A7N4
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 27
MoleculeChains Sequence LengthOrganismDetailsImage
50S ribosomal protein L33AA [auth C]50Escherichia coli K-12Mutation(s): 0
Gene Names: rpmGb3636JW3611
UniProt
Find proteins for P0A7N9 (Escherichia coli (strain K12))
Explore P0A7N9
Go to UniProtKB:  P0A7N9
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP0A7N9
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 28
MoleculeChains Sequence LengthOrganismDetailsImage
50S ribosomal protein L34BA [auth D]46Escherichia coli K-12Mutation(s): 0
Gene Names: rpmHrimAssaFb3703JW3680
UniProt
Find proteins for P0A7P5 (Escherichia coli (strain K12))
Explore P0A7P5
Go to UniProtKB:  P0A7P5
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP0A7P5
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 29
MoleculeChains Sequence LengthOrganismDetailsImage
50S ribosomal protein L35CA [auth E]64Escherichia coli K-12Mutation(s): 0
Gene Names: rpmIb1717JW1707
UniProt
Find proteins for P0A7Q1 (Escherichia coli (strain K12))
Explore P0A7Q1
Go to UniProtKB:  P0A7Q1
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP0A7Q1
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 30
MoleculeChains Sequence LengthOrganismDetailsImage
50S ribosomal protein L36DA [auth F]38Escherichia coli K-12Mutation(s): 0
Gene Names: rpmJb3299JW3261
UniProt
Find proteins for P0A7Q6 (Escherichia coli (strain K12))
Explore P0A7Q6
Go to UniProtKB:  P0A7Q6
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP0A7Q6
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 31
MoleculeChains Sequence LengthOrganismDetailsImage
30S ribosomal protein S2EA [auth G]225Escherichia coli K-12Mutation(s): 0
Gene Names: rpsBb0169JW0164
UniProt
Find proteins for P0A7V0 (Escherichia coli (strain K12))
Explore P0A7V0
Go to UniProtKB:  P0A7V0
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP0A7V0
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 32
MoleculeChains Sequence LengthOrganismDetailsImage
30S ribosomal protein S3FA [auth H]206Escherichia coli K-12Mutation(s): 0
Gene Names: rpsCb3314JW3276
UniProt
Find proteins for P0A7V3 (Escherichia coli (strain K12))
Explore P0A7V3
Go to UniProtKB:  P0A7V3
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP0A7V3
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 33
MoleculeChains Sequence LengthOrganismDetailsImage
30S ribosomal protein S4GA [auth I]205Escherichia coli K-12Mutation(s): 0
Gene Names: rpsDramAb3296JW3258
UniProt
Find proteins for P0A7V8 (Escherichia coli (strain K12))
Explore P0A7V8
Go to UniProtKB:  P0A7V8
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP0A7V8
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 34
MoleculeChains Sequence LengthOrganismDetailsImage
30S ribosomal protein S5HA [auth J]157Escherichia coli K-12Mutation(s): 0
Gene Names: rpsEspcb3303JW3265
UniProt
Find proteins for P0A7W1 (Escherichia coli (strain K12))
Explore P0A7W1
Go to UniProtKB:  P0A7W1
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP0A7W1
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 35
MoleculeChains Sequence LengthOrganismDetailsImage
30S ribosomal protein S6IA [auth K]100Escherichia coli K-12Mutation(s): 0
Gene Names: rpsFb4200JW4158
UniProt
Find proteins for P02358 (Escherichia coli (strain K12))
Explore P02358
Go to UniProtKB:  P02358
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP02358
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 36
MoleculeChains Sequence LengthOrganismDetailsImage
30S ribosomal protein S7JA [auth L]151Escherichia coli K-12Mutation(s): 0
Gene Names: rpsGb3341JW3303
UniProt
Find proteins for P02359 (Escherichia coli (strain K12))
Explore P02359
Go to UniProtKB:  P02359
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP02359
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 37
MoleculeChains Sequence LengthOrganismDetailsImage
30S ribosomal protein S8KA [auth M]129Escherichia coli K-12Mutation(s): 0
Gene Names: rpsHb3306JW3268
UniProt
Find proteins for P0A7W7 (Escherichia coli (strain K12))
Explore P0A7W7
Go to UniProtKB:  P0A7W7
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP0A7W7
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 38
MoleculeChains Sequence LengthOrganismDetailsImage
30S ribosomal protein S9LA [auth N]127Escherichia coli K-12Mutation(s): 0
Gene Names: rpsIb3230JW3199
UniProt
Find proteins for P0A7X3 (Escherichia coli (strain K12))
Explore P0A7X3
Go to UniProtKB:  P0A7X3
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP0A7X3
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 39
MoleculeChains Sequence LengthOrganismDetailsImage
30S ribosomal protein S10MA [auth O]98Escherichia coli K-12Mutation(s): 0
Gene Names: rpsJnusEb3321JW3283
UniProt
Find proteins for P0A7R5 (Escherichia coli (strain K12))
Explore P0A7R5
Go to UniProtKB:  P0A7R5
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP0A7R5
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 40
MoleculeChains Sequence LengthOrganismDetailsImage
30S ribosomal protein S11NA [auth P]116Escherichia coli K-12Mutation(s): 0
Gene Names: rpsKb3297JW3259
UniProt
Find proteins for P0A7R9 (Escherichia coli (strain K12))
Explore P0A7R9
Go to UniProtKB:  P0A7R9
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP0A7R9
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 41
MoleculeChains Sequence LengthOrganismDetailsImage
30S ribosomal protein S12OA [auth Q]123Escherichia coli K-12Mutation(s): 0
Gene Names: rpsLstrAb3342JW3304
UniProt
Find proteins for P0A7S3 (Escherichia coli (strain K12))
Explore P0A7S3
Go to UniProtKB:  P0A7S3
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP0A7S3
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 42
MoleculeChains Sequence LengthOrganismDetailsImage
30S ribosomal protein S13PA [auth R]114Escherichia coli K-12Mutation(s): 0
Gene Names: rpsMb3298JW3260
UniProt
Find proteins for P0A7S9 (Escherichia coli (strain K12))
Explore P0A7S9
Go to UniProtKB:  P0A7S9
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP0A7S9
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 43
MoleculeChains Sequence LengthOrganismDetailsImage
30S ribosomal protein S14QA [auth S]100Escherichia coli K-12Mutation(s): 0
Gene Names: rpsNb3307JW3269
UniProt
Find proteins for P0AG59 (Escherichia coli (strain K12))
Explore P0AG59
Go to UniProtKB:  P0AG59
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP0AG59
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 44
MoleculeChains Sequence LengthOrganismDetailsImage
30S ribosomal protein S15RA [auth T]88Escherichia coli K-12Mutation(s): 0
Gene Names: rpsOsecCb3165JW3134
UniProt
Find proteins for P0ADZ4 (Escherichia coli (strain K12))
Explore P0ADZ4
Go to UniProtKB:  P0ADZ4
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP0ADZ4
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 45
MoleculeChains Sequence LengthOrganismDetailsImage
30S ribosomal protein S16SA [auth U]82Escherichia coli K-12Mutation(s): 0
Gene Names: rpsPb2609JW2590
UniProt
Find proteins for P0A7T3 (Escherichia coli (strain K12))
Explore P0A7T3
Go to UniProtKB:  P0A7T3
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP0A7T3
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 46
MoleculeChains Sequence LengthOrganismDetailsImage
30S ribosomal protein S17TA [auth V]80Escherichia coli K-12Mutation(s): 0
Gene Names: rpsQneaAb3311JW3273
UniProt
Find proteins for P0AG63 (Escherichia coli (strain K12))
Explore P0AG63
Go to UniProtKB:  P0AG63
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP0AG63
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 47
MoleculeChains Sequence LengthOrganismDetailsImage
30S ribosomal protein S18UA [auth W]65Escherichia coli K-12Mutation(s): 0
Gene Names: rpsRb4202JW4160
UniProt
Find proteins for P0A7T7 (Escherichia coli (strain K12))
Explore P0A7T7
Go to UniProtKB:  P0A7T7
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP0A7T7
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 48
MoleculeChains Sequence LengthOrganismDetailsImage
30S ribosomal protein S19VA [auth X]79Escherichia coli K-12Mutation(s): 0
Gene Names: rpsSb3316JW3278
UniProt
Find proteins for P0A7U3 (Escherichia coli (strain K12))
Explore P0A7U3
Go to UniProtKB:  P0A7U3
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP0A7U3
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 49
MoleculeChains Sequence LengthOrganismDetailsImage
30S ribosomal protein S20WA [auth Y]85Escherichia coli K-12Mutation(s): 0
Gene Names: rpsTb0023JW0022
UniProt
Find proteins for P0A7U7 (Escherichia coli (strain K12))
Explore P0A7U7
Go to UniProtKB:  P0A7U7
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP0A7U7
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 50
MoleculeChains Sequence LengthOrganismDetailsImage
30S ribosomal protein S21XA [auth Z]65Escherichia coli K-12Mutation(s): 0
Gene Names: rpsUb3065JW3037
UniProt
Find proteins for P68679 (Escherichia coli (strain K12))
Explore P68679
Go to UniProtKB:  P68679
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP68679
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 51
MoleculeChains Sequence LengthOrganismDetailsImage
50S ribosomal protein L1YA [auth a]223Escherichia coli K-12Mutation(s): 0
Gene Names: rplAb3984JW3947
UniProt
Find proteins for P0A7L0 (Escherichia coli (strain K12))
Explore P0A7L0
Go to UniProtKB:  P0A7L0
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP0A7L0
Sequence Annotations
Expand
  • Reference Sequence
Find similar nucleic acids by:  (by identity cutoff)  |  3D Structure
Entity ID: 52
MoleculeChains LengthOrganismImage
16S ribosomal RNAZA [auth 3]1,539Escherichia coli K-12
Sequence Annotations
Expand
  • Reference Sequence
Find similar nucleic acids by:  (by identity cutoff)  |  3D Structure
Entity ID: 53
MoleculeChains LengthOrganismImage
23S ribosomal RNAAB [auth 1]2,903Escherichia coli K-12
Sequence Annotations
Expand
  • Reference Sequence
Find similar nucleic acids by:  (by identity cutoff)  |  3D Structure
Entity ID: 54
MoleculeChains LengthOrganismImage
5S ribosomal RNABB [auth 2]120Escherichia coli K-12
Sequence Annotations
Expand
  • Reference Sequence
Find similar nucleic acids by:  (by identity cutoff)  |  3D Structure
Entity ID: 55
MoleculeChains LengthOrganismImage
tRNAfMetCB [auth 5],
DB [auth 6]
77Escherichia coli K-12
Sequence Annotations
Expand
  • Reference Sequence

Find similar nucleic acids by:  Sequence   |   3D Structure

Entity ID: 56
MoleculeChains LengthOrganismImage
mRNAEB [auth 4]18Escherichia coli K-12
Sequence Annotations
Expand
  • Reference Sequence
Find similar nucleic acids by:  (by identity cutoff)  |  3D Structure
Entity ID: 57
MoleculeChains LengthOrganismImage
tRNAPheFB [auth 7]76Escherichia coli K-12
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 1 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
FME
Query on FME

Download Ideal Coordinates CCD File
GB [auth 5]N-FORMYLMETHIONINE
C6 H11 N O3 S
PYUSHNKNPOHWEZ-YFKPBYRVSA-N
Experimental Data & Validation

Experimental Data

  • Method: ELECTRON MICROSCOPY
  • Resolution: 3.70 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE
EM Software:
TaskSoftware PackageVersion
MODEL REFINEMENTCNS
MODEL REFINEMENTRSRef
MODEL REFINEMENTPHENIX
RECONSTRUCTIONFREALIGN

Structure Validation

View Full Validation Report



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)United StatesR01 GM106105
National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)United StatesR01 GM107465
National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)United StatesR35 GM127094

Revision History  (Full details and data files)

  • Version 1.0: 2020-07-01
    Type: Initial release
  • Version 1.1: 2020-07-15
    Changes: Database references
  • Version 1.2: 2020-09-09
    Changes: Database references
