6WCM | pdb_00006wcm

Crystal structure of Laccase from Thermus thermophilus HB27 with an open conformation of beta-hairpin (Average deposited dose 15.50 MGy)

PDB DOI: https://doi.org/10.2210/pdb6WCM/pdb

Classification: OXIDOREDUCTASE
Organism(s): Thermus thermophilus HB27
Expression System: Escherichia coli BL21(DE3)
Mutation(s): No

Deposited: 2020-03-30 Released: 2021-03-31
Deposition Author(s): Miranda-Blancas, R., Rudino-Pinera, E.

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.70 Å
R-Value Free:
0.237 (Depositor), 0.239 (DCC)
R-Value Work:
0.197 (Depositor), 0.197 (DCC)
R-Value Observed:
0.199 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 6WCM

This is version 1.1 of the entry. See complete history.

Literature

Dynamic behavior of beta-hairpin loop at laccase of Thermus thermophilus at 1.7 angstroms resolution

Miranda-Blancas, R., Rudino-Pinera, E.

To be published.

Macromolecule Content

Total Structure Weight: 49.21 kDa
Atom Count: 3,861
Modeled Residue Count: 440
Deposited Residue Count: 440
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Laccase	A	440	Thermus thermophilus HB27	Mutation(s): 0 Gene Names: TT_C1370 EC: 1.10.3.2
UniProt
Find proteins for Q72HW2 (Thermus thermophilus (strain ATCC BAA-163 / DSM 7039 / HB27)) Explore Q72HW2 Go to UniProtKB: Q72HW2
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	Q72HW2
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
1PE Query on 1PE Download:Ideal Coordinates CCD File SDF format, chain D [auth A] MOL2 format, chain D [auth A] mmCIF format, chain D [auth A]	D [auth A]	PENTAETHYLENE GLYCOL C₁₀ H₂₂ O₆ JLFNLZLINWHATN-UHFFFAOYSA-N		Interactions Focus chain D [auth A] Interactions & Density Focus chain D [auth A]
CU Query on CU Download:Ideal Coordinates CCD File SDF format, chain C [auth A] SDF format, chain B [auth A] MOL2 format, chain C [auth A] MOL2 format, chain B [auth A] mmCIF format, chain C [auth A] mmCIF format, chain B [auth A]	B [auth A], C [auth A]	COPPER (II) ION Cu JPVYNHNXODAKFH-UHFFFAOYSA-N		Interactions Focus chain B [auth A] Focus chain C [auth A] Interactions & Density Focus chain B [auth A] Focus chain C [auth A]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.70 Å
R-Value Free: 0.237 (Depositor), 0.239 (DCC)
R-Value Work: 0.197 (Depositor), 0.197 (DCC)
R-Value Observed: 0.199 (Depositor)

Space Group: P 1 2₁ 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 54.436	α = 90
b = 60.817	β = 109.34
c = 76.235	γ = 90

Software Package:

Software Name	Purpose
MOSFLM	data reduction
SCALA	data scaling
PHENIX	refinement
PDB_EXTRACT	data extraction
PHASER	phasing

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

Deposition Data

Released Date: 2021-03-31

Deposition Author(s):

Miranda-Blancas, R.

Rudino-Pinera, E.

Revision History (Full details and data files)

Version 1.0: 2021-03-31
Type: Initial release
Version 1.1: 2023-10-18
Changes: Data collection, Database references, Refinement description
