6WCK | pdb_00006wck

KRAS G-quadruplex G16T mutant with Bromo Uracil replacing T8 and T16.


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.80 Å
  • R-Value Free:
    0.241 (Depositor), 0.242 (DCC)
  • R-Value Work:
    0.197 (Depositor), 0.198 (DCC)
  • R-Value Observed:
    0.199 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 6WCK

This is version 1.3 of the entry. See complete history

Literature

High resolution crystal structure of a KRAS promoter G-quadruplex reveals a dimer with extensive poly-A pi-stacking interactions for small-molecule recognition.

Ou, A.Schmidberger, J.W.Wilson, K.A.Evans, C.W.Hargreaves, J.A.Grigg, M.O'Mara, M.L.Iyer, K.S.Bond, C.S.Smith, N.M.

(2020) Nucleic Acids Res 48: 5766-5776

  • DOI: https://doi.org/10.1093/nar/gkaa262
  • Primary Citation Related Structures:
    6N65, 6WCK

  • PubMed Abstract:

    Aberrant KRAS signaling is a driver of many cancers and yet remains an elusive target for drug therapy. The nuclease hypersensitive element of the KRAS promoter has been reported to form secondary DNA structures called G-quadruplexes (G4s) which may play important roles in regulating KRAS expression, and has spurred interest in structural elucidation studies of the KRAS G-quadruplexes. Here, we report the first high-resolution crystal structure (1.6 Å) of a KRAS G-quadruplex as a 5'-head-to-head dimer with extensive poly-A π-stacking interactions observed across the dimer. Molecular dynamics simulations confirmed that the poly-A π-stacking interactions are also maintained in the G4 monomers. Docking and molecular dynamics simulations with two G4 ligands that display high stabilization of the KRAS G4 indicated the poly-A loop was a binding site for these ligands in addition to the 5'-G-tetrad. Given sequence and structural variability in the loop regions provide the opportunity for small-molecule targeting of specific G4s, we envisage this high-resolution crystal structure for the KRAS G-quadruplex will aid in the rational design of ligands to selectively target KRAS.


  • Organizational Affiliation
    • School of Molecular Sciences, University of Western Australia, Crawley, WA 6009, Australia.

Macromolecule Content

  • Total Structure Weight: 14.43 kDa
  • Atom Count: 1,109
  • Modeled Residue Count: 44
  • Deposited Residue Count: 44
  • Unique nucleic acid chains: 1

Macromolecules

Find similar nucleic acids by:  Sequence
Entity ID: 1
MoleculeChains LengthOrganismImage
DNA (5'-D(*AP*GP*GP*GP*CP*GP*GP*(BRU)P*GP*TP*GP*GP*GP*AP*AP*(BRU)P*AP*GP*GP*GP*AP*A)-3')
A, B
22Homo sapiens
Sequence Annotations
Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.80 Å
  • R-Value Free:  0.241 (Depositor), 0.242 (DCC)
  • R-Value Work:  0.197 (Depositor), 0.198 (DCC)
  • R-Value Observed: 0.199 (Depositor)
Space Group: P 1 21 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 33.452α = 90
b = 29.943β = 94.62
c = 52.691γ = 90
Software Package:
Software NamePurpose
XDSdata reduction
Aimlessdata scaling
MOLREPphasing
PHENIXrefinement
PDB_EXTRACTdata extraction

Structure Validation

View Full Validation Report



Entry History

& Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
National Health and Medical Research Council (NHMRC, Australia)AustraliaAPP1139936

Revision History  (Full details and data files)

  • Version 1.0: 2020-04-15
    Type: Initial release
  • Version 1.1: 2020-05-06
    Changes: Database references
  • Version 1.2: 2020-06-10
    Changes: Database references
  • Version 1.3: 2023-10-18
    Changes: Data collection, Database references, Derived calculations, Refinement description
