6WAJ | pdb_00006waj

Crystal structure of the UBL domain of human NLE1

PDB DOI: https://doi.org/10.2210/pdb6WAJ/pdb

Classification: PROTEIN BINDING
Organism(s): Homo sapiens
Expression System: Escherichia coli
Mutation(s): No

Deposited: 2020-03-25 Released: 2020-04-22
Deposition Author(s): Halabelian, L., Zeng, H., Li, Y., Bountra, C., Edwards, A.M., Arrowsmith, C.H., Structural Genomics Consortium (SGC)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.90 Å
R-Value Free:
0.254 (Depositor), 0.259 (DCC)
R-Value Work:
0.248 (Depositor), 0.255 (DCC)
R-Value Observed:
0.249 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 6WAJ

This is version 1.1 of the entry. See complete history.

Literature

Crystal structure of the UBL domain of human NLE1

Halabelian, L., Zeng, H., Li, Y., Bountra, C., Edwards, A.M., Arrowsmith, C.H., Structural Genomics Consortium (SGC)

To be published.

Macromolecule Content

Total Structure Weight: 10.58 kDa
Atom Count: 611
Modeled Residue Count: 81
Deposited Residue Count: 98
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
NLE1	A	98	Homo sapiens	Mutation(s): 0
UniProt & NIH Common Fund Data Resources
Find proteins for Q9NVX2 (Homo sapiens) Explore Q9NVX2 Go to UniProtKB: Q9NVX2
PHAROS: Q9NVX2 GTEx: ENSG00000073536
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	Q9NVX2
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
UNX (Subject of Investigation/LOI) Query on UNX Download:Ideal Coordinates CCD File SDF format, chain E [auth A] SDF format, chain D [auth A] SDF format, chain C [auth A] SDF format, chain B [auth A] MOL2 format, chain E [auth A] MOL2 format, chain D [auth A] MOL2 format, chain C [auth A] MOL2 format, chain B [auth A] mmCIF format, chain E [auth A] mmCIF format, chain D [auth A] mmCIF format, chain C [auth A] mmCIF format, chain B [auth A]	B [auth A], C [auth A], D [auth A], E [auth A]	UNKNOWN ATOM OR ION X		Interactions Focus chain B [auth A] Focus chain C [auth A] Focus chain D [auth A] Focus chain E [auth A] Interactions & Density Focus chain B [auth A] Focus chain C [auth A] Focus chain D [auth A] Focus chain E [auth A]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.90 Å
R-Value Free: 0.254 (Depositor), 0.259 (DCC)
R-Value Work: 0.248 (Depositor), 0.255 (DCC)
R-Value Observed: 0.249 (Depositor)

Space Group: P 6₁ 2 2

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 35.546	α = 90
b = 35.546	β = 90
c = 205.994	γ = 120

Software Package:

Software Name	Purpose
PHENIX	refinement
XDS	data reduction
Aimless	data scaling
PHASER	phasing
PDB_EXTRACT	data extraction

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

Deposition Data

Released Date: 2020-04-22

Deposition Author(s):

Arrowsmith, C.H.

Structural Genomics Consortium (SGC)

Revision History (Full details and data files)

Version 1.0: 2020-04-22
Type: Initial release
Version 1.1: 2023-10-18
Changes: Data collection, Database references, Refinement description
