6VBI | pdb_00006vbi

crystal structure of PDE5 in complex with a non-competitive inhibitor

PDB DOI: https://doi.org/10.2210/pdb6VBI/pdb

Classification: HYDROLASE/INHIBITOR
Organism(s): Homo sapiens
Expression System: Escherichia coli
Mutation(s): No

Deposited: 2019-12-18 Released: 2021-01-20
Deposition Author(s): Ke, H., Luo, H.B.

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.30 Å
R-Value Free:
0.252 (Depositor), 0.255 (DCC)
R-Value Work:
0.189 (Depositor), 0.190 (DCC)
R-Value Observed:
0.192 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 6VBI

Ligand Structure Quality Assessment

This is version 1.2 of the entry. See complete history.

Literature

Identification of a novel allosteric pocket and its regulation mechanism

Zhang, T., Ke, H., Luo, H.

To be published.

Macromolecule Content

Total Structure Weight: 76.05 kDa
Atom Count: 5,096
Modeled Residue Count: 605
Deposited Residue Count: 650
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
cGMP-specific 3',5'-cyclic phosphodiesterase	A, B	325	Homo sapiens	Mutation(s): 0 Gene Names: PDE5A, PDE5 EC: 3.1.4.35
UniProt & NIH Common Fund Data Resources
Find proteins for O76074 (Homo sapiens) Explore O76074 Go to UniProtKB: O76074
PHAROS: O76074 GTEx: ENSG00000138735
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	O76074
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
FZA (Subject of Investigation/LOI) Query on FZA Download:Ideal Coordinates CCD File SDF format, chain D [auth B] SDF format, chain C [auth A] MOL2 format, chain D [auth B] MOL2 format, chain C [auth A] mmCIF format, chain D [auth B] mmCIF format, chain C [auth A]	C [auth A], D [auth B]	(13bS)-4,9-dimethoxy-14-methyl-8,13,13b,14-tetrahydroindolo[2',3':3,4]pyrido[2,1-b]quinazolin-5(7H)-one C₂₁ H₂₁ N₃ O₃ FFAIVCGLKMKWII-FQEVSTJZSA-N		Interactions Focus chain C [auth A] Focus chain D [auth B] Interactions & Density Focus chain C [auth A] Focus chain D [auth B]

Binding Affinity Annotations
ID	Source	Binding Affinity
FZA	BindingDB: 6VBI	IC50: 35 (nM) from 1 assay(s)

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.30 Å
R-Value Free: 0.252 (Depositor), 0.255 (DCC)
R-Value Work: 0.189 (Depositor), 0.190 (DCC)
R-Value Observed: 0.192 (Depositor)

Space Group: P 2₁ 2₁ 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 65.975	α = 90
b = 85.519	β = 90
c = 124.381	γ = 90

Software Package:

Software Name	Purpose
PHENIX	refinement
CrysalisPro	data reduction
CrysalisPro	data scaling
PHASER	phasing

Structure Validation

View Full Validation Report

Ligand Structure Quality Assessment

View more in-depth experimental data

Entry History

Deposition Data

Released Date: 2021-01-20

Deposition Author(s):

Revision History (Full details and data files)

Version 1.0: 2021-01-20
Type: Initial release
Version 1.1: 2023-10-11
Changes: Data collection, Database references, Refinement description
Version 1.2: 2024-10-30
Changes: Structure summary
