6VB6 | pdb_00006vb6

HLA-B*15:02 complexed with a synthetic peptide

• PDB DOI: https://doi.org/10.2210/pdb6VB6/pdb

• Classification: IMMUNE SYSTEM
• Organism(s): Homo sapiens, synthetic construct
• Expression System: Escherichia coli
• Mutation(s): No


• Deposited: 2019-12-18 Released: 2020-11-25
• Deposition Author(s): Schutte, R.J., Li, D., Ostrov, D.A.
• Funding Organization(s): National Institutes of Health/National Institute Of Allergy and Infectious Diseases (NIH/NIAID)

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 2.15 Å
• R-Value Free:
  0.242 (Depositor), 0.242 (DCC)
• R-Value Work:
  0.180 (Depositor), 0.181 (DCC)
• R-Value Observed:
  0.185 (Depositor)

Starting Model: experimental

Literature

HLA-B*15:02 complexed with a synthetic peptide

Schutte, R.J., Li, D., Ostrov, D.A.

To be published.

Biological Assembly 1

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Hetero 3-mer - A1B1C1

Biological assembly 1 assigned by authors and generated by PISA (software)

Biological Assembly Evidence: gel filtration

Macromolecule Content

• Total Structure Weight: 44.88 kDa
• Atom Count: 3,467
• Modeled Residue Count: 384
• Deposited Residue Count: 384
• Unique protein chains: 3

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
MHC class I antigen	A	276	Homo sapiens	Mutation(s): 0  Gene Names: HLA-B
UniProt
Find proteins for F4NBQ8 (Homo sapiens) Explore F4NBQ8  Go to UniProtKB:  F4NBQ8

Entity ID: 2
Molecule	Chains	Sequence Length	Organism	Details	Image
Beta-2-microglobulin	B	99	Homo sapiens	Mutation(s): 0  Gene Names: B2M, CDABP0092, HDCMA22P
UniProt & NIH Common Fund Data Resources
Find proteins for P61769 (Homo sapiens) Explore P61769  Go to UniProtKB:  P61769
PHAROS:  P61769 GTEx:  ENSG00000166710

Entity ID: 3
Molecule	Chains	Sequence Length	Organism	Details	Image
Synthetic peptide THR-VAL-ARG-ALA-SER-GLY-HIS-SER-TYR	C	9	synthetic construct	Mutation(s): 0

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
GOL	D [auth A], E [auth A]	GLYCEROL C3 H8 O3 PEDCQBHIVMGVHV-UHFFFAOYSA-N
ACT	F [auth C]	ACETATE ION C2 H3 O2 QTBSBXVTEAMEQO-UHFFFAOYSA-M

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 2.15 Å
• R-Value Free:  0.242 (Depositor), 0.242 (DCC)
• R-Value Work:  0.180 (Depositor), 0.181 (DCC)
• R-Value Observed: 0.185 (Depositor)

Space Group: P 2₁ 2₁ 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 51.079	α = 90
b = 81.8	β = 90
c = 110.842	γ = 90

Software Package:

Software Name	Purpose
PHENIX	refinement
PDB_EXTRACT	data extraction
XDS	data reduction
XDS	data scaling
PHENIX	phasing

Structure Validation

Entry History

& Funding Information

Deposition Data

• Released Date: 2020-11-25
Deposition Author(s): Schutte, R.J., Li, D., Ostrov, D.A.

---

Funding Organization	Location	Grant Number
National Institutes of Health/National Institute Of Allergy and Infectious Diseases (NIH/NIAID)	United States	1R01AI103348-01

Revision History

• Version 1.0: 2020-11-25
  Type: Initial release

• Version 1.1: 2023-10-11
  Changes: Data collection, Database references, Refinement description
• Version 1.2: 2024-11-06
  Changes: Structure summary
