6VB5 | pdb_00006vb5

HLA-B*15:02 complexed with a synthetic peptide

PDB DOI: https://doi.org/10.2210/pdb6VB5/pdb

Classification: IMMUNE SYSTEM
Organism(s): Homo sapiens, synthetic construct
Expression System: Escherichia coli
Mutation(s): No

Deposited: 2019-12-18 Released: 2020-11-25
Deposition Author(s): Schutte, R.J., Li, D., Ostrov, D.A.
Funding Organization(s): National Institutes of Health/National Institute Of Allergy and Infectious Diseases (NIH/NIAID)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.15 Å
R-Value Free:
0.224 (Depositor), 0.231 (DCC)
R-Value Work:
0.171 (Depositor)
R-Value Observed:
0.174 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

This is version 1.2 of the entry. See complete history.

Literature

HLA-B*15:02 complexed with a synthetic peptide

Schutte, R.J., Li, D., Ostrov, D.A.

To be published.

Macromolecule Content

Total Structure Weight: 45.05 kDa
Atom Count: 3,518
Modeled Residue Count: 384
Deposited Residue Count: 384
Unique protein chains: 3

Macromolecules

Find similar proteins by:

| 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
MHC class I antigen	A	276	Homo sapiens	Mutation(s): 0 Gene Names: HLA-B
UniProt
Find proteins for F4NBQ8 (Homo sapiens) Explore F4NBQ8 Go to UniProtKB: F4NBQ8
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	F4NBQ8
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

| 3D Structure

Entity ID: 2
Molecule	Chains	Sequence Length	Organism	Details	Image
Beta-2-microglobulin	B	99	Homo sapiens	Mutation(s): 0 Gene Names: B2M, CDABP0092, HDCMA22P
UniProt & NIH Common Fund Data Resources
Find proteins for P61769 (Homo sapiens) Explore P61769 Go to UniProtKB: P61769
PHAROS: P61769 GTEx: ENSG00000166710
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	P61769
Sequence Annotations Expand
Reference Sequence

Find similar proteins by: Sequence | 3D Structure

Entity ID: 3
Molecule	Chains	Sequence Length	Organism	Details	Image
Synthetic peptide THR-VAL-ARG-ALA-SER-GLY-HIS-SER-TYR	C	9	synthetic construct	Mutation(s): 0

Small Molecules

Ligands 4 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
GOL Query on GOL Download:Ideal Coordinates CCD File SDF format, chain E [auth A] MOL2 format, chain E [auth A] mmCIF format, chain E [auth A]	E [auth A]	GLYCEROL C₃ H₈ O₃ PEDCQBHIVMGVHV-UHFFFAOYSA-N		Interactions Focus chain E [auth A] Interactions & Density Focus chain E [auth A]
EDO Query on EDO Download:Ideal Coordinates CCD File SDF format, chain F [auth A] SDF format, chain G [auth A] SDF format, chain H [auth A] MOL2 format, chain F [auth A] MOL2 format, chain G [auth A] MOL2 format, chain H [auth A] mmCIF format, chain F [auth A] mmCIF format, chain G [auth A] mmCIF format, chain H [auth A]	F [auth A], G [auth A], H [auth A]	1,2-ETHANEDIOL C₂ H₆ O₂ LYCAIKOWRPUZTN-UHFFFAOYSA-N		Interactions Focus chain F [auth A] Focus chain G [auth A] Focus chain H [auth A] Interactions & Density Focus chain F [auth A] Focus chain G [auth A] Focus chain H [auth A]
ACT Query on ACT Download:Ideal Coordinates CCD File SDF format, chain J [auth C] SDF format, chain D [auth A] MOL2 format, chain J [auth C] MOL2 format, chain D [auth A] mmCIF format, chain J [auth C] mmCIF format, chain D [auth A]	D [auth A], J [auth C]	ACETATE ION C₂ H₃ O₂ QTBSBXVTEAMEQO-UHFFFAOYSA-M		Interactions Focus chain D [auth A] Focus chain J [auth C] Interactions & Density Focus chain D [auth A] Focus chain J [auth C]
NA Query on NA Download:Ideal Coordinates CCD File SDF format, chain I [auth B] MOL2 format, chain I [auth B] mmCIF format, chain I [auth B]	I [auth B]	SODIUM ION Na FKNQFGJONOIPTF-UHFFFAOYSA-N		Interactions Focus chain I [auth B] Interactions & Density Focus chain I [auth B]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.15 Å
R-Value Free: 0.224 (Depositor), 0.231 (DCC)
R-Value Work: 0.171 (Depositor)
R-Value Observed: 0.174 (Depositor)

Space Group: P 2₁ 2₁ 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 50.825	α = 90
b = 81.277	β = 90
c = 109.43	γ = 90

Software Package:

Software Name	Purpose
PHENIX	refinement
PDB_EXTRACT	data extraction
XDS	data reduction
XDS	data scaling
PHENIX	phasing

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Released Date: 2020-11-25

Deposition Author(s):

Schutte, R.J.

Li, D.

Ostrov, D.A.

Funding Organization	Location	Grant Number
National Institutes of Health/National Institute Of Allergy and Infectious Diseases (NIH/NIAID)	United States	1R01AI103348-01

Revision History (Full details and data files)

Version 1.0: 2020-11-25
Type: Initial release
Version 1.1: 2023-10-11
Changes: Data collection, Database references, Refinement description
Version 1.2: 2024-11-20
Changes: Structure summary
