6V81 | pdb_00006v81

The crystal structure of the outer-membrane transporter YncD


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.96 Å
  • R-Value Free:
    0.314 (Depositor), 0.324 (DCC)
  • R-Value Work:
    0.277 (Depositor), 0.278 (DCC)
  • R-Value Observed:
    0.279 (Depositor)

wwPDB Validation 3D Report Full Report

Validation slider image for 6V81

Ligand Structure Quality Assessment


This is version 1.3 of the entry. See complete history

Literature

The crystal structure of the TonB-dependent transporter YncD reveals a positively charged substrate-binding site.

Grinter, R.Lithgow, T.

(2020) Acta Crystallogr D Struct Biol 76: 484-495

  • DOI: https://doi.org/10.1107/S2059798320004398
  • Primary Citation Related Structures:
    6V81

  • PubMed Abstract:

    The outer membrane of Gram-negative bacteria is highly impermeable to hydrophilic molecules of larger than 600 Da, protecting these bacteria from toxins present in the environment. In order to transport nutrients across this impermeable membrane, Gram-negative bacteria utilize a diverse family of outer-membrane proteins called TonB-dependent transporters. The majority of the members of this family transport iron-containing substrates. However, it is becoming increasingly clear that TonB-dependent transporters target chemically diverse substrates. In this work, the structure and phylogenetic distribution of the TonB-dependent transporter YncD are investigated. It is shown that while YncD is present in some enteropathogens, including Escherichia coli and Salmonella spp., it is also widespread in Gammaproteobacteria and Betaproteobacteria of environmental origin. The structure of YncD was determined, showing that despite a distant evolutionary relationship, it shares structural features with the ferric citrate transporter FecA, including a compact positively charged substrate-binding site. Despite these shared features, it is shown that YncD does not contribute to the growth of E. coli in pure culture under iron-limiting conditions or with ferric citrate as an iron source. Previous studies of transcriptional regulation in E. coli show that YncD is not induced under iron-limiting conditions and is unresponsive to the ferric uptake regulator (Fur). These observations, combined with the data presented here, suggest that YncD is not responsible for the transport of an iron-containing substrate.


  • Organizational Affiliation
    • Infection and Immunity Program, Biomedicine Discovery Institute and Department of Microbiology, Monash University, Clayton, VIC 3800, Australia.

Macromolecule Content

  • Total Structure Weight: 77.67 kDa
  • Atom Count: 5,106
  • Modeled Residue Count: 652
  • Deposited Residue Count: 700
  • Unique protein chains: 1

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
Probable TonB-dependent receptor YncD700Escherichia coli BW25113Mutation(s): 0
Gene Names: yncD
Membrane Entity: Yes
UniProt
Find proteins for P76115 (Escherichia coli (strain K12))
Explore P76115
Go to UniProtKB:  P76115
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP76115
Sequence Annotations
Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.96 Å
  • R-Value Free:  0.314 (Depositor), 0.324 (DCC)
  • R-Value Work:  0.277 (Depositor), 0.278 (DCC)
  • R-Value Observed: 0.279 (Depositor)
Space Group: P 21 2 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 87.94α = 90
b = 98.64β = 90
c = 124.86γ = 90
Software Package:
Software NamePurpose
PHENIXrefinement
PDB_EXTRACTdata extraction
XDSdata reduction
Aimlessdata scaling
PHENIXphasing

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History

& Funding Information

Deposition Data

  • Released Date: 2020-05-06
  • Deposition Author(s): Grinter, R.

Funding OrganizationLocationGrant Number
Wellcome TrustUnited Kingdom106077/Z/14/Z

Revision History  (Full details and data files)

  • Version 1.0: 2020-05-06
    Type: Initial release
  • Version 1.1: 2020-05-13
    Changes: Database references
  • Version 1.2: 2020-07-29
    Type: Remediation
    Reason: Carbohydrate remediation
    Changes: Data collection, Derived calculations, Structure summary
  • Version 1.3: 2024-10-23
    Changes: Data collection, Database references, Structure summary
