6V1F

Crystal structure of the bromodomain of human BRD7 bound to BI9564


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.00 Å
  • R-Value Free: 0.249
  • R-Value Work: 0.217
  • R-Value Observed: 0.219

wwPDB Validation   3D Report Full Report


Ligand Structure Quality Assessment


This is version 1.1 of the entry. See complete history


Literature

Structural Basis of Inhibitor Selectivity in the BRD7/9 Subfamily of Bromodomains.

Karim, R.M.Chan, A.Zhu, J.Y.Schonbrunn, E.

(2020) J Med Chem 63: 3227-3237

  • DOI: 10.1021/acs.jmedchem.9b01980
  • Primary Citation of Related Structures:
    6PPA, 6UZF, 6V0Q, 6V0S, 6V0U, 6V0X, 6V14, 6V16, 6V17, 6V1B, 6V1E, 6V1F, 6V1H, 6V1K, 6V1L, 6V1U

  • PubMed Abstract:
  • Inhibition of the bromodomain containing protein 9 (BRD9) by small molecules is an attractive strategy to target mutated SWI/SNF chromatin-remodeling complexes in cancer. However, reported BRD9 inhibitors also inhibit the closely related bromodomain-containing protein 7 (BRD7), which has different biological functions ...

    Inhibition of the bromodomain containing protein 9 (BRD9) by small molecules is an attractive strategy to target mutated SWI/SNF chromatin-remodeling complexes in cancer. However, reported BRD9 inhibitors also inhibit the closely related bromodomain-containing protein 7 (BRD7), which has different biological functions. The structural basis for differential potency and selectivity of BRD9 inhibitors is largely unknown because of the lack of structural information on BRD7. Here, we biochemically and structurally characterized diverse inhibitors with varying degrees of potency and selectivity for BRD9 over BRD7. Novel cocrystal structures of BRD7 liganded with new and previously reported inhibitors of five different chemical scaffolds were determined alongside BRD9 and BRD4. We also report the discovery of first-in-class dual bromodomain-kinase inhibitors outside the bromodomain and extraterminal family targeting BRD7 and BRD9. Combined, the data provide a new framework for the development of BRD7/9 inhibitors with improved selectivity or additional polypharmacologic properties.


    Organizational Affiliation

    Department of Molecular Medicine, USF Morsani College of Medicine, University of South Florida, Tampa, Florida 33612, United States.



Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChainsSequence LengthOrganismDetailsImage
Bromodomain-containing protein 7A126Homo sapiensMutation(s): 0
Gene Names: BRD7BP75CELTIX1
UniProt & NIH Common Fund Data Resources
Find proteins for Q9NPI1 (Homo sapiens)
Explore Q9NPI1
Go to UniProtKB:  Q9NPI1
PHAROS:  Q9NPI1
GTEx:  ENSG00000166164
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ9NPI1
Protein Feature View
Expand
  • Reference Sequence
Small Molecules
Ligands 1 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
5U6 (Subject of Investigation/LOI)
Query on 5U6

Download Ideal Coordinates CCD File
B [auth A]4-[4-[(dimethylamino)methyl]-2,5-dimethoxy-phenyl]-2-methyl-2,7-naphthyridin-1-one
C20 H23 N3 O3
BJFSUDWKXGMUKA-UHFFFAOYSA-N
 Ligand Interaction
Binding Affinity Annotations
IDSourceBinding Affinity
5U6 Binding MOAD:  6V1F Kd: 418 (nM) from 1 assay(s)
BindingDB:  6V1F Kd: min: 73, max: 418 (nM) from 4 assay(s)
IC50: 3410 (nM) from 1 assay(s)
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.00 Å
  • R-Value Free: 0.249
  • R-Value Work: 0.217
  • R-Value Observed: 0.219
  • Space Group: C 2 2 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 71.49α = 90
b = 108.71β = 90
c = 36.65γ = 90
Software Package:
Software NamePurpose
PHENIXrefinement
XSCALEdata scaling
PDB_EXTRACTdata extraction
XDSdata reduction
PHASERphasing

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2020-03-11
    Type: Initial release
  • Version 1.1: 2020-04-08
    Changes: Database references
