Crystal structure of human GAC in complex with inhibitor UPGL00012
Huang, Q., Cerione, R.A.To be published.
Experimental Data Snapshot
Starting Model: experimental
View more details
wwPDB Validation   3D Report Full Report
Currently 6UMC does not have a validation slider image.
Entity ID: 1 | |||||
---|---|---|---|---|---|
Molecule | Chains | Sequence Length | Organism | Details | Image |
Glutaminase kidney isoform, mitochondrial | 527 | Homo sapiens | Mutation(s): 0  Gene Names: GLS, GLS1, KIAA0838 EC: 3.5.1.2 | ||
UniProt & NIH Common Fund Data Resources | |||||
Find proteins for O94925 (Homo sapiens) Explore O94925  Go to UniProtKB:  O94925 | |||||
PHAROS:  O94925 GTEx:  ENSG00000115419  | |||||
Entity Groups   | |||||
Sequence Clusters | 30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity | ||||
UniProt Group | O94925 | ||||
Sequence AnnotationsExpand | |||||
|
Ligands 1 Unique | |||||
---|---|---|---|---|---|
ID | Chains | Name / Formula / InChI Key | 2D Diagram | 3D Interactions | |
U27 (Subject of Investigation/LOI) Query on U27 | E [auth A], F [auth D] | 2-phenyl-N-{5-[(3R)-3-({5-[(phenylacetyl)amino]-1,3,4-thiadiazol-2-yl}oxy)pyrrolidin-1-yl]-1,3,4-thiadiazol-2-yl}acetamide C24 H23 N7 O3 S2 JGTIIKRXHSZCBG-GOSISDBHSA-N |
Length ( Å ) | Angle ( ˚ ) |
---|---|
a = 99.979 | α = 90 |
b = 138.816 | β = 90 |
c = 176.64 | γ = 90 |
Software Name | Purpose |
---|---|
PHENIX | refinement |
HKL-2000 | data reduction |
HKL-2000 | data scaling |
PHENIX | phasing |
View Full Validation Report
Currently 6UMC does not have a validation slider image.
Funding Organization | Location | Grant Number |
---|---|---|
National Institutes of Health/National Human Genome Research Institute (NIH/NHGRI) | United States | GM122575 |
National Institutes of Health/National Human Genome Research Institute (NIH/NHGRI) | United States | GM124166 |
National Institutes of Health/National Human Genome Research Institute (NIH/NHGRI) | United States | CA201402 |
