6UKI

HhaI endonuclease in Complex with DNA in space group P212121 (pH 6.0)


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.7 Å
  • R-Value Free: 0.224
  • R-Value Work: 0.180

wwPDB Validation 3D Report Full Report


This is version 1.1 of the entry. See complete history

Literature

Structure of HhaI endonuclease with cognate DNA at an atomic resolution of 1.0 angstrom.

Horton, J.R.Yang, J.Zhang, X.Petronzio, T.Fomenkov, A.Wilson, G.G.Roberts, R.J.Cheng, X.

(2019) Nucleic Acids Res. --: --

  • DOI: 10.1093/nar/gkz1195
  • Primary Citation of Related Structures:

  • PubMed Abstract:
  • HhaI, a Type II restriction endonuclease, recognizes the symmetric sequence 5'-GCG↓C-3' in duplex DNA and cleaves ('↓') to produce fragments with 2-base, 3'-overhangs. We determined the structure of HhaI in complex with cognate DNA at an ultra-high a ...

    HhaI, a Type II restriction endonuclease, recognizes the symmetric sequence 5'-GCG↓C-3' in duplex DNA and cleaves ('↓') to produce fragments with 2-base, 3'-overhangs. We determined the structure of HhaI in complex with cognate DNA at an ultra-high atomic resolution of 1.0 Å. Most restriction enzymes act as dimers with two catalytic sites, and cleave the two strands of duplex DNA simultaneously, in a single binding event. HhaI, in contrast, acts as a monomer with only one catalytic site, and cleaves the DNA strands sequentially, one after the other. HhaI comprises three domains, each consisting of a mixed five-stranded β sheet with a defined function. The first domain contains the catalytic-site; the second contains residues for sequence recognition; and the third contributes to non-specific DNA binding. The active-site belongs to the 'PD-D/EXK' superfamily of nucleases and contains the motif SD-X11-EAK. The first two domains are similar in structure to two other monomeric restriction enzymes, HinP1I (G↓CGC) and MspI (C↓CGG), which produce fragments with 5'-overhangs. The third domain, present only in HhaI, shifts the positions of the recognition residues relative to the catalytic site enabling this enzyme to cleave the recognition sequence at a different position. The structure of M.HhaI, the biological methyltransferase partner of HhaI, was determined earlier. Together, these two structures represent the first natural pair of restriction-modification enzymes to be characterized in atomic detail.


    Organizational Affiliation

    New England Biolabs, Inc., Ipswich, MA 01938, USA.,Department of Epigenetics & Molecular Carcinogenesis, The University of Texas MD Anderson Cancer Center, Houston, TX 77030, USA.




Macromolecules

Find similar proteins by: Sequence  |  Structure


Entity ID: 1
MoleculeChainsSequence LengthOrganismDetails
HhaI Restriction Endonuclease
X, Y
258Haemophilus parahaemolyticus HK385Mutation(s): 0
Find proteins for I3DBY6 (Haemophilus parahaemolyticus HK385)
Go to UniProtKB:  I3DBY6
Entity ID: 2
MoleculeChainsLengthOrganism
DNA (5'-D(*CP*TP*GP*TP*TP*GP*CP*GP*CP*TP*TP*GP*GP*A)-3')A,D14Haemophilus parahaemolyticus
Entity ID: 3
MoleculeChainsLengthOrganism
DNA (5'-D(*TP*CP*CP*AP*AP*GP*CP*GP*CP*AP*AP*CP*AP*G)-3')B,E14Haemophilus parahaemolyticus
Small Molecules
Ligands 2 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
CA
Query on CA

Download SDF File
Download CCD File
A, D, X, Y
CALCIUM ION
Ca
BHPQYMZQTOCNFJ-UHFFFAOYSA-N
 Ligand Interaction
EDO
Query on EDO

Download SDF File
Download CCD File
B
1,2-ETHANEDIOL
ETHYLENE GLYCOL
C2 H6 O2
LYCAIKOWRPUZTN-UHFFFAOYSA-N
 Ligand Interaction
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.7 Å
  • R-Value Free: 0.224
  • R-Value Work: 0.180
  • Space Group: P 21 21 21
Unit Cell:
Length (Å)Angle (°)
a = 94.411α = 90.00
b = 94.998β = 90.00
c = 97.868γ = 90.00
Software Package:
Software NamePurpose
PHENIXphasing
HKL-2000data reduction
SERGUIdata collection
PHENIXrefinement
HKL-2000data scaling

Structure Validation

View Full Validation Report or Ramachandran Plots



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)United StatesGM049245-23

Revision History

  • Version 1.0: 2019-12-18
    Type: Initial release
  • Version 1.1: 2020-01-08
    Type: Database references
