6UCQ

Crystal structure of the Thermus thermophilus 70S ribosome recycling complex


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 3.5 Å
  • R-Value Free: 0.294
  • R-Value Work: 0.244

wwPDB Validation 3D Report Full Report


This is version 1.2 of the entry. See complete history

Literature

Structural basis for ribosome recycling by RRF and tRNA.

Zhou, D.Tanzawa, T.Lin, J.Gagnon, M.G.

(2020) Nat.Struct.Mol.Biol. 27: 25-32

  • DOI: 10.1038/s41594-019-0350-7

  • PubMed Abstract:
  • The bacterial ribosome is recycled into subunits by two conserved proteins, elongation factor G (EF-G) and the ribosome recycling factor (RRF). The molecular basis for ribosome recycling by RRF and EF-G remains unclear. Here, we report the crystal st ...

    The bacterial ribosome is recycled into subunits by two conserved proteins, elongation factor G (EF-G) and the ribosome recycling factor (RRF). The molecular basis for ribosome recycling by RRF and EF-G remains unclear. Here, we report the crystal structure of a posttermination Thermus thermophilus 70S ribosome complexed with EF-G, RRF and two transfer RNAs at a resolution of 3.5 Å. The deacylated tRNA in the peptidyl (P) site moves into a previously unsuspected state of binding (peptidyl/recycling, p/R) that is analogous to that seen during initiation. The terminal end of the p/R-tRNA forms nonfavorable contacts with the 50S subunit while RRF wedges next to central inter-subunit bridges, illuminating the active roles of tRNA and RRF in dissociation of ribosomal subunits. The structure uncovers a missing snapshot of tRNA as it transits between the P and exit (E) sites, providing insights into the mechanisms of ribosome recycling and tRNA translocation.


    Organizational Affiliation

    State Key Laboratory of Genetic Engineering, School of Life Sciences, Zhongshan Hospital, Fudan University, Shanghai, China. linjinzhong@fudan.edu.cn.,Department of Microbiology and Immunology, University of Texas Medical Branch, Galveston, Texas, USA. magagnon@utmb.edu.,Department of Microbiology and Immunology, University of Texas Medical Branch, Galveston, Texas, USA.,State Key Laboratory of Genetic Engineering, School of Life Sciences, Zhongshan Hospital, Fudan University, Shanghai, China.,Sealy Center for Structural Biology and Molecular Biophysics, University of Texas Medical Branch, Galveston, Texas, USA. magagnon@utmb.edu.,Institute for Human Infections and Immunity, University of Texas Medical Branch, Galveston, Texas, USA. magagnon@utmb.edu.




Macromolecules

Find similar proteins by: Sequence  |  Structure


Entity ID: 3
MoleculeChainsSequence LengthOrganismDetails
50S ribosomal protein L2
1D, 2D
276Thermus thermophilus (strain HB8 / ATCC 27634 / DSM 579)Mutation(s): 0
Gene Names: rplB
Find proteins for P60405 (Thermus thermophilus (strain HB8 / ATCC 27634 / DSM 579))
Go to UniProtKB:  P60405
Entity ID: 4
MoleculeChainsSequence LengthOrganismDetails
50S ribosomal protein L3
1E, 2E
206Thermus thermophilus (strain HB8 / ATCC 27634 / DSM 579)Mutation(s): 0
Gene Names: rplC
Find proteins for Q5SHN8 (Thermus thermophilus (strain HB8 / ATCC 27634 / DSM 579))
Go to UniProtKB:  Q5SHN8
Entity ID: 5
MoleculeChainsSequence LengthOrganismDetails
50S ribosomal protein L4
1F, 2F
210Thermus thermophilus (strain HB8 / ATCC 27634 / DSM 579)Mutation(s): 0
Gene Names: rplD
Find proteins for Q5SHN9 (Thermus thermophilus (strain HB8 / ATCC 27634 / DSM 579))
Go to UniProtKB:  Q5SHN9
Entity ID: 6
MoleculeChainsSequence LengthOrganismDetails
50S ribosomal protein L5
1G, 2G
182Thermus thermophilus (strain HB8 / ATCC 27634 / DSM 579)Mutation(s): 0
Gene Names: rplE
Find proteins for Q5SHQ0 (Thermus thermophilus (strain HB8 / ATCC 27634 / DSM 579))
Go to UniProtKB:  Q5SHQ0
Entity ID: 7
MoleculeChainsSequence LengthOrganismDetails
50S ribosomal protein L6
1H, 2H
180Thermus thermophilus (strain HB8 / ATCC 27634 / DSM 579)Mutation(s): 0
Gene Names: rplF
Find proteins for P0DOY8 (Thermus thermophilus (strain HB8 / ATCC 27634 / DSM 579))
Go to UniProtKB:  P0DOY8
Entity ID: 8
MoleculeChainsSequence LengthOrganismDetails
50S ribosomal protein L13
1N, 2N
140Thermus thermophilus (strain HB8 / ATCC 27634 / DSM 579)Mutation(s): 0
Gene Names: rplM
Find proteins for P60488 (Thermus thermophilus (strain HB8 / ATCC 27634 / DSM 579))
Go to UniProtKB:  P60488
Entity ID: 9
MoleculeChainsSequence LengthOrganismDetails
50S ribosomal protein L14
1O, 2O
122Thermus thermophilus (strain HB8 / ATCC 27634 / DSM 579)Mutation(s): 0
Gene Names: rplN
Find proteins for Q5SHP8 (Thermus thermophilus (strain HB8 / ATCC 27634 / DSM 579))
Go to UniProtKB:  Q5SHP8
Entity ID: 10
MoleculeChainsSequence LengthOrganismDetails
50S ribosomal protein L15
1P, 2P
150Thermus thermophilus (strain HB8 / ATCC 27634 / DSM 579)Mutation(s): 0
Gene Names: rplO
Find proteins for Q5SHQ7 (Thermus thermophilus (strain HB8 / ATCC 27634 / DSM 579))
Go to UniProtKB:  Q5SHQ7
Entity ID: 11
MoleculeChainsSequence LengthOrganismDetails
50S ribosomal protein L16
1Q, 2Q
141Thermus thermophilus (strain HB8 / ATCC 27634 / DSM 579)Mutation(s): 0
Gene Names: rplP
Find proteins for P60489 (Thermus thermophilus (strain HB8 / ATCC 27634 / DSM 579))
Go to UniProtKB:  P60489
Entity ID: 12
MoleculeChainsSequence LengthOrganismDetails
50S ribosomal protein L17
1R, 2R
118Thermus thermophilus (strain HB8 / ATCC 27634 / DSM 579)Mutation(s): 0
Gene Names: rplQ (rpl17)
Find proteins for Q9Z9H5 (Thermus thermophilus (strain HB8 / ATCC 27634 / DSM 579))
Go to UniProtKB:  Q9Z9H5
Entity ID: 13
MoleculeChainsSequence LengthOrganismDetails
50S ribosomal protein L18
1S, 2S
112Thermus thermophilus (strain HB8 / ATCC 27634 / DSM 579)Mutation(s): 0
Gene Names: rplR
Find proteins for Q5SHQ4 (Thermus thermophilus (strain HB8 / ATCC 27634 / DSM 579))
Go to UniProtKB:  Q5SHQ4
Entity ID: 14
MoleculeChainsSequence LengthOrganismDetails
50S ribosomal protein L19
1T, 2T
146Thermus thermophilus (strain HB8 / ATCC 27634 / DSM 579)Mutation(s): 0
Gene Names: rplS
Find proteins for P60490 (Thermus thermophilus (strain HB8 / ATCC 27634 / DSM 579))
Go to UniProtKB:  P60490
Entity ID: 15
MoleculeChainsSequence LengthOrganismDetails
50S ribosomal protein L20
1U, 2U
118Thermus thermophilus (strain HB8 / ATCC 27634 / DSM 579)Mutation(s): 0
Gene Names: rplT
Find proteins for P60491 (Thermus thermophilus (strain HB8 / ATCC 27634 / DSM 579))
Go to UniProtKB:  P60491
Entity ID: 16
MoleculeChainsSequence LengthOrganismDetails
50S ribosomal protein L21
1V, 2V
101Thermus thermophilus (strain HB8 / ATCC 27634 / DSM 579)Mutation(s): 0
Gene Names: rplU
Find proteins for P60492 (Thermus thermophilus (strain HB8 / ATCC 27634 / DSM 579))
Go to UniProtKB:  P60492
Entity ID: 17
MoleculeChainsSequence LengthOrganismDetails
50S ribosomal protein L22
1W, 2W
113Thermus thermophilus (strain HB8 / ATCC 27634 / DSM 579)Mutation(s): 0
Gene Names: rplV
Find proteins for Q5SHP3 (Thermus thermophilus (strain HB8 / ATCC 27634 / DSM 579))
Go to UniProtKB:  Q5SHP3
Entity ID: 18
MoleculeChainsSequence LengthOrganismDetails
50S ribosomal protein L23
1X, 2X
96Thermus thermophilus (strain HB8 / ATCC 27634 / DSM 579)Mutation(s): 0
Gene Names: rplW
Find proteins for Q5SHP0 (Thermus thermophilus (strain HB8 / ATCC 27634 / DSM 579))
Go to UniProtKB:  Q5SHP0
Entity ID: 19
MoleculeChainsSequence LengthOrganismDetails
50S ribosomal protein L24
1Y, 2Y
110Thermus thermophilus (strain HB8 / ATCC 27634 / DSM 579)Mutation(s): 0
Gene Names: rplX
Find proteins for Q5SHP9 (Thermus thermophilus (strain HB8 / ATCC 27634 / DSM 579))
Go to UniProtKB:  Q5SHP9
Entity ID: 20
MoleculeChainsSequence LengthOrganismDetails
50S ribosomal protein L25
1Z, 2Z
206Thermus thermophilus (strain HB8 / ATCC 27634 / DSM 579)Mutation(s): 0
Gene Names: rplY (rpl25, rptL5)
Find proteins for Q5SHZ1 (Thermus thermophilus (strain HB8 / ATCC 27634 / DSM 579))
Go to UniProtKB:  Q5SHZ1
Entity ID: 21
MoleculeChainsSequence LengthOrganismDetails
50S ribosomal protein L27
10, 20
85Thermus thermophilus (strain HB8 / ATCC 27634 / DSM 579)Mutation(s): 0
Gene Names: rpmA
Find proteins for P60493 (Thermus thermophilus (strain HB8 / ATCC 27634 / DSM 579))
Go to UniProtKB:  P60493
Entity ID: 22
MoleculeChainsSequence LengthOrganismDetails
50S ribosomal protein L28
11, 21
98Thermus thermophilus (strain HB8 / ATCC 27634 / DSM 579)Mutation(s): 0
Gene Names: rpmB
Find proteins for P60494 (Thermus thermophilus (strain HB8 / ATCC 27634 / DSM 579))
Go to UniProtKB:  P60494
Entity ID: 23
MoleculeChainsSequence LengthOrganismDetails
50S ribosomal protein L29
12, 22
72Thermus thermophilus (strain HB8 / ATCC 27634 / DSM 579)Mutation(s): 0
Gene Names: rpmC
Find proteins for Q5SHP6 (Thermus thermophilus (strain HB8 / ATCC 27634 / DSM 579))
Go to UniProtKB:  Q5SHP6
Entity ID: 24
MoleculeChainsSequence LengthOrganismDetails
50S ribosomal protein L30
13, 23
60Thermus thermophilus (strain HB8 / ATCC 27634 / DSM 579)Mutation(s): 0
Gene Names: rpmD
Find proteins for Q5SHQ6 (Thermus thermophilus (strain HB8 / ATCC 27634 / DSM 579))
Go to UniProtKB:  Q5SHQ6
Entity ID: 25
MoleculeChainsSequence LengthOrganismDetails
50S ribosomal protein L31
14, 24
71Thermus thermophilus (strain HB8 / ATCC 27634 / DSM 579)Mutation(s): 0
Gene Names: rpmE
Find proteins for Q5SJE1 (Thermus thermophilus (strain HB8 / ATCC 27634 / DSM 579))
Go to UniProtKB:  Q5SJE1
Entity ID: 26
MoleculeChainsSequence LengthOrganismDetails
50S ribosomal protein L32
15, 25
60Thermus thermophilus (strain HB8 / ATCC 27634 / DSM 579)Mutation(s): 0
Gene Names: rpmF (rpl32)
Find proteins for P80339 (Thermus thermophilus (strain HB8 / ATCC 27634 / DSM 579))
Go to UniProtKB:  P80339
Entity ID: 27
MoleculeChainsSequence LengthOrganismDetails
50S ribosomal protein L33
16, 26
54Thermus thermophilus (strain HB8 / ATCC 27634 / DSM 579)Mutation(s): 0
Gene Names: rpmG (rpl33)
Find proteins for P35871 (Thermus thermophilus (strain HB8 / ATCC 27634 / DSM 579))
Go to UniProtKB:  P35871
Entity ID: 28
MoleculeChainsSequence LengthOrganismDetails
50S ribosomal protein L34
17, 27
49Thermus thermophilus (strain HB8 / ATCC 27634 / DSM 579)Mutation(s): 0
Gene Names: rpmH (rpl34)
Find proteins for P80340 (Thermus thermophilus (strain HB8 / ATCC 27634 / DSM 579))
Go to UniProtKB:  P80340
Entity ID: 29
MoleculeChainsSequence LengthOrganismDetails
50S ribosomal protein L35
18, 28
65Thermus thermophilus (strain HB8 / ATCC 27634 / DSM 579)Mutation(s): 0
Gene Names: rpmI
Find proteins for Q5SKU1 (Thermus thermophilus (strain HB8 / ATCC 27634 / DSM 579))
Go to UniProtKB:  Q5SKU1
Entity ID: 30
MoleculeChainsSequence LengthOrganismDetails
50S ribosomal protein L36
19, 29
37Thermus thermophilus (strain HB8 / ATCC 27634 / DSM 579)Mutation(s): 0
Gene Names: rpmJ
Find proteins for Q5SHR2 (Thermus thermophilus (strain HB8 / ATCC 27634 / DSM 579))
Go to UniProtKB:  Q5SHR2
Entity ID: 32
MoleculeChainsSequence LengthOrganismDetails
30S ribosomal protein S2
1b, 2b
256Thermus thermophilus (strain HB8 / ATCC 27634 / DSM 579)Mutation(s): 0
Gene Names: rpsB (rps2)
Find proteins for P80371 (Thermus thermophilus (strain HB8 / ATCC 27634 / DSM 579))
Go to UniProtKB:  P80371
Entity ID: 33
MoleculeChainsSequence LengthOrganismDetails
30S ribosomal protein S3
1c, 2c
239Thermus thermophilus (strain HB8 / ATCC 27634 / DSM 579)Mutation(s): 0
Gene Names: rpsC (rps3)
Find proteins for P80372 (Thermus thermophilus (strain HB8 / ATCC 27634 / DSM 579))
Go to UniProtKB:  P80372
Entity ID: 34
MoleculeChainsSequence LengthOrganismDetails
30S ribosomal protein S4
1d, 2d
209Thermus thermophilus (strain HB8 / ATCC 27634 / DSM 579)Mutation(s): 0
Gene Names: rpsD (rps4)
Find proteins for P80373 (Thermus thermophilus (strain HB8 / ATCC 27634 / DSM 579))
Go to UniProtKB:  P80373
Entity ID: 35
MoleculeChainsSequence LengthOrganismDetails
30S ribosomal protein S5
1e, 2e
162Thermus thermophilus (strain HB8 / ATCC 27634 / DSM 579)Mutation(s): 0
Gene Names: rpsE
Find proteins for Q5SHQ5 (Thermus thermophilus (strain HB8 / ATCC 27634 / DSM 579))
Go to UniProtKB:  Q5SHQ5
Entity ID: 36
MoleculeChainsSequence LengthOrganismDetails
30S ribosomal protein S6
1f, 2f
101Thermus thermophilus (strain HB8 / ATCC 27634 / DSM 579)Mutation(s): 0
Gene Names: rpsF
Find proteins for Q5SLP8 (Thermus thermophilus (strain HB8 / ATCC 27634 / DSM 579))
Go to UniProtKB:  Q5SLP8
Entity ID: 37
MoleculeChainsSequence LengthOrganismDetails
30S ribosomal protein S7
1g, 2g
156Thermus thermophilus (strain HB8 / ATCC 27634 / DSM 579)Mutation(s): 0
Gene Names: rpsG (rps7)
Find proteins for P17291 (Thermus thermophilus (strain HB8 / ATCC 27634 / DSM 579))
Go to UniProtKB:  P17291
Entity ID: 38
MoleculeChainsSequence LengthOrganismDetails
30S ribosomal protein S8
1h, 2h
138Thermus thermophilus (strain HB8 / ATCC 27634 / DSM 579)Mutation(s): 0
Gene Names: rpsH
Find proteins for P0DOY9 (Thermus thermophilus (strain HB8 / ATCC 27634 / DSM 579))
Go to UniProtKB:  P0DOY9
Entity ID: 39
MoleculeChainsSequence LengthOrganismDetails
30S ribosomal protein S9
1i, 2i
128Thermus thermophilus (strain HB8 / ATCC 27634 / DSM 579)Mutation(s): 0
Gene Names: rpsI (rps9)
Find proteins for P80374 (Thermus thermophilus (strain HB8 / ATCC 27634 / DSM 579))
Go to UniProtKB:  P80374
Entity ID: 40
MoleculeChainsSequence LengthOrganismDetails
30S ribosomal protein S10
1j, 2j
105Thermus thermophilus (strain HB8 / ATCC 27634 / DSM 579)Mutation(s): 0
Gene Names: rpsJ
Find proteins for Q5SHN7 (Thermus thermophilus (strain HB8 / ATCC 27634 / DSM 579))
Go to UniProtKB:  Q5SHN7
Entity ID: 41
MoleculeChainsSequence LengthOrganismDetails
30S ribosomal protein S11
1k, 2k
129Thermus thermophilus (strain HB8 / ATCC 27634 / DSM 579)Mutation(s): 0
Gene Names: rpsK (rps11)
Find proteins for P80376 (Thermus thermophilus (strain HB8 / ATCC 27634 / DSM 579))
Go to UniProtKB:  P80376
Entity ID: 42
MoleculeChainsSequence LengthOrganismDetails
30S ribosomal protein S12
1l, 2l
132Thermus thermophilus (strain HB8 / ATCC 27634 / DSM 579)Mutation(s): 0
Gene Names: rpsL
Find proteins for Q5SHN3 (Thermus thermophilus (strain HB8 / ATCC 27634 / DSM 579))
Go to UniProtKB:  Q5SHN3
Entity ID: 43
MoleculeChainsSequence LengthOrganismDetails
30S ribosomal protein S13
1m, 2m
126Thermus thermophilus (strain HB8 / ATCC 27634 / DSM 579)Mutation(s): 0
Gene Names: rpsM (rps13)
Find proteins for P80377 (Thermus thermophilus (strain HB8 / ATCC 27634 / DSM 579))
Go to UniProtKB:  P80377
Entity ID: 44
MoleculeChainsSequence LengthOrganismDetails
30S ribosomal protein S14 type Z
1n, 2n
61Thermus thermophilus (strain HB8 / ATCC 27634 / DSM 579)Mutation(s): 0
Gene Names: rpsZ (rpsN)
Find proteins for P0DOY6 (Thermus thermophilus (strain HB8 / ATCC 27634 / DSM 579))
Go to UniProtKB:  P0DOY6
Entity ID: 45
MoleculeChainsSequence LengthOrganismDetails
30S ribosomal protein S15
1o, 2o
89Thermus thermophilus (strain HB8 / ATCC 27634 / DSM 579)Mutation(s): 0
Gene Names: rpsO
Find proteins for Q5SJ76 (Thermus thermophilus (strain HB8 / ATCC 27634 / DSM 579))
Go to UniProtKB:  Q5SJ76
Entity ID: 46
MoleculeChainsSequence LengthOrganismDetails
30S ribosomal protein S16
1p, 2p
88Thermus thermophilus (strain HB8 / ATCC 27634 / DSM 579)Mutation(s): 0
Gene Names: rpsP
Find proteins for Q5SJH3 (Thermus thermophilus (strain HB8 / ATCC 27634 / DSM 579))
Go to UniProtKB:  Q5SJH3
Entity ID: 47
MoleculeChainsSequence LengthOrganismDetails
30S ribosomal protein S17
1q, 2q
105Thermus thermophilus (strain HB8 / ATCC 27634 / DSM 579)Mutation(s): 0
Gene Names: rpsQ
Find proteins for P0DOY7 (Thermus thermophilus (strain HB8 / ATCC 27634 / DSM 579))
Go to UniProtKB:  P0DOY7
Entity ID: 48
MoleculeChainsSequence LengthOrganismDetails
30S ribosomal protein S18
1r, 2r
88Thermus thermophilus (strain HB8 / ATCC 27634 / DSM 579)Mutation(s): 0
Gene Names: rpsR
Find proteins for Q5SLQ0 (Thermus thermophilus (strain HB8 / ATCC 27634 / DSM 579))
Go to UniProtKB:  Q5SLQ0
Entity ID: 49
MoleculeChainsSequence LengthOrganismDetails
30S ribosomal protein S19
1s, 2s
93Thermus thermophilus (strain HB8 / ATCC 27634 / DSM 579)Mutation(s): 0
Gene Names: rpsS
Find proteins for Q5SHP2 (Thermus thermophilus (strain HB8 / ATCC 27634 / DSM 579))
Go to UniProtKB:  Q5SHP2
Entity ID: 50
MoleculeChainsSequence LengthOrganismDetails
30S ribosomal protein S20
1t, 2t
106Thermus thermophilus (strain HB8 / ATCC 27634 / DSM 579)Mutation(s): 0
Gene Names: rpsT (rps20)
Find proteins for P80380 (Thermus thermophilus (strain HB8 / ATCC 27634 / DSM 579))
Go to UniProtKB:  P80380
Entity ID: 51
MoleculeChainsSequence LengthOrganismDetails
30S ribosomal protein Thx
1u, 2u
27Thermus thermophilus (strain HB8 / ATCC 27634 / DSM 579)Mutation(s): 0
Gene Names: rpsU
Find proteins for Q5SIH3 (Thermus thermophilus (strain HB8 / ATCC 27634 / DSM 579))
Go to UniProtKB:  Q5SIH3
Entity ID: 52
MoleculeChainsSequence LengthOrganismDetails
50S ribosomal protein L9,Elongation factor G
1v, 2v
758Thermus thermophilus (strain HB8 / ATCC 27634 / DSM 579)Mutation(s): 0
Gene Names: rplI, fusA (fus)
Find proteins for Q5SLQ1 (Thermus thermophilus (strain HB8 / ATCC 27634 / DSM 579))
Go to UniProtKB:  Q5SLQ1
Find proteins for Q5SHN5 (Thermus thermophilus (strain HB8 / ATCC 27634 / DSM 579))
Go to UniProtKB:  Q5SHN5
Entity ID: 53
MoleculeChainsSequence LengthOrganismDetails
Ribosome-recycling factor
1w, 2w
185Thermus thermophilus (strain HB8 / ATCC 27634 / DSM 579)Mutation(s): 0
Gene Names: frr
Find proteins for Q9WX76 (Thermus thermophilus (strain HB8 / ATCC 27634 / DSM 579))
Go to UniProtKB:  Q9WX76
Entity ID: 1
MoleculeChainsLengthOrganism
23S Ribosomal RNA1A,2A2915Thermus thermophilus HB8
Entity ID: 2
MoleculeChainsLengthOrganism
5S Ribosomal RNA1B,2B121Thermus thermophilus HB8
Entity ID: 31
MoleculeChainsLengthOrganism
16S Ribosomal RNA1a,2a1521Thermus thermophilus HB8
Entity ID: 54
MoleculeChainsLengthOrganism
P-site and E-site tRNAs1x,1y,2x,2y76Escherichia coli
Entity ID: 55
MoleculeChainsLengthOrganism
mRNA1z,2z21synthetic construct
Small Molecules
Ligands 5 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
K
Query on K

Download SDF File
Download CCD File
2A
POTASSIUM ION
K
NPYPAHLBTDXSSS-UHFFFAOYSA-N
 Ligand Interaction
GDP
Query on GDP

Download SDF File
Download CCD File
1v, 2v
GUANOSINE-5'-DIPHOSPHATE
C10 H15 N5 O11 P2
QGWNDRXFNXRZMB-UUOKFMHZSA-N
 Ligand Interaction
SF4
Query on SF4

Download SDF File
Download CCD File
1d, 2d
IRON/SULFUR CLUSTER
Fe4 S4
LJBDFODJNLIPKO-VKOJMFJBAC
 Ligand Interaction
ZN
Query on ZN

Download SDF File
Download CCD File
14, 15, 16, 19, 1n, 1Y, 24, 25, 26, 29, 2n, 2Y
ZINC ION
Zn
PTFCDOFLOPIGGS-UHFFFAOYSA-N
 Ligand Interaction
MG
Query on MG

Download SDF File
Download CCD File
10, 11, 12, 13, 15, 16, 17, 18, 19, 1a, 1A, 1B, 1b, 1D, 1d, 1E, 1e, 1F, 1g, 1H, 1i, 1l, 1m, 1n, 1N, 1o, 1O, 1p, 1P, 1q, 1Q, 1R, 1S, 1s, 1t, 1T, 1u, 1U, 1V, 1v, 1W, 1x, 1Y, 1y, 1z, 1Z, 20, 21, 23, 24, 25, 26, 27, 28, 29, 2a, 2A, 2B, 2b, 2c, 2d, 2D, 2E, 2e, 2F, 2f, 2g, 2h, 2i, 2k, 2l, 2m, 2N, 2O, 2o, 2p, 2P, 2Q, 2q, 2r, 2S, 2s, 2t, 2T, 2u, 2V, 2v, 2w, 2X, 2x, 2Y, 2y, 2Z, 2z
MAGNESIUM ION
Mg
JLVVSXFLKOJNIY-UHFFFAOYSA-N
 Ligand Interaction
Modified Residues  16 Unique
IDChainsTypeFormula2D DiagramParent
PSU
Query on PSU
1a, 1A, 1x, 1y, 2a, 2A, 2x, 2y
RNA LINKINGC9 H13 N2 O9 PU
5MC
Query on 5MC
1a, 1A, 2a, 2A
RNA LINKINGC10 H16 N3 O8 PC
M2G
Query on M2G
1a, 2a
RNA LINKINGC12 H18 N5 O8 PG
OMC
Query on OMC
1A, 2A
RNA LINKINGC10 H16 N3 O8 PC
MA6
Query on MA6
1a, 2a
RNA LINKINGC12 H18 N5 O7 PA
4SU
Query on 4SU
1x, 1y, 2x, 2y
RNA LINKINGC9 H13 N2 O8 P SU
MIA
Query on MIA
1x, 1y, 2x, 2y
RNA LINKINGC16 H24 N5 O7 P SA
2MG
Query on 2MG
1a, 2a
RNA LINKINGC11 H16 N5 O8 PG
UR3
Query on UR3
1a, 2a
RNA LINKINGC10 H15 N2 O9 PU
OMG
Query on OMG
1A, 2A
RNA LINKINGC11 H16 N5 O8 PG
7MG
Query on 7MG
1a, 1x, 1y, 2a, 2x, 2y
RNA LINKINGC11 H18 N5 O8 PG
5MU
Query on 5MU
1A, 1x, 1y, 2A, 2x, 2y
RNA LINKINGC10 H15 N2 O9 PU
2MA
Query on 2MA
1A, 2A
RNA LINKINGC11 H16 N5 O7 PA
2MU
Query on 2MU
1A, 2A
RNA LINKINGC11 H17 N2 O9 PU
0TD
Query on 0TD
1l, 2l
L-PEPTIDE LINKINGC5 H9 N O4 SASP
4OC
Query on 4OC
1a, 2a
RNA LINKINGC11 H18 N3 O8 PC
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 3.5 Å
  • R-Value Free: 0.294
  • R-Value Work: 0.244
  • Space Group: P 21 21 21
Unit Cell:
Length (Å)Angle (°)
a = 209.655α = 90.00
b = 448.741β = 90.00
c = 623.994γ = 90.00
Software Package:
Software NamePurpose
XDSdata reduction
Cootmodel building
PHASERphasing
XSCALEdata scaling
PHENIXrefinement
PDB_EXTRACTdata extraction

Structure Validation

View Full Validation Report or Ramachandran Plots



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Ministry of Science and Technology (MoST, China)China2017YFA0504602
National Natural Science Foundation of China (NSFC)China31770784
Other privateUnited StatesStartup funds from The University of Texas Medical Branch
Other privateUnited StatesRising Science and Technology Acquisition and Retention Program award
Other privateUnited StatesMcLaughlin Fellowship from the Institute for Human Infections and Immunity at The University of Texas Medical Branch
Other privateUnited StatesEndowment from Sealy and Smith Foundation to Sealy Center for Structural Biology at The University of Texas Medical Branch

Revision History

  • Version 1.0: 2019-12-25
    Type: Initial release
  • Version 1.1: 2020-01-08
    Type: Database references
  • Version 1.2: 2020-01-22
    Type: Database references
