EM structure of MPEG-1 (L425K, alpha conformation) soluble pre-pore complex

Experimental Data Snapshot

  • Resolution: 2.93 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE

wwPDB Validation   3D Report Full Report

This is version 2.0 of the entry. See complete history


The cryo-EM structure of the acid activatable pore-forming immune effector Macrophage-expressed gene 1.

Pang, S.S.Bayly-Jones, C.Radjainia, M.Spicer, B.A.Law, R.H.P.Hodel, A.W.Parsons, E.S.Ekkel, S.M.Conroy, P.J.Ramm, G.Venugopal, H.Bird, P.I.Hoogenboom, B.W.Voskoboinik, I.Gambin, Y.Sierecki, E.Dunstone, M.A.Whisstock, J.C.

(2019) Nat Commun 10: 4288-4288

  • DOI: https://doi.org/10.1038/s41467-019-12279-2
  • Primary Citation of Related Structures:
    6U23, 6U2J, 6U2K, 6U2L, 6U2W

  • PubMed Abstract:

    Macrophage-expressed gene 1 (MPEG1/Perforin-2) is a perforin-like protein that functions within the phagolysosome to damage engulfed microbes. MPEG1 is thought to form pores in target membranes, however, its mode of action remains unknown. We use cryo-Electron Microscopy (cryo-EM) to determine the 2.4 Å structure of a hexadecameric assembly of MPEG1 that displays the expected features of a soluble prepore complex. We further discover that MPEG1 prepore-like assemblies can be induced to perforate membranes through acidification, such as would occur within maturing phagolysosomes. We next solve the 3.6 Å cryo-EM structure of MPEG1 in complex with liposomes. These data reveal that a multi-vesicular body of 12 kDa (MVB12)-associated β-prism (MABP) domain binds membranes such that the pore-forming machinery of MPEG1 is oriented away from the bound membrane. This unexpected mechanism of membrane interaction suggests that MPEG1 remains bound to the phagolysosome membrane while simultaneously forming pores in engulfed bacterial targets.

  • Organizational Affiliation

    Department of Genetics, The University of Melbourne, Parkville, VIC, 3010, Australia.

Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Macrophage-expressed gene 1 proteinA [auth B]642Homo sapiensMutation(s): 1
Gene Names: MPEG1
Membrane Entity: Yes
UniProt & NIH Common Fund Data Resources
Find proteins for Q2M385 (Homo sapiens)
Explore Q2M385
Go to UniProtKB:  Q2M385
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ2M385
Sequence Annotations
  • Reference Sequence


Entity ID: 2
MoleculeChains Length2D Diagram Glycosylation3D Interactions
2-acetamido-2-deoxy-beta-D-glucopyranose-(1-4)-2-acetamido-2-deoxy-beta-D-glucopyranoseB [auth A],
Glycosylation Resources
GlyTouCan:  G42666HT
GlyCosmos:  G42666HT
GlyGen:  G42666HT
Experimental Data & Validation

Experimental Data

  • Resolution: 2.93 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE

Structure Validation

View Full Validation Report

Entry History & Funding Information

Deposition Data

Funding OrganizationLocationGrant Number
Australian Research Council (ARC)Australia--

Revision History  (Full details and data files)

  • Version 1.0: 2019-09-25
    Type: Initial release
  • Version 1.1: 2019-10-02
    Changes: Data collection, Database references
  • Version 1.2: 2020-01-15
    Changes: Author supporting evidence
  • Version 2.0: 2020-07-29
    Type: Remediation
    Reason: Carbohydrate remediation
    Changes: Atomic model, Data collection, Derived calculations, Structure summary
