6TQI

I-MOTIF STRUCTURE FORMED FROM THE C STRAND OF A HUMAN TELOMERE FRAGMENT


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.95 Å
  • R-Value Free: 0.227
  • R-Value Work: 0.239
  • R-Value Observed: 0.238

wwPDB Validation 3D Report Full Report



Literature

Native de novo structural determinations of non-canonical nucleic acid motifs by X-ray crystallography at long wavelengths.

Zhang, Y.El Omari, K.Duman, R.Liu, S.Haider, S.Wagner, A.Parkinson, G.N.Wei, D.

(2020) Nucleic Acids Res

  • DOI: 10.1093/nar/gkaa439
  • Structures With Same Primary Citation

  • PubMed Abstract:
  • Obtaining phase information remains a formidable challenge for nucleic acid structure determination. The introduction of an X-ray synchrotron beamline designed to be tunable to long wavelengths at Diamond Light Source has opened the possibility to na ...

    Obtaining phase information remains a formidable challenge for nucleic acid structure determination. The introduction of an X-ray synchrotron beamline designed to be tunable to long wavelengths at Diamond Light Source has opened the possibility to native de novo structure determinations by the use of intrinsic scattering elements. This provides opportunities to overcome the limitations of introducing modifying nucleotides, often required to derive phasing information. In this paper, we build on established methods to generate new tools for nucleic acid structure determinations. We report on the use of (i) native intrinsic potassium single-wavelength anomalous dispersion methods (K-SAD), (ii) use of anomalous scattering elements integral to the crystallization buffer (extrinsic cobalt and intrinsic potassium ions), (iii) extrinsic bromine and intrinsic phosphorus SAD to solve complex nucleic acid structures. Using the reported methods we solved the structures of (i) Pseudorabies virus (PRV) RNA G-quadruplex and ligand complex, (ii) PRV DNA G-quadruplex, and (iii) an i-motif of human telomeric sequence. Our results highlight the utility of using intrinsic scattering as a pathway to solve and determine non-canonical nucleic acid motifs and reveal the variability of topology, influence of ligand binding, and glycosidic angle rearrangements seen between RNA and DNA G-quadruplexes of the same sequence.


    Organizational Affiliation

    College of Science, Huazhong Agricultural University, Wuhan 430070, China.



Macromolecules
  • Find similar nucleic acids by: Sequence   |   Structure
Entity ID: 1
MoleculeChainsLengthOrganism
DNA (5'-*TP*AP*AP*CP*CP*CP*TP*AP*A-3')A9Homo sapiens
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.95 Å
  • R-Value Free: 0.227
  • R-Value Work: 0.239
  • R-Value Observed: 0.238
  • Space Group: P 62 2 2
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 31.9α = 90
b = 31.9β = 90
c = 81.88γ = 120
Software Package:
Software NamePurpose
REFMACrefinement
XDSdata reduction
Aimlessdata scaling
SHELXDEphasing
PDB_EXTRACTdata extraction

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History

  • Version 1.0: 2020-06-10
    Type: Initial release
